  • Page 1 Network Dome Camera Quick Start Guide MVID-03IR-E...
  • Page 2 Network Dome Camera·Quick Start Guide Quick Start Guide About this Manual This Manual is applicable to 17xx & 27xx Network Dome Camera. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Network Dome Camera·Quick Start Guide FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Network Dome Camera·Quick Start Guide 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
  • Page 5 Network Dome Camera·Quick Start Guide The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings Follow these Cautions Follow these safeguards to prevent...
  • Page 6 Network Dome Camera·Quick Start Guide ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
  • Page 7 Network Dome Camera·Quick Start Guide ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ●...

  • Page 8: Table Of Contents

    Network Dome Camera·Quick Start Guide Table of Contents 1 Appearance Description ............... 10 1.1 Type I Camera ............... 10 1.1.1 Overview ..............10 1.1.2 Cable Description............. 12 1.2 Type II Camera .............. 13 1.2.1 Overview ..............14 1.2.2 Cable Description............. 15 2 Installation ..................
  • Page 9 Network Dome Camera·Quick Start Guide 4 Accessing via Web Browser ............51 5 Operating via Guarding Vision App ..........53 Enable Guarding Vision Service on Camera ....53 5.1.1 Enable Guarding Vision Service via SADP Software .. 53 5.1.2 Enable Guarding Vision Service via Web Browser ..54 Guarding Vision Setup ...........

  • Page 10: Appearance Description

    Network Dome Camera·Quick Start Guide 1 Appearance Description This series of cameras has two appearance types. Type I Camera Type I camera has different models. Some models have the lens that zoom and focus levels must be manually adjusted via zoom/focus lever and some models have a motor-driven lens that zoom and focus adjustment can be completed via web browser or client software.
  • Page 11 Network Dome Camera·Quick Start Guide Figure 1-2 Overview of Type I Camera (2) Table 1-1 Overview of Type I Camera Description Bubble Black Liner Lens Mounting Base Reset Auxiliary Video Output Serial Port Memory Card Slot...

  • Page 12: Cable Description

    Network Dome Camera·Quick Start Guide 1.1.2 Cable Description Cable description of the Type I network dome camera is shown below. Note: Cables vary according to different models as the figures below. Figure 1-3 Cable Description of Type I Camera (1) Figure 1-4 Cable Description of Type I Camera (2)

  • Page 13: Type Ii Camera

    Network Dome Camera·Quick Start Guide Table 1-2 Cable Description Description Network Interface Power Supply Interface Audio/Alarm Interface Audio Input and Output Interface Video Output Interface Alarm Input and Output Interface Notes:  Power on the camera when pressing the RESET button, and press button for another 10 seconds to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 14: Overview

    Network Dome Camera·Quick Start Guide 1.2.1 Overview The overview of the Type II network dome camera is shown below. Overview of Type II Camera (1) Overview of Type II Camera (2)

  • Page 15: Cable Description

    Network Dome Camera·Quick Start Guide Overview of Type II Camera Description Bubble Black Liner Lens Reset Memory Card Slot 1.2.2 Cable Description Cable description of the Type II network dome camera is shown below. Note: Cables vary according to different models as the figures below. Figure 1-7 Cable Description of Type II Camera (1)
  • Page 16 Network Dome Camera·Quick Start Guide Figure 1-8 Cable Description of Type II Camera (2) Table 1-4 Cable Description Description Power Supply Interface Network Interface Video Output Interface Note: Power on the camera when pressing the REST button, and press button for another 10 seconds to restore the default settings, including the user name, password, IP address, port No., etc...

  • Page 17: Installation

    Network Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or PoE (802.3af). Make sure your power supply matches with your camera.

  • Page 18: Preparation

    Network Dome Camera·Quick Start Guide Preparation Purpose: Before mounting, you have to disassemble the camera and install the memory card first. 2.1.1 Disassembling Steps: 1. Loosen the three screws on the edge of the bubble with the screw driver. 2. Lift and put aside the bubble. 3.

  • Page 19: Memory Card Installation

    Network Dome Camera·Quick Start Guide Black Liner Bubble Screws Remove the Bubble and Black Liner (Type II Camera) 2.1.2 Memory Card Installation Steps: 1. Rotate the camera body to completely expose the memory card slot. 2. Insert the memory card into the memory card slot, and push to get it mounted.
  • Page 20 Network Dome Camera·Quick Start Guide Memory Card Memory Card Slot Install the Memory Card (Type I Camera) Memory Card Slot Install the Memory Card (Type II Camera) 3. (Optional) To unmount the memory card, push to eject it.

