  • Page 1 Total Vehicle Management System TVMS1280 TVMS1280-NA...

  • Page 2: Warnings, Safety Instructions

    IS INSTALLED AS PER THESE INSTALLATION INSTRUCTIONS. REDARC RECOMMENDS THAT THE SYSTEM BE INSTALLED BY A SUITABLY QUALIFIED PERSON. DISCLAIMER: REDARC accepts no liability for any injury, loss or property damage which may occur from the improper or unsafe installation or use of its products.
  • Page 3 REDARC for repair. Incorrect handling or reassembly may result in a risk of electric shock or fire and may void the unit warranty. Use of an attachment not recommended or sold by REDARC may result in a risk of fire, electric shock, or injury to persons.

  • Page 4: Table Of Contents

    CONTENTS Table of Contents Warnings, Safety Instructions Features and Benefits 1. Introduction 1.1 Kit Contents 1.2 Specifications 1.3 Compatible REDARC Devices 1.4 Dimensions 2. Installation Guide 2.1 System Layout 2.2 Mounting Instructions 2.3 DC Cable Size Requirements 2.4 Digital Inputs 2.5 Fuses...

  • Page 5: Features And Benefits

    RedVision acts as a central hub that connects devices and displays vital information for the vehicle and its on-board accessories. RedVision allows the user to turn lights, REDARC inverters, water pumps and other loads such as televisions, electric steps and fridges on or off, while displaying...

  • Page 6: Introduction

    Fuse puller tool (fitted) 80A midi fuse Midi fuse holder 50A midi fuses (fitted) Crimp terminals for fuse holder 0.5m R-Bus Cable 3m REDARC Inverter Remote Cable R-Bus Terminator Temperature Sensors Power cable mating connectors Digital Input mating connector Display (DISP4300): Part 4.3”...

  • Page 7: Specifications

    Warranty 2 years Electrical Specifications System Voltage Maximum Charger Current Maximum Battery Current No. Switched Circuits 5 x 10A Max, 5 x 30A Max Compatible REDARC Devices Type REDARC Part Device Relevant section of Number Connection Wire this manual BCDC1220...

  • Page 8: Dimensions

    INTRODUCTION Dimensions Dim C 2.5mm (0.1”) 71.5mm (2.81”) Dim D 58mm (2.28”) 80mm (3.14”) 27mm 66mm (2.59”) (1.06”) 138mm (5.43”) Dim A Ø6mm (.23”) Dim B Ø11mm (.43”) Dim C Ø6mm (.23”) Dim D 28mm (1.1”) Figure 1.4.1 - Distribution Box Dimensions...
  • Page 9 INTRODUCTION 18.5mm (0.73”) 178mm (7.00”) 11mm ( 0.43”) (0.28”) 11mm Optional Spacer (0.43”) 158mm (6.22”) 19mm 15mm (0.74”) (0.59”) 156mm (6.14”) (0.23”) Figure 1.4.2 - Display Dimensions...

  • Page 10: Installation Guide

    INSTALLATION GUIDE System Layout* Distribution Box Display Terminating Resistor To Ignition To Alternate Trigger Signals Water Level Sensors Small Loads Large Loads Battery Sensor Temperature Sensors Auxiliary Battery Inverter See the Manager30 manual for full wiring details. Do not use this product to control safety critical devices or those that could cause harm if operated remotely (for example fume exhaust fans or lifters).

  • Page 11: Mounting Instructions

    INSTALLATION GUIDE Mounting Instructions The Distribution Box should be mounted as close as possible to the auxiliary battery(s) and Battery Charger to avoid voltage drop. 2.2.1 Mounting the Distribution Box The Distribution Box may be mounted in any orientation but must be mounted onto a flat, solid surface using 4 x M6 (or 14G) screws or bolts.
  • Page 12 INSTALLATION GUIDE 2.2.2 Mounting the Display The Display should be mounted on a flat, solid surface in a sheltered location such as in the vehicle (Refer to Page 48 for a 1:1 cutout template). It is however acceptable to mount the Display in any convenient location, as long as it is protected from harsh environments such as being exposed to rain or severe amounts of dust or full-time direct sunlight.
  • Page 13 INSTALLATION GUIDE 2.2.3 Removing the Display Fascia...
  • Page 14 INSTALLATION GUIDE Refer to Page 48 for a 1:1 cutout template 2.2.4 Flush Mount Drill/Cut Dimensions 164mm (6.45”) 156mm (6.14”) 109mm (4.29”) NOT TO SCALE Refer to Page 48 for a 1:1 cutout template 132 (5.20”) 2.2.5 Surface Mount Drill/Cut Dimensions 156mm (6.14”) 24mm (.94”)

