OWNER'S MANUAL
Digital Video Recorder
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
LE6016N
LE6016D
P/NO :
COV30400919
1105(V1.5)

Advertisement

Table of Contents
loading

Related Manuals for LG LE6016D

Summary of Contents for LG LE6016D

  • Page 1 OWNER’S MANUAL Digital Video Recorder Please read this manual carefully before operating your set and retain it for future reference. MODEL LE6016N LE6016D P/NO : COV30400919 1105(V1.5)

  • Page 2: Safety Information

    Safety Information Safety Information against harmful interference when the equipment is CAUTION operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used RISK OF ELECTRIC SHOCK in accordance with the instruction manual, may DO NOT OPEN cause harmful interference to radio communications.
  • Page 3 Refer servicing to qualified personnel only. European representative : Caution: The apparatus should not be exposed to LG Electronics Service Europe B.V. water (dripping or splashing) and no objects filled Veluwezoom 15, 1327 with liquids, such as vases, should be placed on the AE Almere.

  • Page 4: Important Safety Instructions

    Safety Information IMPORTANT SAFETY Unplug this apparatus during lightning storms or when unused for long periods of time. INSTRUCTIONS Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been Read these instructions.

  • Page 5: Please Follow The Directions Safely Use The Product

    Safety Information Please follow the • Do not disassemble or reconfigure the product. Because high level of current directions safely use flows on the device, it is dangerous to do the product It can cause a fire, an electric shock or an injury. • Always check for dangerous elements The purpose of the following safety precaution where the product is installed.
  • Page 6 Electronics. retailer to replace the hard drive. • Do not put heavy objects on top of the LG Electronics is not responsible for the product. data loss from misuse by the user. Any changes or modifications in • Be careful not to let alien particles get construction of this device which are not inside the product.
  • Page 7 When disposing the battery, follow the direction of the manufacturer. LG Electronics is not responsible for the problem from misuse by the user • Do not move or flip the product over while...

  • Page 8: Table Of Contents

    Before use Shutdown 2-1. Product characteristics 3-2. Monitor Screen 2-2. Components 3-3. System Setting System 2-3. Front side Camera LE6016D model Event LE6016N model Network Information 2-4. Rear side 3-4. PTZ Control 2-5. Remote Controller 3-5. Search (Playback) & How to set the id of remote...
  • Page 9 service Time search Event Search Backup 6-2. Recommended device to List of recommended USB memory Web viewer Recommended list of CD/ DVD media List of supported PTZ 4-1. Installation camera Web viewer installation 6-3. Initial setting list for factory default 4-2. Functional description 6-4.

  • Page 10: Before Use

    Before use Before use 2-1. Product characteristics • Adopted the stable Embedded Linux • Stable file system recovery even after power supply is disconnected from a power outage. • Realized small file size and high video quality by applying the H.264. • Supports terra byte hard disk (up to 1TB ) •...

  • Page 11: Components

    Supporting Daylight saving • Simultaneous output to VGA and BNC 2-2. Components Installation CD Owner’s Manual Power cable Mouse Remote control Adapter HDD power SATA cable Screws cable Reference: The type of components can be applied differently by the option. 2-3. Front side LE6016D model...

  • Page 12: Le6016N Model

    Before use LE6016N model There is no built-in DVD recorder at LE6016N model. DVD Recorder: This is used for DVD backup. • Hard disk LED: This is turned on HDD is accessed. • Power LED: This is turned on when the power is turned on. • Network LED: This is turned on when network is connected. •...

  • Page 13: Rear Side

    Before use 2-4. Rear side h i j Main output port: It is used to connect BNC type monitor. (It outputs the same video as MAIN output.) Camera video input: These are used to connect cameras. External HDD port: It is used to connect E-SATA HDD. Sensor/Alarm/RS-485 ports - These are used to connect sensor, alarm and RS-485 serial communication port.

  • Page 14: Remote Controller

    Before use 2-5. Remote Controller Function Description Power This is used to turn on/off the power. Emergency This is used to start/stop emergency recording recording. Number keys This is used to input channel or values. Plus(+) This is used to increase setting values. Minus(-) This is used to decrease setting values.