  • Page 21: Mounting

    Network Dome Camera·Quick Start Guide Mounting Installation of type I camera, and type II camera are similar. We take type I camera as an example in this manual. 2.2.1 Ceiling Mounting Steps: 1. Attach the drill template (supplied) to the place where you want to fix the camera.
  • Page 22 Network Dome Camera·Quick Start Guide Front Drill Template Hole A: Route cables through the ceiling. Hole B: Side outlet. Hole 1: Fix the mounting base. Please use Φ5.5mm drill to install expansion screws. The Drill Template (Type II Camera) Notes: ●...
  • Page 23 Network Dome Camera·Quick Start Guide Back Box Screws Secure the Camera 4. Adjust the surveillance angle, zoom and focus level. Refer to the Chapter 2.3 Image and Focus Adjusting for detailed information. 5. Install the inner black liner back to the camera. 6.
  • Page 24 Network Dome Camera·Quick Start Guide Conduit Installation on the Side If you want to route the cables from side of the camera, you need to install a conduit for cable routing. Steps: 1. Rotate the water-proof plug counterclockwise to remove it from the camera.

  • Page 25: In-Ceiling Mounting

    Network Dome Camera·Quick Start Guide Note: For wall mounting, position the side outlet directly downward for waterproofing. Downward Side Outlet Direction 2.2.2 In-ceiling Mounting Before you start: In-ceiling mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. The in-ceiling mounting bracket shown in below is only for demonstration.
  • Page 26 Network Dome Camera·Quick Start Guide Main Body Ceiling Hole Size In-ceiling Mounting Bracket Cut a Hole for In-ceiling Mounting 2. Align No.1 screw holes with the corresponding screw holes on the bracket, and secure the mounting base to the bracket with screws. In-ceiling Mounting Bracket Mounting...
  • Page 27 Network Dome Camera·Quick Start Guide In-ceiling Mounting Mounting Base Bracket Camera Screw Holes for Camera Fixing Install the Camera to the Mounting Base 4. Place the bracket and camera to the hole in ceiling, and screw the toggle bolt clockwise to fix the bracket in ceiling.
  • Page 28 Network Dome Camera·Quick Start Guide Toggle Bolts: screw them clockwise Toggle Bolts: fix the bracket Fix the Bracket in Ceiling 5. Adjust the surveillance angle, and refer to Chapter 2.3 Image and Focus Adjusting for details. 6. Install the black liner and the bubble back to the camera. Install the Black Liner and the Bubble...

  • Page 29: Mounting With Wall Mounting Bracket

    Network Dome Camera·Quick Start Guide 7. Install the rim to the bracket. Install the Rim 2.2.3 Mounting with Wall Mounting Bracket Before you start: Wall mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. The wall mounting bracket shown below is only for demonstration.
  • Page 30 Network Dome Camera·Quick Start Guide Steps: 1. Route the cables, install the wall mounting bracket, and secure the cap on the bracket. Wall Mounting Bracket Install Wall Mounting Bracket 2. Align the screw holes of the mounting base with the corresponding screw holes of the cap.
  • Page 31 Network Dome Camera·Quick Start Guide Secure the Camera 5. Connect the video output connector to the monitor. Connect the power connector to the power supply. 6. Adjust the image and focus. Refer to the Chapter 2.3Image and Focus Adjusting for more detailed information. 7.

  • Page 32: Mounting With Pendant Mounting Bracket

    Network Dome Camera·Quick Start Guide Secure Black Liner and Bubble 2.2.4 Mounting with Pendant Mounting Bracket Before you start: Pendant mounting bracket is not included in package. If you choose this mounting type, you have to prepare a bracket first. The pendant mounting bracket shown below is only for demonstration.
  • Page 33 Network Dome Camera·Quick Start Guide Size of the Mounting Base Steps: 1. Route the cables and Install the pendant mounting bracket. Secure the cap on the bracket. Pendant Mounting Bracket Install the Pendant Mounting Bracket 2. Align the screw holes of the mounting base with the corresponding screw holes of the cap.
  • Page 34 Network Dome Camera·Quick Start Guide 3. Secure the mounting base to the cap with screws. Mounting Base Install the Mounting Base 4. Align the camera with the mounting base, and secure the camera with screws. Secure the Camera...

