Saramonic SR-TM1 User Manual

Directional condenser microphone

Advertisement

Quick Links

DIRECTIONAL
CONDENSER MICROPHONE
The Saramonic SR-TM1 is a directional shotgun microphone features
a cardioid polar pattern, built-in rechargeable battery, 150 Hz low cut
switch, +6 dB high frequency boost, -10 db PAD and power button.
SR-TM1
1 Introduction
The Saramonic SR-TM1 is a directional shotgun microphone features a cardioid
polar pattern, built-in rechargeable battery, 150 Hz low cut switch, +6 dB high
frequency boost, -10 db PAD and power button.
The SR-TM1 is very fit in several environments for applications such as DSLR
video making, ENG, filmmaking, field recording, sound design, and broadcast
applications.
2 Product Structure
150 Hz high pass filter button
+6 dB high frequency boost
-10 db PAD
Power button
Built-in Li-ion battery
3 Power Supply
The TM1 can be powered via
• The built-in Lithium Battery; OR
• 48V phantom power, which is supplied by your camera or recording
devices (such as Saramonic SR-PAX2, SR-AX104, SR-AX107.) When phantom
power is applied, the built-in battery will not be used, or charged.
Power
Power Indicator
Micro USB input
XLR output
Foam windshield
Mic clip
MicroUSB cable
by Built-In Battery
by 48V Phantom Power
Blue Light
Green Light
Low Power
Red Light

Advertisement

loading
Need help?

Need help?

Do you have a question about the SR-TM1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Saramonic SR-TM1

  • Page 1 150 Hz low cut switch, +6 dB high frequency boost, -10 db PAD and power button. The SR-TM1 is very fit in several environments for applications such as DSLR video making, ENG, filmmaking, field recording, sound design, and broadcast applications.
  • Page 2 5 buttons will flash blue in cycles. When the SR-TM1 has been fully charged, the 5 buttons will stay blue. Pull out the cable and long press the power button to restart , now the SR-TM1 is ready to use.
