Saramonic SR-TM7 Quick Start Manual

DIRECTIONAL
CONDENSER MICROPHONE
The Saramonic SR-TM7 is a directional shotgun microphone features a
super- cardioid polar pattern, built-in rechargeable battery, 75Hz/150 Hz
low cut switch, +6 dB high frequency boost, -10 db PAD and power button.
SR-TM7
1 Introduction
Saramonic SR-TM7 is a directional shotgun microphone features a super-cardioid
polar pattern, built-in rechargeable battery, 75 Hz/150 Hz low cut switch, +6 dB
high frequency boost, -10 db PAD and power button.
SR-TM7 is very fit in several environments for applications such as DSLR
video making, ENG, filmmaking, field recording, sound design, and broadcast
applications.
2 Product Structure
3 Power Supply
The TM7 can be powered via
• The built-in Lithium Battery; OR
• 48V phantom power, which is supplied by your camera or recording
devices (such as Saramonic SR-PAX2, SR-AX104, SR-AX107.) When phantom
power is applied, the built-in battery will not be used, or charged.
Power
Power button
75 Hz high pass filter button.
150 Hz high pass filter button
+6 dB high frequency boost
-10 db PAD
Power button
Built-in Li-ion battery
Foam windshield
XLR output
Micro USB input
Mic clip
MicroUSB cable
by built-in battery by 48v phantom power
Blue light Green light
low power
Red light
