Summary of Contents for ERNITEC MicroView MVCLOUD-101
- Page 1 Camera Network Cube Camera Quick Start Guide MVCLOUD-101...
- Page 2 Network Ernitec Cube Camera·Quick Start Guide Quick Start Guide About this Manual This Manual is applicable to MVCLOUD -101 Network Ernitec Cameras. The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information here in after are for description and explanation only.
-
Page 3: Regulatory Information
Network Ernitec Cube Camera·Quick Start Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Safety Instruction
Network Ernitec Cube Camera·Quick Start Guide 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. - Page 5 Network Ernitec Cube Camera·Quick Start Guide Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.
- Page 6 Network Ernitec Cube Camera·Quick Start Guide ● If smoke, odor, or noise rise from the device, turn off the power at once and unplug the power cable, and contact the service center. Cautions ● Make sure the power supply voltage is correct before using the camera.
- Page 7 Network Ernitec Cube Camera·Quick Start Guide ● While in delivery, pack the camera in its original, or equivalent, packing, packing materials. Or packing of the same texture. ● Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment shall be replaced regularly according to their average endurance.
-
Page 8: Table Of Contents
2.2 Ceiling Mounting ............16 3 Setting the Network Camera over the LAN ........19 3.1 Wiring ................19 4 Register Camera Into Ernitec Cloud Services ........ 20 4.1 Register Camera from dashboard for professionals ..20 4.1.1 Register Camera ..........20 4.1.2 Unregister Camera .......... -
Page 9: Appearance Description
Network Ernitec Cube Camera·Quick Start Guide 1 Appearance Description There are two cube camera appearances available for this camera series, refer to the following chapter for details. Type I & Type II Cube Camera Figure 1-1 Type I Cube Camera... - Page 10 Network Ernitec Cube Camera·Quick Start Guide Figure 1-3 Front View and Side View of Type I and Type II Cube Camera Figure 1-4 Rear View of Type I Cube Camera...
- Page 11 Network Ernitec Cube Camera·Quick Start Guide Figure 1-5 Rear View of Type II Cube Camera Description of Type I and Type II Cube Camera Table 1-1 Description Lens Microphone IR LED Alarm: Solid red when the camera is armed; Solid blue when the camera is unarmed.
- Page 12 Network Ernitec Cube Camera·Quick Start Guide Description Link: Flashing amber when network is connected; Unlit when network is disconnected PIR(Passive Infrared) sensor Light Sensing microSD Card Slot 3-axis Bracket 10M / 100M self-adaptive Ethernet interface &PoE WPS (Wi-Fi Protected Setup)/Reset Button...
-
Page 13: Wps Instruction
Network Ernitec Cube Camera·Quick Start Guide WPS Instruction WPS (Wi-Fi Protected Setup, also known as AOSS or QSS) is a computing standard that attempts to allow easy establishment of a secure wireless network. A wireless router with the WPS function is required to enable the WPS function of the camera. -
Page 14: Installation
Network Ernitec Cube Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera. -
Page 15: Stand Mouting
Network Ernitec Cube Camera·Quick Start Guide Stand Mouting Steps: Take the bracket out from the package. Figure 2-1 Bracket Align the camera body to the bracket, and rotate the camera body to fix it with the bracket. Figure 2-2 Install the Camera Body... -
Page 16: Ceiling Mounting
Network Ernitec Cube Camera·Quick Start Guide Assemble the camera as the steps above, and put the camera on the flat surface. Ceiling Mounting 1. Drill the screw holes according to the drill template. Figure 2-3 Drill Template 2. Disassemble the 3-axis bracket. Hold the base with one hand, and rotate the pole anticlockwise to disassemble the pole from the base. - Page 17 Network Ernitec Cube Camera·Quick Start Guide Knob Pole Mounting Base Fixed Tray Figure 2-4 Disassemble the Bracket 3. Install the fixed tray to the ceiling with the supplied screws. 4. Install the base to the fixed plate. Figure 2-5 Install the Fixed Plate and Mounting Base...
- Page 18 Network Ernitec Cube Camera·Quick Start Guide Figure 2-6 Install the Camera 6. Adjust surveillance angel (1) Loosen the knob to adjust the panning angle from 0° to 360°. (2) Adjust the tilting angle from 0° to 90°. (3) After adjusting the angle of the camera to the desired position, fasten the knob.
-
Page 19: Setting The Network Camera Over The Lan
Network Ernitec Cube Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. -
Page 20: Register Camera Into Ernitec Cloud Services
Network Ernitec Cube Camera·Quick Start Guide 4 Register Camera Into Ernitec Cloud Services Register Camera from dashboard for professionals 4.1.1 Register Camera Steps: Find the MAC Address on the sticker of the camera box. Figure 4-1: Mac Address on the sticker... - Page 21 Network Ernitec Cube Camera·Quick Start Guide Go to the Customers page of Dashboard. Click on “Add Camera” button of subscription’s customer. Figure 4-2: Add Camera Button After the camera is connected to internet, you have 30 minutes from its start time in order to enter the MAC address, camera name and choose the Time Zone then click “Add”...
-
Page 22: Unregister Camera
4.1.2 Unregister Camera Steps: 1. In order to disable Ernitec Cloud services, please click on “Delete Camera” button of the Customers page of Dashboard. Figure 4-4: Delete Camera Button 2. If you are sure to delete your camera, click on “Yes“button. -
Page 23: Register Camera With Scan Of The Qr Code
Register Camera with scan of the QR Code You can also register your camera with scanning the QR code from “Ernitec Cloud” App on IOS/Android. The application “Ernitec Cloud” can be downloaded from App Store or from Google Play (please refer... -
Page 24: Download "Ernitec Video" App On Ios/Android
Network Ernitec Cube Camera·Quick Start Guide 5 Download “Ernitec Cloud” App on IOS/Android To use the mobile application “Ernitec Cloud”, you should download it with two ways: Searching “Ernitec Cloud” from the Google Play (Android) or from the App Store (IOS). - Page 25 Using your smartphones or your iPhone equipped with an application to read QR codes you can easily download “Ernitec Cloud” App. Once you scan the QR Code existing on the sticker of camera box, the link of download application appears on the screen of your smartphones or your iPhone.
-
Page 26: Wifi Network Setup
2. Register the camera (Refer to the chapter 4). 3. From the website Ernitec-Cloud, or with the mobile application, go to the camera setting, the Wi-Fi setting. 4. Select the Wi-Fi network from the list.