  • Page 15: Connection And Initial Setting

    Before use 2-6. Connection and initial setting Caution • The camera or other external devices can be connected to this device in numerous methods. Refer to the user manual of the camera or other external device for addition information on connection methods. • When installing the camera, check whether the power of the camera is turned off. • After installing the monitor, turn on the power of the DVR. Connect the BNC type monitor. (The same video output as VGA.) Connect the camera for coaxial connection. Connect the Connect the network cable. power adapter. Connect the BNC Connect USB type monitor.

  • Page 16: Control Port (Output) Connection

    Before use RS-485 connection ① This device has 1 data port (RS-485). ② Use this port to connect the PTZ camera or the keypad. (Optional) ③ PTZ camera / keyboard connection Connect the PTZ serial communication cable to the RS-485 port. ii.

  • Page 17: Sensor (Input) Connection

    Before use Sensor (Input) connection Sensor input 1 Connect one of the signal cables (2 cables) of various sensors (IR sensor, heat ray detector, magnetic etc.) to the Sensor input 2 COM port and connect the remaining signal cable to the Sensor input 3 sensor number you want.

  • Page 18: Hard Disk Installation Or Replacement

    Before use Be careful not to cause an impact from the tools and hard disk used for the installation. • Protect the hard disk from static electricity. CAUTION This device has elements to cause an electric shock, an accident or a problem to the product. Also the hard disk may not be recognized or operated properly due to incorrect installation and setting.
  • Page 19 11. After installing the hard disk, you must format the hard disk from the setting menu. <LE6016N> <LE6016D> The first SATA cable port on the main board must be connected at all times. If a hard disk is not connected, this device may not operate normally.
  • Page 20 Before use 3. After removing all of power/SATA cable connected to hard disk, please separate hard disk bracket from the body. 4. Loosen the screws on the left and right side of the bracket holding the hard disk. 5. Separate the hard disk from the bracket holding the hard disk. 6.
  • Page 21 Before use Database recovery of the HDD • The system has the check process of the database condition during the system booting. If there is some problem, the system will be displayed the confirmation window to recover the database. • Recovery time of the database is proportional to the amount of data.

  • Page 22: Functional Description

    Functional description Functional description 3-1. Operation Start Up 1. Turn on this device, then it boots with power indicator light turned on. 2. After booting it will be displayed as the LOGOUT id. 3. Pressing button, then the login window would be displayed. Select user and press “OK” button to continue.

  • Page 23: Shutdown

    Functional description [PASSWORD] The default user and password are set to ‘admin’ and ‘000000’ as shown above. Click password input area, you will see the screen keypad as right. 4. Input password by using virtual keypad on screen. 5. Click “OK” button to execute DVR system and you will see live screen. Shutdown 1.

  • Page 24: Monitor Screen

    Functional description 3-2. Monitor Screen [Camera name] • Shows camera name • If you want to modify camera name, you can do so by selecting [Setup] Ò [Camera]Ò [Channel] [Status icon] (OSD) • Status icon shows current status of camera/recording. • (OSD Feature) Item Icon Description...
  • Page 25 Functional description [Channel selection] • Selected channel shows green rectangle on the edge of the screen. [Live view] • It shows current live view as real time. [System control toolbar] d e h i j k l m n o p [Network status display] •...
  • Page 26 Functional description [Divided screen selection] • 1/4/9/13/16 divided screen can be displayed in live view. [Auto sequential] • Click button and each channel will be switched automatically. • This function does not work at 16 divided screen. • You can set the switching interval at [Setup] [System] [Overview] Ò...
  • Page 27 Functional description • You can see the log of previous date or next date by using button. • You can see the previous or next log list by using ( - ) / ( + ) button. • Click “OK” button to close window. •...

  • Page 28: System Setting

    Functional description 3-3. System Setting System setting can be configured by setup menu. Working condition can be specified by front button / mouse / remote controller. Only admin user can setup system configuration by menu. System [Overview] • You can specify the system configuration by this menu. •...
  • Page 29 Functional description REMOTE ID: ID can be selected from 00 to 99. DE-INTERLACE: Enable or disable de-interlace feature for playback screen. De-interlace feature is only available for ‘D1’ resolution. AUTO SWITCHING : Set dwell time when auto switching function is working. (1 Sec ~ 30 Sec) SPOT-DIVISION: Set the division mode for SPOU OUT screen.
  • Page 30 Functional description LOCALE : Specify locale of country. If you click button, the time zone dialog box will be shown as below, and select a time zone, then click OK to change setting. NTP SERVER : It is used to set internet time server. Daylight saving time is applied automatically according to corresponding ø...
  • Page 31 Functional description If you access as Admin account, previous password is not required. ø No authority setting is available for Admin account. ø Only camera authority is allowed for Logout account. ø Logout screen setting is applied as the same for Spot-Out. ø...
  • Page 32 If data is initialized, it can’t be recovered. Before use “initialize”, important data must be backup. • HDD Factory initialization makes format HDD and you will loose recorded data [Controller] • Connect keyboard controller to DVR system. • Setup configuration to access DVR with keyboard controller. (*Refer to controller user manual) Supported device : LKD1000 Dynamic Controller (LG) ø...

