Motic Moticam S2 Assembly

Moticam S2

Thank you for purchasing our Moticam S2 solution.

This quick step guide will show you how to place the Moticam S2 onto

a C-mount microscope.

Moticam S2

C-Mount adapter

Note:

Please note that the Moticam S2 is a C-mount camera, therefore you

must have a trinocular microscope with a relevant C-Mount adapter

between 0.5X and 0.65X magnification.

Protective

dust cover

Step 1:

Unscrew the protective dust cover from the

bottom of the Moticam S2 to expose the imaging

sensor to light.

Assembly

Trinocular Microscope

Table of Contents

Do you have a question about the Moticam S2 and is the answer not in the manual?

Page 1 Moticam S2 Assembly Thank you for purchasing our Moticam S2 solution. This quick step guide will show you how to place the Moticam S2 onto a C-mount microscope. Moticam S2 C-Mount adapter Trinocular Microscope Note: Please note that the Moticam S2 is a C-mount camera, therefore you must have a trinocular microscope with a relevant C-Mount adapter between 0.5X and 0.65X magnification.
Page 2 Step 2: Mount the Moticam S2 onto your microscope’s C-mount, and if your microscope is equipped with a beam splitter, pull the beam splitter to ensure light can reach to the trinocular port. Power button Step 3: Plug in the Moticam S2 power supply and...
Page 3 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment.