  • Page 15: Dc Cable Size Requirements

    Positive to Ground 2.3.2 Output Wire Diameter Selection REDARC recommends the installer use suitably rated cable and fuses for the load connected. Refer to the table below for the 10 and 30 amp connector terminal sizes and maximum cable sizes.

  • Page 16: Digital Inputs

    INSTALLATION GUIDE Digital I/Os Digital Inputs Start Battery Positive Start Battery Negative The Distribution Box incorporates 3 digital inputs. The digital inputs, , can be configured to switch Distribution Box output loads on/off when triggered (for example, to turn off all loads except a fridge when the vehicle ignition is on).

  • Page 17: Fuses

    INSTALLATION GUIDE Fuses Spare Charger Fuse 50A Charger Fuse Override Switches 30A Max Circuit Fuses 10A Max Circuit Fuses Spare Fuses 2.5.1 Fuse Locations The Distribution Box load output channels are protected by standard blade fuses located in the fuse panel: Part Type 10A Max Loads...
  • Page 18 INSTALLATION GUIDE Master Override Indicator Master Override switch Blown Fuse Indicators 10A max circuit 30A max circuit override switches override switches Note: Fuse values may vary from those shown in this diagram, depending on individual system requirements 2.5.3 Blown Fuse Indicators A blown fuse is indicated by an illuminated indicator (white) above the blown fuse.

  • Page 19: Battery & Charger Connection

    Battery & Charger Connection The RedVision is intended to be used in conjunction with the Manager30, but alternatively, it can be used with a REDARC BCDC charger. 2.6.1 Battery Connection Wire the Auxiliary Battery Positive (+) to the Distribution Box through the supplied 80A MIDI fuse - this fuse should be mounted as close as practical the battery.
  • Page 20 INSTALLATION GUIDE 2.6.3 BCDC Connection If using a BCDC, it should be mounted as close as possible to the Distribution Box. Connect the BCDC’s battery output positive (+) and Ground ( ) to the Distribution Box Charger (+) and Ground (-) connections. Refer to Section 2.3 for cable sizing. The Distribution Box includes a 50A MIDI fuse to protect the charging circuit.

  • Page 21: Temperature Sensors

    -40°C to +80°C (-40°F to +176°F). The two supplied temperature sensors may be added to the system by simply plugging into the two sockets on the Distribution Box. Additionally, the REDARC sensors in the table below are also compatible: Part...

  • Page 22: R-Bus Connection

    INSTALLATION GUIDE R-Bus Connection (Manager30) Terminating Resistor Battery Sensor Display 2.8.1 Connecting the RedVision R-Bus RedVision uses an R-Bus communication system to link components. 1. Use the supplied 1 metre (3’3”) RJ45 cable to connect the Battery Management System to either of the sockets on the Distribution Box. 2.
  • Page 23 2m. The REDARC Manager30 Sensor has this resistor built in, thus removing the need to add an extra terminating resistor to one end of the system. The other end of the network should be terminated by inserting the supplied Terminating Resistor into the last device in the network (for example, into the RedVision Display in the diagram on Page 21).

  • Page 24: Water Level Sensors

    INSTALLATION GUIDE Water Level Sensors Up to six water level sensors may be connected to the Distribution Box. 2-5 pin tank senders Most 2-5 pin conductive tank sensors can be used in conjunction with an Wire 5 (if applicable) AMP-171822-5 connector (not Wire 4 (if applicable)

  • Page 25: Optional Inverter Connection

    Rear (12V end) of Inverter REDARC’s RS/RS2-Series inverters may be connected to the Distribution Box to allow the user to switch the inverter on/off, via the Display. The 350W model inverter (R-12- 350RS2) also offers power on/off control. The inverter should be mounted as close as possible to the Auxiliary battery (Refer to the inverter’s user manual for further installation...