  • Page 33: Camera

    Functional description Camera On the camera menu, channel, recording, schedule, color and PTZ can be configured. [Channel] • You can specify channel name and audio for each camera. CAMERA : Select camera to change CHANNEL NAME : Input channel name (Max 8 digits) AUDIO : Specify channel that audio is related.
  • Page 34 Functional description [Recording] • You can specify recording configuration. TOTAL FRAME : Max frame rate has restricted by screen resolution. CAMERA : Select camera to set frame and quality. RESOLUTION : Specify screen resolution. (CIF / HALF D1 / D1 ) FRAME : You can specify recording frame rate when recording method is continuous for selected camera.
  • Page 35 Functional description [Schedule] • You can specify recording method by schedule with date and time. Click time table to change recoding method. Click channel number to change recording method for all time. Click time label to change recording method for all channel. Click “COPY”...
  • Page 36 CAMERA : select camera to setup PTZ. DEVICE NAME : Select camera name.(Max 15 cameras supported) 1. LG Multix_E / LG Co.,Ltd 2. LG Multix / LG Co.,Ltd 3. LPT - A100L / LG Co.,Ltd 4. LVC-C100 / C200HM / LG Electric Inc...
  • Page 37 Functional description 5. HSDN251 / Honeywell Co.,Ltd 6. MD200 / 2000 / 1200 / 800 / Sony Co.,Ltd 7. New Born / NEW BORN HIGHTECH 8. WVCS850 / Panasonic 9. PELCO-D / PELCO Co.,Ltd 10. PELCO-P / PELCO Co.,Ltd SAMSUNG_E / SAMSUNG Co.,Ltd 12.

  • Page 38: Event

    Functional description Event You can specify the processing when event occurs like sensor, motion detection, video loss, and the email notification settings when event occurs. [Sensor] • You can specify the processing when event occurs from input device. SENSOR : Selecting sensor number. ( 1 ~ 8 ) TYPE : Setting NO / NC type.
  • Page 39 Functional description CHANNEL : Selecting associated channel with the sensor input. (OFF/1~16) ALARM : Setting alarm out when event occurs from input device.(OFF/1~4) ALERT : Setting sound a buzzer when event occurs from input device. (ON/OFF) SPOT-OUT : Setting spot out when event occurs from input device.(ON/OFF) DURATION : Setting the duration time from event occurs.
  • Page 40 Functional description > SELECT ALL : Selecting entire area. > UNSELECT ALL : Unselecting entire area. > SAVE : Saving selected area as a motion detection zone. > EXIT : Exiting motion zone setting. SENSITIVITY : Setting the motion sensitivity. (1 to 10) ALARM : Setting alarm out when motion is detected.
  • Page 41 Functional description ALERT : Setting sound a buzzer when video loss. (ON/OFF) DURATION : Setting duration time from video loss. (OFF/1~10 Sec.) [E-mail] • You can set the E-mail notification when event occurs. MODE : Enabling or disabling E-mail notification. (OFF / Authentication / Not authentication) SMTP SERVER : Setting the IP address or domain name of SMTP server.

