OAP7250AG
Wireless 450M + 1.3Gbps Long Range outdoor Dual Band Concurrent
AP
Please verify contents of the box before continuing to set up the OAP7250AG.
OAP7250AG Access Point
OAP7250AG Quick Start Guide
Mounting Bracket
PoE injector
Mounting Kit Package (includes hex cap screws, washers, wall anchors and bolts, ring clamp)
Ground Cables
Packaged Ground Screw
Power Adapter
Pole Mounting Bracket
7dBi 5GHz Omni-directional antennas
5dBi 2.4GHz Omni-directional antennas
Connect to the OAP7250AG Access Point
1. Attach and gently tighten the provided antennas to the appropriate port on the OAP7250AG
2. Attach one of the supplied Ground Cables to the Ground screw on the PoE injector.
3. Attach the wire end the Ground Cable to a safety ground.
4. Using one of the CAT5e/CAT6 Ethernet cable, connect one end of the cable to the LAN1 Port (PoE
Input) of the CAP7250AG and the other end into the AP/Bridge port on the PoE injector.
5. Connect the second CAT5e/CAT6 Ethernet cable to the Switch/Computer Ethernet port.
6. Connect the Power adapter to the DC IN port of the PoE injector and plug the other end into an
electrical outlet.
Quick Installation Guide
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SENAO OAP7250AG
Summary of Contents for SENAO OAP7250AG
- Page 1 5dBi 2.4GHz Omni-directional antennas Connect to the OAP7250AG Access Point 1. Attach and gently tighten the provided antennas to the appropriate port on the OAP7250AG 2. Attach one of the supplied Ground Cables to the Ground screw on the PoE injector.
-
Page 2: Ip Address Configuration
Note: The OAP7250AG can be powered through the LAN1 Port (PoE Input) by any PSE (Power Sourcing Equipment) which supports IEEE802.11at (PoE+) including the provided PoE injector. With adequate input power, the OAP7250AG can power a device connected to the LAN2 Port (PSE Output). - Page 3 (Example 192.168.1.10 and the Subnet Mask as 255.255.255.0) Access the OAP7250AG 1. To configure the OAP7250AG, open a web browser and enter 192.168.1.1 in the address bar. Then hit enter. 2. A login screen will appear. The default username and password of the OAP7250AG is admin. Please...
- Page 4 Wall Mounting the OAP7250AG 1. Make the four locations of the mounting holes on the flat mounting surface. 2. Drill a 37mm deep 8mm hole in the markings and hammer the bolts into the openings. 3. Place the lock and flat washers on the four hex cap screws and drive the screws to attach the bracket...
- Page 5 4. Tighten the flat washers to secure the bracket to the mounting surface. Pole Mounting the OAP7250AG 1. Place the lock and flat washers on the four hex cap screws and drive the screws to attach bracket to the back of the OAP7250AG...
- Page 6 2. Drive the four round head screws to attach the Pole Mount Bracket to the bracket. 3. Thread the open end of the Pole Strap through the two tabs on the Pole Mount Bracket.
- Page 7 4. Lock and tighten Pole Strap to secure Pole Mount Bracket to the Pole.
-
Page 8: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 9: Professional Installation Instruction
Professional installation instruction 1. Installation personal This product is designed for specific application and needs to be installed by a qualified personal who has RF and related rule knowledge. The general user shall not attempt to install or change the setting. 2.