  • Page 26: System Configuration

    SYSTEM CONFIGURATION RedVision Configurator App. The RedVision ‘Configurator’ App allows the user to setup and/or customise their RedVision setup from the convenience of their mobile device. If this is your first time using the Configurator App, please follow the Bluetooth pairing ®...

  • Page 27: Configure Charger

    SYSTEM CONFIGURATION Configure Charger The Configure BMS (Charger) page allows you to setup the Input Trigger and Disconnect When settings for a Manager30 should one be connected. • The default Input trigger setting is ‘Automatic’. • The default Disconnect When From the Main Menu: setting is ‘Always’.

  • Page 28: Configure Distribution Box - Load Disconnect Settings

    SYSTEM CONFIGURATION Configure Distribution Box - Load Disconnect Settings From the Main Menu: 1. Tap the Distribution Box Button, then 2. Tap the Load Disconnect Settings Button The Configure TVMS Disconnect page allows you to set the Disconnect Trigger for the RedVision system.

  • Page 29: Configure Distribution Box - Channels

    SYSTEM CONFIGURATION Configure Distribution Box - Channels From the Main Menu: 1. Tap the Distribution Box Button, then 2. Tap the Channels Button The Channel Settings page allows you to customise each of the connections to your RedVision Distribution Box. Simply put, you can tell RedVision what you have connected to it, and how you want RedVision to control that channel.
  • Page 30 (i.e. Clean, Black, Brown etc.) 5. Inverter Settings - Allows enabling of Inverter remote control should a REDARC RS series inverter be connected to the ‘Optional Inverter Connection’ port on the RedVision Distribution Box.
  • Page 31 SYSTEM CONFIGURATION From the Channel Settings Menu: • Tap the Channel that you wish to modify There are three main Logic Configuration types that can be used: 1. Always On - This will ensure that the selected channel is Always On. This could be used for a fridge, for example, so that you don’t accidentally turn it OFF.

  • Page 32: Configure Display - Soft Keys

    Changing configuration via wiring changes and/or using the Configurator App. could result in removal of safety features intended to prevent operation of external lights or mechanical devices while the vehicle is in motion, leading to hazardous or fatal consequence. SYSTEM CONFIGURATION Configure Display - Soft Keys The Configure Soft Keys page al- lows allocation of any Output Chan-...

  • Page 33: Configure Display - Home Screen

    SYSTEM CONFIGURATION Configure Display - Home Screen From the Main Menu: 1. Tap the Display Button, then 2. Tap the Home Screen Button The Home Screen Settings page allows configuration of the RedVision Display Home Screen. Home Screen Layout - This drop down menu allows selection of a number of Home Screen combinations.

  • Page 34: Configure Display - Status Screen

    SYSTEM CONFIGURATION Configure Display - Status Screen From the Main Menu: 1. Tap the Display Button, then 2. Tap the Status Screen Button, then 3. Select your Screen or Add a new Status Screen The Status Screen Settings page allows configuration of the RedVision Display Status Screens.

  • Page 35: Configure Display - Temperature Units

    SYSTEM CONFIGURATION Configure Display - Temperature Units From the Main Menu: 1. Tap the Display Button, then 2. Tap the Temperature Units Button The Temperature Screen Settings page allows configuration of the RedVision Display Temperature Units. Simply select if you would like your units displayed in Celsius or Fahrenheit and hit save.

