- Page 1 CK222500TX Espresso Pyramid End Table For assistance with assembly contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#11838 Max Top Load 40 lbs. Max Load Inside the Trunk 60 lbs.
- Page 2 CK222500TX Espresso Pyramid End Table Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 8 PCS 8 PCS 1 PC Small Cam Screw Small Cam Lock ϕ6.8 x 36mm ϕ15 x 12mm Wrench 8 PCS 8 PCS 31 PCS ϕ8 x 30mm ϕ ¼” x 2 ¾” ϕ 3.5 x 16mm Dowel Bolt Screw 1 PC 1 PC 1 PC...
- Page 4 CK222500TX Espresso Pyramid End Table Assembly Instructions PLEASE DO NOT OVER-TIGHTEN CAMBOLTS. PLEASE STOP WHEN YOU FEEL TIGHT Step 1: Put all parts on a soft surface to prevent scratches. Attach handle-A (N) to the top (A) using screws (L) and tighten with Phillips screwdriver as shown.
- Page 5 Step 4: Attach handles (P) to left side panels (D) using screws (L) and tighten with phillips screwdriver as shown. Step 5: Screw small cam screws (G) into back panel (C) as shown. Step 6: Insert dowels (J) into side panels (D) as shown.
- Page 6 Step 7: Turn the trunk base upside down and attach legs (F) to the bottom of trunk using screws (K) as shown. Step 8: Attach Hinge (R) to back panel (C) and top panel(A) by using screws (L) as shown and then tighten all screw by phillips screwdriver(not included) Step 9:...
- Page 7 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
