Specifi cations - V554
Product Specifi cations
LCD Module
Frequency
Pixel Clock
Viewable Size
Input Signal
DVI
DVI-D 24pin
DisplayPort DisplayPort Connector Digital RGB
VGA
15pin Mini D-sub
4
(RGB)*
HDMI
HDMI Connector
VGA
15pin Mini D-sub
4
(YPbPr)*
VIDEO*
4
RCA port
Output Signal
DisplayPort DisplayPort Connector Digital RGB
AUDIO
AUDIO
Stereo Mini Jack
Input
HDMI Connector
DisplayPort Connector Digital Audio
AUDIO
Stereo Mini Jack
Output
Speaker Output
Control
SD card Hub
USB Hub
Power Supply
Power Consumption
Operational Environment
Storage Environment
Dimension
Weight
VESA compatible mounting interface
Power Management
Plug & Play
Power supply for Slot 2 type OPTION
NOTE: Technical specifi cations are subject to change without notice.
55"/138.78 cm diagonal
Pixel Pitch:
0.630 mm
Resolution:
1920 x 1080
Color:
Over 1073 million colors (depending on display card used)
Brightness:
500 cd/m
2
(Max.) @25°C
Contrast Ratio:
1200:1
Viewing Angle:
89° (typ) @ CR>10
Horizontal:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
Vertical:
50.0 - 85.0 Hz (Analog Input)
24.0 - 85.0 Hz (Digital Input)
Analog: 13.5 MHz, 25.0 MHz - 195.0 MHz
Digital: 25.0 MHz - 165.0 MHz (DVI), 25.0 MHz - 600.0 MHz (HDMI/DisplayPort)
1209.6 x 680.4 mm
Digital RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
The DisplayPort input complies with Standard V1.2, applicable to HDCP
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 3840x2160 (24Hz/30Hz/60Hz
(DisplayPort1.2))*
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
Digital YUV
HDMI
Digital RGB
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz,
3840x2160 (30Hz/24Hz/25Hz/60Hz (MODE2))*
Component
Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
Composite
1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
DisplayPort complies with Standard V1.2, applicable to HDCP
Analog Audio
Stereo L/R 0.5 Vrms
Digital Audio
PCM 32, 44.1, 48 KHz (16/20/24bit)
PCM 32, 44.1, 48 KHz (16/20/24bit)
Analog Audio
Stereo L/R 0.5 Vrms
External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W (Stereo)
RS-232C In:
9 Pin D-sub
LAN:
RJ-45 10 BASE-T/100 BASE-TX x 2
Stereo Mini Jack 3.5 mm Ø
Remote IN:
Port: microSD card. Up to 32GB microSDHC is supported.
USB1:
USB 2.0 Downstream port
USB2:
USB 2.0 Upstream port
USB CM1 (2A):
Power supply port, 5V/2A
USB CM2:
USB service port for maintenance
USB MP:
Media Player/Firmware update port
3.3 - 1.4 A @ 100-240V AC, 50/60Hz
Normal operation: Approx. 110 W
Temperature*
2
:
0 - 40°C / 32 - 104°F, 0 - 35°C / 32 - 95°F (Slot 2 type PC with Face up position or with Face
down position)
Humidity:
20 - 80% (without condensation)
Altitude:
0 - 3000 m (Brightness may decrease with altitude)
Temperature:
-20 - 60°C / -4 - 140°F
Humidity:
10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
1244 (W) x 714.8 (H) x 62.9 (D) mm/49 (W) x 28.1 (H) x 2.5 (D) inches (w/o Deco Dimension)
24.6 kg (54.2 lbs)
300 mm x 300 mm (M6, 4 Holes)
VESA DPM
VESA DDC2Bi, DDC/CI, DisplayPort
16V/3.6 A
*2: When you use option board accessories, please contact your supplier for detailed information.
English-70
1,
4
*
1,
4
*
1
, 1920X1080 (60Hz), 1080p, 1080i
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1
1
, WUXGA60*
, 1920X1080 (60Hz)
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1,
4
, 4096x2160 (24Hz)*
*
*1: Compressed image.
*3: Reproduced text may look blurred.
*4: Common terminal.