  • Page 36: User Guide

    USER GUIDE The Display Time Notification Bar Temperature Up/Down indication function Softkeys Softkeys Softkey Locked Device active indication Up/Down Left/Right arrow arrow Left/Right function Power Button The Display is the main user interface for the RedVision System. It brings information and control to one place without the need for multiple displays and control panels.
  • Page 37 USER GUIDE 4.1.1 Navigation The Left/Right buttons are used to navigate the pages on the centre of the screen. The Up/Down buttons are used to cycle through devices on the Home Page or to navigate through options found on other pages. The Left/Right and Up/Down functions are indicated on the screen.
  • Page 38 USER GUIDE 4.1.5 Basic Screens Home Screen The Home Screen shows the system overview in the centre, with connected devices managed by Soft Keys to the left and right. The system overview shows BMS status and Water Tank levels Pushing the Up/Down arrows cycles through all available devices.
  • Page 39 Charging Source information page. Pushing the down arrow displays When used with a REDARC MANAGER system. the Distribution Box Info. screen* When used with a REDARC RedVision Distribution Box. Distribution Box Information The Distribution Box information Distribution Box screen provides information 14.4V...
  • Page 40 USER GUIDE 4.1.6 Display Settings Factory Settings Display Settings Key Sound: Key Backlight: Home Timeout: 1 min Standby Timeout: 1 min Brightness Minimum: Brightness Maximum: 100% Clock Format: 12 Hour The Display Settings screen allows setup and modification of Display specific settings as outlined below.
  • Page 41 REDARC This icon links to the R-Bus Diagnostics screen. This screen provides a serial number for each REDARC device connected to the system. More information on the selected device can be found by clicking the top right Soft Key This icon links to the Fault History screen.
  • Page 42 USER GUIDE 4.1.8 BMS Settings BMS Settings When a Battery Management System is connected, the system will allow setup and modification of a number of BMS settings as outlined below. This icon will return to the Home Screen This icon links to the Battery Information screen. This screen allows the user to set their battery type and size.
  • Page 43 USER GUIDE 4.1.9 Distribution Box Settings Distribution Box This Settings screen allows setup and modification of the Distribution Box Load Disconnect feature and provides information on the Distribution Box’s channel setup. Distribution Box settings can only be changed by the system installer. This icon will return to the Home Screen This icon links to the Channel Information screen.

  • Page 44: Fault Display

    USER GUIDE Fault Display TVMS Output Fuse blown Fault screens will be shown if either an output fuse is blown, the Manager has a fault, or if the unit encounters a switching fault. Fuse Faults When a fuse fault is detected (ie, a fuse is blown) the output channel will be turned off and the corresponding icon on the display will be shown in red.

  • Page 45: The Redvision App

    It also provides the user with the ability to monitor water levels, temperature, energy (battery power) consumption and storage, with the battery information available when used with a REDARC Manager battery management system. The RedVision App replicates most of the display and switching features of the Display.
  • Page 46 Pairing Instructions ® 1. Install the RedVision or Configurator App (scan the corresponding QR code or search for “REDARC” on your device’s app store) 2. On the Display, press Left, navigate to display RedVision settings & press the Bluetooth ®...
  • Page 47 USER GUIDE 4.3.2 Subsequent Connections Once a smartphone has been paired with a RedVision Display, it will automatically reconnect with that Display when the app is opened. If you have multiple RedVision Displays paired and you want to switch between which is connected to your smart phone, tap on the 3 gear symbol on the top left of the app.

  • Page 48: Product Identification & Compliance

    Consult the dealer or an experienced radio/TV technician for help Any changes or modifications not expressly approved by REDARC could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.

  • Page 49: Display Drill/Cutout Template

    DISPLAY DRILL/CUTOUT TEMPLATE...
  • Page 50 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 51: Two Year Product Warranty

    • Friendly, personalised, professional service and product support In the unlikely event that a technical issue arises with a Redarc product, customers are encouraged to initially contact the Redarc Technical Support Team on (08) 8322 4848 power@redarc.com.au for prompt and efficient diagnosis and product support.
  • Page 52 For North American +1 (704) 247-5150 specific warranty Canada terms please visit... +1 (604) 260-5512 Mexico www.redarcelectronics.com +52 (558) 526-2898 UK/Europe power@redarcelectronics.eu www.redarcelectronics.eu +44 (0)20 3930 8109 Copyright © 2020 REDARC Electronics Pty Ltd. All rights reserved. www.redarc.com.au WARTVMS1280 - REV10...
