Brother VM5200 Operation Manual page 281

CAUTION
• When sewing bobbin work, be sure to select an
embroidery pattern for bobbin work. If any other
type of pattern is selected, the machine may be
damaged.
Note
• Bobbin work embroidery sewing speed
defaults to 100 spm when a bobbin work
embroidery pattern is selected. The
Settings screen will only allow speed to be
adjusted from 100 spm to a maximum
sewing speed of 350 spm.
Memo
• When an embroidery pattern for bobbin
work is selected, the automatic thread
cutting function is turned off. Afterward, if a
pattern other than one for bobbin work is
selected, the automatic thread cutting
function is returned to the setting that was
selected before the embroidery pattern for
bobbin work was chosen.
h
Press .
 The sewing screen is displayed.
CREATING BOBBIN WORK (EMBROIDERY)
Note
• Since bobbin work is sewn from the wrong
side of the fabric, the pattern shown in the
screen appears as a mirror image of the
final sewn embroidery. If necessary, flip the
image to preview it. In addition, when
sewing with the thread colors shown in the
embroidery screen, select a bobbin thread
that matches what is shown in the screen.
a Image shown in screen
Memo
• With embroidery patterns for bobbin work,
the size and thread density cannot be
changed. In addition, the automatic thread
cutting function cannot be turned on.
i
Press , and then adjust the tension of
the upper thread.
For details on adjusting the tension of the upper
thread, refer to "Adjusting Thread Tension" on
page E-30.
Memo
• We recommend a setting between 6 and 8
for the upper thread tension.
b Sewn embroidery
(Right side of fabric)
Appendix A-13
A
1
