WINDOW AIR CONDITIONER
Operator's manual
Customer Service / Service à la clientèle:
Our customer service staff is available to help you. For any problem with your purchase, or to receive further
information about this product, please call our toll-free number.
SAVE THIS MANUAL
Keep this manual and the original sales invoice in a safe, dry place for future reference.
Notre personnel du service à la clientèle est disponible pour vous aider. En cas de problème avec votre achat, ou pour
obtenir plus d'informations à propos de ce produit, veuillez composer notre numéro sans frais.
CONSERVEZ CE GUIDE
Conservez ce manuel avec la facture d'origine dans un endroit sûr et sec pour référence future.
Model/Modèle :
87795062
MWFUK-06CRN1-BCL1
87795059
MWFUK-08CRN1-BCL0
87795060
MWEUK-10CRN1-BCL0
15625013
MWEUK-12CRN1-BCL0
1-866-206-0888
Advertisement
Related Manuals for Arctic King 87795062
Summary of Contents for Arctic King 87795062
- Page 1 Model/Modèle : 87795062 MWFUK-06CRN1-BCL1 87795059 MWFUK-08CRN1-BCL0 87795060 MWEUK-10CRN1-BCL0 15625013 MWEUK-12CRN1-BCL0 WINDOW AIR CONDITIONER Operator's manual Customer Service / Service à la clientèle: 1-866-206-0888 Our customer service staff is available to help you. For any problem with your purchase, or to receive further information about this product, please call our toll-free number.
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions Installation Instructions Normal Sounds Air Conditioner Features Care and Cleaning Troubleshooting Tips Remote Controller Instructions Air Conditioner Limited Warranty... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ THIS MANUAL Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your air conditioner. You'll find many answers to common problems in the chart of troubleshooting tips. - Page 4 IMPORTANT SAFETY INSTRUCTIONS CAUTION When the air filter is to be Do not put a pet or house plant Ventilate the room well when removed, do not touch the metal where it will be exposed to direct used together with a stove, etc. air flow.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING NOTE: The power supply cord with this air For Your Safety Do not store or use gasoline or other flammable vapours or liquids in the vicinity conditioner contains a current detection of this or any other appliance. device designed to reduce the risk of fire.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS CAUTION BEFORE YOU BEGIN Do not, under any circumstances, cut or Read these instructions completely remove the third (ground) prong from the and carefully. power cord. IMPORT ANT - Save these Do not change the plug on the power cord instructions for local inspector s use. - Page 7 INSTALLATION INSTRUCTIONS C: Align the hole in the top rail with those in the top PREPARE THE WINDOW of the unit as shown in Fig. B Lower sash must open sufficiently to allow a clear Fig. B vertical opening (H). See Table 1 for correct size. Side louvers and the rear of the AC must have clear air space to allow enough airflow through the condenser for heat removal.
- Page 8 INSTALLATION INSTRUCTIONS B. Slide the free end "Ⅰ" section of the panel directly SECURE THE ACCORDION PANELS into the cabinet as shown in Fig. 2. Slide the panel A. Keeping a firm grip on the air conditioner, carefully down. Be sure to leave enough space to slip the top and bottom of the frame into the rails on the place the unit into the window opening so the bottom cabinet.
- Page 9 INSTALLATION INSTRUCTIONS B. Drive 3/4 or 1/2" (19 or 12.7 mm) locking screws through frame holes into window sash (Fig.8). Fig.8 C. To secure lower sash in place, attach right angle sash lock with 3/4 or 1/2" (19 or 12.7 mm) screw as shown (Fig.9).
- Page 10 INSTALLATION INSTRUCTIONS INSTALL WEATHER STRIPPING (only If AC is Blocked by Stor m Window be applicable to ENERGY STAR models ) Add wood as shown in Fig.11, or remove storm In order to minimize air leaks between the room air window before air conditioner is installed.
-
Page 11: Normal Sounds
NORMAL SOUNDS AIR CONDITIONER FEATURES High Pitched Chatter High efficiency compressors may have a high pitched chatter Vibration during the cooling cycle. Unit may vibrate and make noise because of poor wall or window construction or incorrect installation. Sound of Rushing Air At the front of the unit you may hear the sound of rushing air being moved by the fan. - Page 12 AIR CONDITIONER FEATURES TO SELECT THE OPERATING MODE: TO ADJUST FAN SPEEDS: Press to select the fan speed in four steps: Auto, To choose operating mode, press Mode button. Each Low, Med or High. Each time the button is pressed, time you press the button, a mode is selected in a the fan speed mode is shifted.
-
Page 13: Care And Cleaning
AIR CONDITIONER FEATURES CARE AND CLEANING ADDITIONAL THINGS YOU SHOULD KNOW DISPLAYS: Displays Now that you have mastered the operating procedure, here are more features in your control that you should become familiar with. The Cool circuit has an automatic 3 minute time- delay start if the unit is turned off and on quickly. -
Page 14: Troubleshooting Tips
CARE AND CLEANING TROUBLESHOOTING TIPS Air Filter Cleaning Cabinet Cleaning Push the vent handle to the vent closed position Be sure to unplug the air conditioner to prevent shock or fire hazard. The cabinet and front may be dusted with an oil-free (where applicable). - Page 15 TROUBLESHOOTING TIPS Problem Solution Dirty air filter-- air restricted. Clean air filter. Refer to Care and Cleaning section. Air conditioner cooling, but room Temperature is set too high. Set temperature to a lowercase setting. is too warm-- NO Air directional louvers positioned improperly. Position louvers for better air distribution. ice forming on cooling coil behind Front of units is blocked by drapes, blinds, furniture, etc.
-
Page 16: Remote Controller Instructions
Remote Controller Instructions Handling the remote controller Location of the remote controller. Use the remote controller within a distance of 16 feet (5 m) from the appliance, pointing it towards the receiver. Reception is confirmed by a beep. CAUTIONS The air conditioner will not operate if curtains, doors or other materials block the signals from the remote controller to the indoor unit. - Page 17 Remote Controller Instructions WARNING 1. Battery must be disposed of properly. Do not short circuit or dispose of in the fire. 2. Keep batteries out of the reach of children. 3. Batteries must not be ingested. 4. Non-rechargeable batteries are not to be recharged. 5.
- Page 18 Remote Controller Instructions NOTE: Function buttons MODE button Press this button to select the ON/OFF button desired operation mode from AUTO, COOL, DRY, HEAT Operation starts when this button (Cooling & heating models is pressed and stops when the button is pressed again. only) and FAN.
- Page 19 Remote Controller Instructions add space automatically between modes cannot...
- Page 20 Remote Controller Instructions add space cannot...
- Page 21 Remote Controller Instructions...
- Page 22 Remote Controller Instructions...
- Page 23 Remote Controller Instructions starts.
- Page 24 Remote Controller Instructions All functions described in these instructions apply to the different models available; if your model doesn't have a specific function, pressing the corresponding button will have no effect.
-
Page 25: Air Conditioner Limited Warranty
Air Conditioner Limited Warranty These products have been made to quality standards and are guaranteed for domestic use against manufacturing faults for a period of 5 years from the date of purchase. One (1) year full warranty from original purchase date and limited 2nd through 5th year sealed system warranty if used for normal trade purposes.