  • Page 42: Network

    Functional description Network You can set the network environments. [TCP/IP] • You can specify the TCP/IP setting according to network environment. • Specifying the TCP port number of Web, Playback and Live. • Default values: Web(80), Playback(9091), Live(9092) For dynamic IP or PPPoE •...
  • Page 43 DNS : Enter the DNS IP address received from ISP using screen keyboard. MAC ADDRESS : This is hardware specific unique address of network device, so user cannot set this value. 8000~65535 port number is recommended. ø Do not use the same port number with each other. ø web(80),playback(9091),live(9092),CMS LG(9100) If the network of DVR is connected via router, you must set Configuration of port ø forwarding according to the router. (web, search, live ports) Please refer to user’s guide of the router which you are using. [Streaming] •...
  • Page 44 • You can use DDNS service provided by LG. • You can connect to DVR easily using host name instead of IP address with LG DDNS MODE : Enabling or disabling DDNS. SERVER : IP address of DDNS. PORT : TCP port number of DDNS.
  • Page 45 PORT : The TCP port number of the central monitoring center. 8000~65535 port number is recommended. ø Do not use the same port number with each other. ø web(80), playback(9091), live(9092), CMS LG(9100) [Event filter] • Specifying the event which will be sent to the central monitoring center and E-mail. SYSTEM START : Enabling or disabling the system start event.

  • Page 46: Information

    Functional description Information You can view the general system information and run software update. [System information] • You can view the system information. MODEL : Model name of the device. IP ADDRESS : The IP address assigned to the device. MAC ADDRESS : The MAC address assigned to the device.
  • Page 47 Functional description VIDEO TYPE : Showing NTSC or PAL. This is set automatically by detecting incoming video signal, so user cannot change this value. HDD: HDD capacity, using ratio and status. * mark is shown at the HDD which is currently recording. “NOT HEALTHY”...
  • Page 48 Functional description [Setting update] IMPORT: You can replace current setting values with new values from USB memory. (ENABLE/DISABLE) EXPORT: You can export current setting values to USB memory. (ENABLE/DISABLE) NOTE USB memory stick is needed to update F/W or settings. It takes about 5 seconds to recognize USB memory device after connected.

  • Page 49: Ptz Control

    Functional description 3-4. PTZ Control It is used to control PTZ camera which is connected at RS-485 port. Settings of camera and DVR should be done if you are to control PTZ camera. 1. Click the icon to control PTZ. 2. Control the PTZ camera using each item below. Click to move the PTZ control window.
  • Page 50 Functional description Click to control the focus of camera manually. Click to control the iris of camera manually. Click to select preset number. Click to move to selected preset position. Click to set current position as a new preset position. Click to delete specified preset number.