  • Page 35: Mounting With Junction Box

    Network Dome Camera·Quick Start Guide 5. Adjust the image and focus. Refer to the Chapter 2.3 Image and Focus Adjusting for more detailed information. 6. Install the inner black liner back to the camera. 7. Secure the bubble to the camera with screws. Secure Black Liner and Bubble 2.2.5 Mounting with Junction box Steps:...
  • Page 36 Network Dome Camera·Quick Start Guide Junction Mounting Base Install the Mounting Base 3. Route the cables through the hole in the center of the mounting base. 4. Align the camera with the mounting base. And secure the camera with screws. Secure Camera...

  • Page 37: Image And Focus Adjusting

    Network Dome Camera·Quick Start Guide 5. Adjust the image and focus. Refer to the Chapter 2.3 Image and Focus Adjusting for more detailed information. 6. Install the inner black liner back to the camera. 7. Secure the bubble to the camera with screws. Secure the Black Liner and Bubble Image and Focus Adjusting Before you start:...

  • Page 38: 3-Axis Adjustment

    Network Dome Camera·Quick Start Guide To a monitor Auxiliary Video Cable Auxiliary Video Output Connect Camera to a Monitor Note: For certain camera models, the auxiliary video cable is not included in the package. Instead, you can connect the video out interface of the camera to a monitor for image and focus adjustment.
  • Page 39 Network Dome Camera·Quick Start Guide 2. Loosen the tilt adjusting screw to adjust the tilt angle [0° to 90°]/ [0° to 70°], hold the black liner to adjust the pan angle [0° to 355°], and hold the lens to rotate the camera [0° to 355°]. Note: The tilting angle varies according to the different models as the figures below.

  • Page 40: Zoom And Focus Adjustment

    Network Dome Camera·Quick Start Guide 2.3.2 Zoom and Focus Adjustment. Manually Adjustment: Some camera models of this series have the lens that zoom and focus levels must be manually adjusted via zoom/focus lever and you can use zoom lever and focus lever to adjust the lens. Steps: 1.
  • Page 41 Network Dome Camera·Quick Start Guide Zoom/Focus Lever Zoom/Focus Lever (Type II Camera) 3. Tighten the zoom lever. 4. Loosen the focus lever and move the lever between F (Far) and N (Near) to obtain the optimum focus. 5. Tighten the focus lever. Motor-driven Lens: Some camera models of this series are equipped with a motor-driven lens.
  • Page 42 Network Dome Camera·Quick Start Guide Zoom and Focus Adjustment via Web Browser...

  • Page 43: Setting The Network Camera Over The Lan

    Network Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 44: Activating The Camera

    Network Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 45: Activation Via Sadp Software

    Network Dome Camera·Quick Start Guide Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 46 Network Dome Camera·Quick Start Guide activate the camera, please refer to the User Manual of Network Camera for other two activation methods. Steps: 1. Run the SADP software to search the online devices. 2. Check the device status from the device list, and select the inactive device.

  • Page 47: Modifying The Ip Address

    Network Dome Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 48 Network Dome Camera·Quick Start Guide For IP address modification via client software, refer to the user manual of client software. Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.
  • Page 49 Network Dome Camera·Quick Start Guide Modify the IP Address Note: You can enable the Guarding Vision service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification.
  • Page 50 Network Dome Camera·Quick Start Guide The batch IP address modification is supported by the SADP. Please refer to the User Manual of SADP for details.

  • Page 51: Accessing Via Web Browser

    Network Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 52 Network Dome Camera·Quick Start Guide Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug- Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 53: Operating Via Guarding Vision App

    Network Dome Camera·Quick Start Guide 5 Operating via Guarding Vision App Purpose: Guarding Vision is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: Guarding Vision service is not supported by certain camera models. Enable Guarding Vision Service on Camera Purpose: Guarding Vision service should be enabled on your camera before...

  • Page 54: Enable Guarding Vision Service Via Web Browser

    Network Dome Camera·Quick Start Guide “Privacy Policy” Service” Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Guarding Vision app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Guarding Vision Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 55 Network Dome Camera·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Platform Access Configuration (Web) 3. Select Platform Access Mode as Guarding Vision. 4.

  • Page 56: Guarding Vision Setup

    Network Dome Camera·Quick Start Guide Guarding Vision Setup Steps: 1. Download and install the Guarding Vision app by searching “Guarding Vision” in App Store or Google Play 2. Launch the app and register for a Guarding Vision user account. 3. Log in Guarding Vision app after registration. Adding Camera to Guarding Vision Before you start: You need to enable the Guarding Vision service on camera before...
  • Page 57 Network Dome Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 58: Initializing The Memory Card

    Network Dome Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
  • Page 59 Network Dome Camera·Quick Start Guide...
