- Page 1 LM-200LED LED Light Meter Users Manual • Mode d’emploi • Bedienungshandbuch • Manuale d’Uso • Manual de uso...
- Page 3 LM-200LED LED Light Meter Users Manual LM-200LED_Rev001 © 2010 Amprobe Test Tools. All rights reserved.
- Page 4 “where to Buy” section on www.amprobe.com for a list of distributors near you. Additionally, in the United States and Canada in-warranty repair and replacement units can also be sent to a Amprobe® Test Tools Service Center (see address below).
- Page 5 LM-200LED ➊ Light sensor ➋ Display(LCD) ➌ Lux / foot candles ➍ MAx hoLD ➎ power Button: on/off ➏ Manual range selection ➐ DATA hoLD button ➑ Light sensor Zero Adjustment...
- Page 6 LM-200LED LED Light Meter CoNtENtS SYMBoLS ......................1 UnpACKing AnD inSpECTion ................1 inTRoDUCTion ....................1 opERATion ......................1 Lx / fc ........................ 2 Data hold ....................... 2 MAn Ranging ....................2 MAx ........................ 2 Auto-power off ..................... 2 Zero ........................2 SpECifiCATionS ....................
-
Page 7: Unpacking And Inspection
UNPACkINg AND INSPECtIoN Your shipping carton should include: LM-200LED LED light meter 9 volt battery Users Manual if any of the items are damaged or missing, return the complete package to the place of purchase for an exchange. -
Page 8: Specifications
Lx / fc illuminance scales. 1 foot-candle = 10.764 Lux and 1 lux = 0.09290 foot- candles. Data Hold freezes the reading present on the LCD at the moment the button is pressed. press hoLD again to disable Data hold. MAN Ranging press the MAnual ranging button for useable reading. -
Page 9: Maintenance And Repair
Illumination: Measuring Range: 20, 200, 2000, 20000, 200000 Lux 20, 200, 2000, 20000 foot candles Accuracy: ± 3 % (Calibrated to standard incandescent lamp at 2856 °K) 8% other visible light sources Angle deviation from cosine Characteristics 30 ° ± 2 % 60 °... - Page 10 battery Replacement Turn off the meter and slide out the battery cover. Replace the battery with a nEDA type 1604 or equivalent 9V alkaline battery. Replace the cover. Remove battery when the instrument is not used for extended period. O P E N Battery Replacement...
- Page 12 Visit www.Amprobe.com for • Catalog • Application notes • product specifications • User manuals please Recycle...