  • Page 51: Search (Playback) & Backup

    Functional description NOTE • The tour which is working will be stop after the setting is changed. • If you control the Camera OSD by using the SAMSUNG E protocol to select the exit(X) menu, the DVR may not opreate normally. In this case, you can recover the system as input the Zoom +/- key after input O key of the OSD.
  • Page 52 Functional description Click the “CANCEL” button to select date again. ø You can select a data if data are duplicated at the same time stamp using spin ø box below. The spin box is shown only when data are duplicated at the same time stamp, which is caused when daylight saving period. Bigger number of duplicated data stands for more recent data. ø Event Search You can search recorded data using event occurrence time. A. Click mouse on the icon of the menu bar which is located in the lower position of the search mode screen. B.
  • Page 53 Functional description E. Select a data to search from the list. Click the mouse button to move to the corresponding recorded data. F. Click “PLAY” button and the searched data will be played. Bookmark You can access the bookmarked time directly without going through the search. 1.
  • Page 54 B. Select a device to backup data will be stored. Only USB-STICK is available for LE6016N. USB-STICK, CD-RW, or DVD-RW can be used for LE6016D. C. Select media type. If you select FILESYSTEM, backup data will be stored as native format with backup player.
  • Page 55 Functional description L. The message “BACKUP STOP” will be shown when backup is finished. • You can backup automatically daily based by schedule backup. A. If you are to use schedule backup, set “USE SCHEDULE” to “ON”. B. Enter the time to execute backup at “BACKUP TIME”. If USB memory stick is not connected nor has no free space, backup cannot be executed.
  • Page 56 Functional description How to cancel backup If you press button when backup is running, the selection message will be Ä shown as below. Click “OK” button to cancel backup. Ä MEDIA ERASE You can erase data in the storage media, like USB memory stick, CD-RW or DVD-RW. Ä...
  • Page 57 Functional description Bigger number of duplicated data stands for more recent data. ø NOTE Do not remove the external USB device when backup is running. • Backup data playback The backup data in USB storage or CD/DVD media can be played at PC. <Selecting backup folder in USB storage> <Selecting CD/DVD drive >...
  • Page 58 Set up the network before the installation. Web viewer installation 1. Enter the LG DVR IP address in the Web address window, and then the following Active X installation window will be displayed. 2. When you click on the Active X install button, the following window will be displayed. Press the...
  • Page 59 Web initialization screen will be displayed. (General installation recommended) 4. Enter the ID and password. (Multi-login is not enabled for admin user ID.) (Default: admin, user1, user2, user3) NOTE Web Viewer and CMS LG cannot be used at the same time.
  • Page 60 Web viewer 4-2. Functional description Web viewer monitoring window Divide screen division (Full screen/1/4/9/16) Selecting a camera Real time image capture (Save as JPEG) Settings (It is available only when you logged in as admin) Enable or disable incoming audio (Default value is disable.) Zoom control Iris control Focus control Preset (Click “Go”...
  • Page 61 Web viewer Web viewer search window Divide screen division (Full screen/1/4/9/16) Selecting a camera Saving video or still image (Saving as AVI/JPEG/BMP) Date/Time selection button to play back (Refer to “Search dialog box”) Enable or disable incoming audio (Default value is disabled.) Pause button Forward play button Backward play button (Displaying only key-frame) Fast forward play button...
  • Page 62 Web viewer Search dialog box Recorded data graph (Click on the data graph to select time to play.) Time scroll bar Zoon in/out of graph (It can be scaled from 2 hours to 24 hours by minute unit.) Displaying selected data/time Displaying calendar (The dates are shown in bold if recorded data exist.) Description of the color of the recorded data graph “OK”...
  • Page 63 Web viewer Saving as AVI file dialog box Camera name/Date/Time which is currently displayed. Starting AVI saving (File name is requested when you click on this button.) Stopping AVI saving Closing Save as AVI dialog box (It will be closed automatically after stopping AVI file if it is being saved.) Specifying time period to save AVI file.
  • Page 64 If you can use Wi-Fi environments, you can view the real-time monitoring video from DVR with iPhone/iPod. 1. Run web browser at iPhone/iPod, and enter LG DVR IP address. 2. Enter id and password, and click “login” button the real-time monitoring screen will be shown.
  • Page 65 Apple iPhone/iPod 3. Real-time monitoring screen. Camera selection (CH1~16) Video screen...
