Summary of Contents for Rally RE1338A
- Page 2 ASSEMBLY/REPAIR PARTS MANUAL MODEL NO. RE1338A Lawn Tractor For Parts and Service, contact our authorized distributor: call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886 167957 11.13.98 TR PRINTED IN U.S.A.
-
Page 3: Contents Of Hardware Pack
CONTENTS OF HARDWARE PACK Parts Bag contents shown full size Parts packed separately in carton Seat (1) Large Flat Washer (2) Sheet Steering Steering Metal Screws Boot Wheel #10-16 x 1/2 (1) Locknut 3/8-24 Manual Parts Bag (1) Hex Bolt 1/2-13 x 1 Parts bag contents not shown full size (1) Shoulder Bolt 5/16-18... -
Page 4: Tools Required For Assembly
ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. - Page 5 ASSEMBLY HOW TO SET UP YOUR TRACTOR SEAT PAN CONNECT BATTERY (See Figs. 2 and 3) CAUTION: Do not short battery termi- nals by allowing a wrench or any other object to contact both terminals at the BATTERY same time. Before connecting battery, BOX DOOR remove metal bracelets, wristwatch bands, rings, etc.
- Page 6 ASSEMBLY CHECK TIRE PRESSURE CHECKLIST The tires on your tractor were overinflated at the factory for BEFORE YOU OPERATE AND ENJOY YOUR NEW shipping purposes. Correct tire pressure is important for TRACTOR, WE WISH TO ASSURE THAT YOU RECEIVE best cutting performance. THE BEST PERFORMANCE AND SATISFACTION FROM THIS QUALITY PRODUCT.
-
Page 7: Service Notes
SERVICE NOTES... - Page 8 TRACTOR - - MODEL NUMBER RE1338A SCHEMATIC BLACK BATTERY FUSE 30 AMP. STARTER AMMETER (OPTIONAL) BLACK WHITE SOLENOID CLUTCH / BRAKE (PEDAL UP) WHITE SEAT SWITCH IGNITION (NOT OCCUPIED) SWITCH WHITE BLACK BLACK BLACK BLACK ATT'MENT CLUTCH GROUNDING (CLUTCH OFF)
-
Page 9: Repair Parts
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A ELECTRICAL... - Page 10 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A ELECTRICAL PART DESCRIPTION 144925 Battery 12 Volt 25 Amp 74760412 Bolt Hex Hd 1/4-20unc X 3/4 156417 Case Battery 153664 Switch Interlock Push-In 10090400 Washer Lock 1/4 73350400 Nut Jam Hex 1/4-20 Unc...
-
Page 11: Chassis And Enclosures
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A CHASSIS AND ENCLOSURES... - Page 12 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A CHASSIS AND ENCLOSURES PART DESCRIPTION 165480 Chassis 140356 Drawbar 17490612 Screw, Thd., Roll. 3/8-16 x 3/4 Type-TT 19131216 Washer 13/32 x 3/4 x 16 Gauge 155272 Bumper Hood/Dash 155923 Saddle 124027X Shield Heat Hood LT...
- Page 13 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A DRIVE...
- Page 14 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A DRIVE KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 1 - - - - - - - Transaxle Peerless 205-544C 61 17490612 Screw, Hex Washer Head, Thd., Order parts from transaxle Roll.
-
Page 15: Steering Wheel
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A STEERING WHEEL... - Page 16 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A STEERING WHEEL PART DESCRIPTION 133741 Wheel, Steering 154427 Asm. Axle, Rear 156483 Asm., Spindle, Lh 157473 Asm., Spindle, Rh 6266H Bearing, Thrust, Hardened 121748X Washer 25/32 x 1-5/8 x 16 Ga. 19272016 Washer 27/32 x 1-1/4 x 16 Ga.
-
Page 17: Optional Equipment
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A ENGINE OPTIONAL EQUIPMENT Spark Arrester... - Page 18 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A ENGINE PART DESCRIPTION 152141 Control Th/ch Flag EEC 15.1 17720410 Screw Hex Thd Cut 1/4-20x5/8 T - - - - - - Engine Tecumseh Model OHV130 Order parts from engine manufacturer 156700 Muffler Tec 11/13.0 HP LT...
- Page 19 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A SEAT PART PART DESCRIPTION DESCRIPTION 127426X Seat 72050412 Nut, Crownlock 1/4-20 x 1-1/2 140551 Bracket, Pivot, Seat 134300 Spacer, Split 74760616 Bolt 121250X Spring 19131610 Washer 13/32 x 1 x 10 Ga.
-
Page 20: Tires And Wheels
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A DECALS PART PART DESCRIPTION DESCRIPTION 159736 Decal, Chassis Hot Muffler 127075 Decal Wheel Steering 132628 Decal, Fender Logo 145005 Decal, Battery Dan/Poi P/L Symbols 142308 Decal, Hood Rh 136832 Decal, V-Belt 142309... -
Page 21: Mower Lift
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A MOWER LIFT 17 18 20... - Page 22 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A MOWER LIFT PART DESCRIPTION 159460 Asm. Inner Wire w/Plunger 159474 Asm., Shaft, Lift 105767X Pin, Groove 12000002 Ring, E #5133-62 19211621 Washer 21/32 x 1 x 21 Ga. 120183X Bearing, Nylon 109413X...
-
Page 23: Mower Deck
REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A MOWER DECK 81 82... - Page 24 REPAIR PARTS TRACTOR - - MODEL NUMBER RE1338A MOWER DECK PART PART DESCRIPTION DESCRIPTION 142829 Mower Housing Assembly 122052X Spacer, Retainer 72140506 Bolt 162132 Knob 138017 Asm., Bar, Anti-Sway 144200 V-Belt, Mower 138440 Asm., Bracket, Anti-Sway Bar 76020312 Pin, Cotter 3/32 x 3/4...
-
Page 25: Service Notes
SERVICE NOTES... - Page 26 SERVICE NOTES...
-
Page 27: Warranty
SERVICE POLICY POLICY ® ® WARRANTY Issued January 1980 Revised January 1991 LIMITED WARRANTIES NEW PEERLESS GEAR POWER TRAIN COMPONENTS A. Products Warranted Peerless Gear and Machine Division of Tecumseh Products Company (“Tecumseh”), subject to the limitations contained below, will, at its option, repair or replace, without charge for parts or labor only, any part of a new Power Train Component (which as used herein means and includes the transaxle, gear box, transmission, differential and right angle drives, and any part of the Power Train Component), EXCEPT any new Power Train Component incorporated in equipment used for commercial or rental purposes, which is found upon... -
Page 28: Limited Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and workmanship. For a period of one (1) year from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
