- Page 1 REPAIR PARTS MANUAL MODEL NO. REN1192RB (REN11T92RBA) Lawn Tractor 532 19 00-22 02.04.04 TR Der Ersatzteilspezialist im Internet. PRINTED IN U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “REN1192RB (REN11T92RBA)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 SCHEMATIC 12VDC STARTER AMMETER BATTERY (OPTIONAL) SOLENOID STARTER FUSE WHITE BLACK BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ATT'MENT CLUTCH (PEDAL UP) (CLUTCH OFF) GREEN OPERATOR PRESENCE RELAY... -
Page 4: Electrical
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 ELECTRICAL Der Ersatzteilspezialist im Internet. - Page 5 REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 ELECTRICAL KEY PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock Push-In 532 12 47-80 Cable Starter 6 Ga.
- Page 6 REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 CHASSIS AND ENCLOSURES 26 25 209 24 chassis-Elite_Basic_CRD_2. Der Ersatzteilspezialist im Internet.
-
Page 7: Chassis
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 CHASSIS AND ENCLOSURES KEY PART KEY PART DESCRIPTION DESCRIPTION 532 17 46-20 Chassis 532 18 03-83 Bracket Exten Chassis Rh CRD 532 18 03-84 Drawbar 532 16 56-05... -
Page 8: Drive
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 DRIVE drive-fender_CRD_Elite_Basic_2 Der Ersatzteilspezialist im Internet. - Page 9 REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 DRIVE KEY PART KEY PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Peerless 206-546 532 12 50-96 Key Woodruff Order parts from transaxle manu- 532 14 50-90 Arm Shift PMST 20"...
- Page 10 REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 STEERING ASSEMBLY steering_pl.lt_29 Der Ersatzteilspezialist im Internet.
-
Page 11: Steering
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 STEERING ASSEMBLY KEY PART DESCRIPTION 532 13 97-68 Steering Wheel 532 18 47-06 Cast Iron Axle Assembly 532 16 98-40 Spindle Assembly, L.H. 532 16 98-39 Spindle Assembly, R.H. -
Page 12: Seat
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 SEAT ASSEMBLY seat_lt.bolt_6 KEY PART KEY PART DESCRIPTION DESCRIPTION 872 05 04-12 Bolt Rdhd Sht Nk 1/4-20 x 1-1/2 532 17 53-89 Seat 532 13 43-00 Spacer Split... -
Page 13: Decals
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 DECALS MAX + _ 90N MAX + _ 150N KEY PART KEY PART DESCRIPTION DESCRIPTION 532 14 54-98 Decal Read Owner’s Manual Sym 532 14 08-37 Decal Saddle Brake Parking... -
Page 14: Engine
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tecumseh_12 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 17 08-64 Control Throttle /Choke 532 13 70-40 Line Fuel 20" 817 72 04-08... -
Page 15: Mower Lift
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 MOWER LIFT 17 18 lift-rh.1piece_3 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 15 94-61 Washer Asm Inner Spring W/ 532 12 46-70 Retainer Spring Plunger 532 17 32-88... -
Page 16: Mower Deck
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 MOWER 36(92cm)_deck-elect.(CRD)_1 Der Ersatzteilspezialist im Internet. 36 GW med/wide/std... - Page 17 REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 MOWER KEY PART KEY PART DESCRIPTION DESCRIPTION 532 16 55-52 Housing Asm. Mower 873 68 06-00 Nut Crownlock 3/8-16 unc 872 14 05-06 Bolt Rdhd Sqnk 5/16-18 unc x 3/4...
-
Page 18: Bagger
REPAIR PARTS TRACTOR- -MODEL NO. REN1192RB (REN11T92RBA), PRODUCT NO. 964 77 31-02 BAGGER Bagger Asy (CRD)_6 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 18 88-47 Bracket Pivot RH 532 16 52-49 Tube Handle Bagger CRD 532 18 08-80 Bag Asm CRD 872 14 04-16 Bolt Carriage 1/4-20 x 2.0 Gr. - Page 19 www.ersatzteil-service.de SERVICE POLICY ® ® WARRANTY Issued January 1980 Revised January 1991 LIMITED WARRANTIES NEW PEERLESS GEAR POWER TRAIN COMPONENTS A. Products Warranted Peerless Gear and Machine Division of Tecumseh Products Company (“Tecumseh”), subject to the limitations contained below, will,at its option, repair or replace, without charge for parts or labor only, any part of a new Power Train Component (which as used herein means and includes the transaxle, gear box, transmission, differential and right angle drives, and any part of the Power Train Component), EXCEPT any new Power Train Component incorporated in equipment used for commercial or rental purposes, which is found upon examination by any Tecumseh Authorized Service Outlet or by Tecumseh’s factory in Grafton, Wisconsin, to be DEFECTIVE...
