Furniture of America CM7047DJ Assembly Instructions

For more information contact our team: service.ec@foagroup.com

CM7047DJ

ASSEMBLY RATING

Tools Required For Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

Phillips Screwdriver

easy and 5 being difficult). For some

(Not Included)

products, two persons are recommended.

EASY

DIFFICULT

2 PERSONS RECOMMENDED

Rev: 18-07- 30

Page 1 of 4

Table of Contents

Do you have a question about the CM7047DJ and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7047DJ ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Phillips Screwdriver easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1pc #2 x 1pc Ø5/16 Dresser Support Leg 50x30x30mm Page 3 of 4...
Page 4 Attach support leg (#2) to the bottom of the dresser (#1), then adjust leveler of the support leg (#2) according to ground level. Remove handles from the inside of drawers, then reattach handles to the outside of drawers. Page 4 of 4...
