Brickcom NR-2108 User Manual page 104

 Scale bar
Users can move thebarto enlarge or narrow downthe time period to check video files
from Time table.

Seek bar
By moving seek bar, users can go to the specific recording time directly.
Time is shown above seek bar to provide time reference.
 Thumbnail in Playback
With thumbnail function in the playback, users can move the pointer of the mouse
to the footage and the snapshot of the specific time will be shown.
It helps users easier to locate the period of time for play the recording file.
From the thumbnail, users can also read the related information such as date, time
and camera name.
The thumbnail will be shown while pointer moves on the footage.
103