  • Page 66 Reference Reference 6-1. Check before requesting for service If the following symptoms are observed when using the product, recheck the following. It may not be a problem. Symptom Checkpoint and resolution Check whether the power plug is correctly plugged. Check whether the voltage of the power supply is correct. I cannot turn on the power of the device If the power cannot be turned even when the power of the...
  • Page 67 Reference Symptom Checkpoint and resolution Check the recording setting from the recording setting menu. Check whether the hard disk is recognized from the system Video of camera is displayed information window. on the screen but I cannot record the video through the If the hard disk is not recognized normally, check the format and device connected condition of the hard disk.
  • Page 68 Reference Symptom Checkpoint and resolution If there is an issue with the camera connected to the system, connect a different camera to the video input port to check whether the existing camera connected to the system has an issue. Check whether the video cable connecting the device and the camera is damaged.
  • Page 69 Reference Symptom Checkpoint and resolution When the E-mail transmission fails without SMTP server setting. • Check whether the network is set up correctly. • Check whether the E-mail address is entered correctly. • Check the spam mail setting for the entered E-mail address. (If the spam mail is set, some mails may automatically be deleted or classified into spam mail box etc.) •...
  • Page 70 Reference 6-2. Recommended device to use List of recommended USB memory Classification Manufacturer Model name Capacity ELECOM MF-BU201GWH BUFFALO RUF2-E1GL-BL Cruzer Micro Scandisk Cruzer Micro U3 8/16GB USM1GJX SONY USM8GH PRINCETON PFU-STS1G DATA TB-ST1GB I-O FM Semiconductor MLC gold SUM-M4GPV SAMSUNG SUM-LWW Transcend JetFlash V10 IMATION Atom USB Drive MLC Sky Digital SKY-DRVx2 XTICK...
  • Page 71 Reference Recommended list of CD/DVD media Manufacturer CD-R CD-RW DVD+R DVD-R DVD+RW DVD-RW Samsung Pleomax Melody Sony MITSUBISHI Verbatim Memorex NOTE Dual layer and mini CD/DVD is not supported in the recommended list of CD/DVD media.
  • Page 72 SAMSUNG_E / SAMSUNG SAMSUNG Co.,Ltd SPD - 2300/3000/3300/ SAMSUNG SAMSUNG Co.,Ltd SUNGJIN / SUNGJIN SUNGJIN Co.,Ltd TPD7720 / DYNACOLOR, DYNACOLOR V1305R-DC / V1311RB/ VICON CRX-1013 / VICON NOTE LE6016N/LE6016D is not compatible with KVM because of exclusive use of mouse.
  • Page 73 Reference 6-3. Initial setting list for factory default 1 Step 2 Step 3 Step 4 Step INPUT Default SYSTEM REMOTE ID 00~99 DE-INTERLACE ON / OFF AUTO-SWITCHING 1~30 Sec 10 Sec SPOT- 1 / 4 / 16 DIVISION SPOT-OUT AUTO/1~16 OVERVIEW BUTTON BUZZER ON/OFF LANGUAGE ENGLISH OVERWRITE ON / OFF USE DATA RETAIN ON/OFF RETAIN DAY...
  • Page 74 Reference admin/user1/user2/ SELECTION admin user3 CONFIRM CAMERA SET 1~16 1~16 PASSWORD SETUP SEARCH / BACKUP AUTO LOGOUT Off, 5 Min to 60 Min FACTORY ON/OFF ON/OFF INITIALIZE SETTING ON/OFF ON/OFF ON/OFF CONTROLLER DEVICE ID 1~16 BAUD RATE 1200~115200 9600 CAMERA CAMERA 1~16 CHANNEL NAME...
  • Page 75 Reference CAMERA 1~16 CIF/ RESOLUTION HALF D1/ FRAME 1~30 RECORDING OFF / 1 / 5 / 7.5 / 10 / EVENT FRAME 15 / 30 VERY LOW QUALITY NORMAL NORMAL HIGH VERY HIGH CAMERA 1~16 C/H/E/N SCHEDULE COPY HOLIDAY CAMERA 1~16 BRIGHTNESS 0~100...
  • Page 76 Reference CAMERA 1~16 LG-Multix_E LG-Multix LPT-A100L LVC-C100 HSDN251 MD200 New Born WVCS850 DEVICE NAME PELCO-D PELCO-P SAMSUNG_E SPD-2300 SUNGJIN TPD7720 V1305R-DC DEVICE ID BAUD RATE 1200~115200 9600 5 Sec 10 Sec 20 Sec TOURING 30 Sec 1Min INTERVAL 1 Min...
  • Page 77 Reference CHANNEL 1~16 MOTION ZONE SELECT ALL SENSITIVITY 1 ~ 10 MOTION ALARM 1~4/OFF ALERT ON/OFF SPOT-OUT ON/OFF DURATION 1~10 Sec./OFF 10 Sec. CHANNEL 1~16 ALARM 1~4/OFF VIDEO LOSS ALERT ON/OFF DURATION 1~10 Sec./OFF 10 Sec. MODE ON/OFF SMPT SERVER PORT ACCOUNT E-MAIL...
  • Page 78 Reference NETWORK DHCP IP CONFIG STATIC IP DHCP IP PPPoE IP ADDRESS SUBNET MASK GATEWAY TCP / IP MAC ADDRESS STATUS DISCONNECT PPPoE USER PASSWORD PLAYBACK 9091 LIVE 9092 CAMERA 1~16 OFF / 1 / 5 / FRAME STREAMING VERY LOW QUALITY NORMAL NORMAL...
  • Page 79 Reference SYSTEM START ON/OFF SHUTDOWN ON/OFF SETTING CHANGE ON/OFF LOGIN/ ON/OFF LOGOUT EVENT FILTER SENSOR ON/OFF DETECTION MOTION ON/OFF DETECTION VIDEO LOSS ON/OFF ALARM OUTPUT ON/OFF INFO MODEL IP ADDRESS MAC ADDRESS F/W VERSION INFORMATION OS VERSION VIDEO TYPE INTERNAL HDD EXTERNAL HDD SYSTEM LOG F / W UPDATE...
  • Page 80 Reference 6-4. Product specification MODEL LE6016N LE6016D OPERATING SYSTEM Embedded Linux COMPRESSION H.264 Hardware Codec MULTIPLEX FUNCTION Live, Record, Backup and Network at the same time RECORDING RESOLUTION D1, Half D1, CIF RECORDING SPEED 480 fps (NTSC), 400 fps (PAL) at CIF Resolution VIDEO INPUT 16 BNC Composite...
