Application Guidelines

Nomenclature

Family, lubricant
& refrigerant
SH: Scroll, POE lubricant,
for R410A
Nominal capacity
in thousand Btu/h at 60 Hz, R410A,
ARI conditions
UL index
Motor voltage code
3: 200-230V/3~/60 Hz
4: 380-400V/3~/50 Hz - 460V/3~/60 Hz
for SH295 & SH485: 380-415V/3~/50Hz - 460V/3~/60Hz
6: 230V/3~/50 Hz
7: 500V/3~/50 Hz - 575V/3~/60 Hz
9: 380V/3~/60 Hz
6
AB243586442172en-001401

Compressor model designation

Danfoss SH scroll compressors for R410A are
available as single compressors. The example
below presents the compressor nomenclature
which equals the technical reference as shown on
the compressor nameplate.
Family, Nominal Approvals
lubricant capacity
& refrigerant
SH 295 A
Code numbers for ordering are listed section
"Ordering information and packaging".
For tandem and trio assemblies, please refer
to the Danfoss SH scroll compressor Parallel
Application Guidelines, FRCC.PC.008.
Voltage Version Evolution
index
4 AB A
Evolution index
Motor protection
L: Internal overload protector
A: Electronic, 24V AC
B: Electronic, 110-240V
C: Customized electrical box
Suction and discharge connections
A: Brazed connections
A~Z
