Summary of Contents for SEI CK789200TX
- Page 1 CK789200TX Slide-Top End Table For assistance with assembly, contact： Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Parts List
CK789200TX Slide-Top End Table Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 Quantity Quantity of 4 of 4 Cam bolt Cam locks Quantity Quantity of 14 of 4 Dowel Bolt : Dia 1/4”x3/4” Quantity Quantity of 4 of 1 Allen wrench Bolt : Dia 1/4”x1” Quantity of 4 screw:3/16”x1-3/16”L Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 4 CK789200TX Slide-Top End Table Assembly Instructions Assembly Instructions: Wood may scratch easily, Be careful when assembling. Do not scratch. Step 1: Attached support rack (E) to side panel (B) with wood Dowel (3) and Screw (7), tighten by using screwdriver (not included) as shown.
- Page 5 Step 3: ( 1) ( 2) Attached Assembly unit in step 2 to upper frame (C) with wood Dowel (3) and Cam bolt (1) and Cam locks (2) ,tighten by using "Please do not over tighten cam bolts. Please stop when you feel screwdriver (not included) as tight"...
- Page 6 Step 5: Turn over the assembled unit in step Attached Slide top (A) to upper frame (C), push by hand as shown. Step 6: Insert bolt (4) into upper frame (C) pre-drilled holes , tighten by using screwdriver (not included) as shown.
- Page 7 Step 7: Close up the Sliding top , Now your Slide-Top End Table is ready to use. Top interior Supports up to 50 lb. Bottom/open shelf Supports up to 20 lb...
-
Page 8: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
