MOTORIZED TREADMILL – MODEL V100
INSTRUCTION MANUAL
Please read these instructions carefully before use and keep for future reference
FOR DOMESTIC INDOOR USE ONLY
WARNING: Keep young children away from this machine at all times. Contact with
the moving surface may result in severe friction burns.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V100 and is the answer not in the manual?

Questions and answers

Related Manuals for Powertrain V100

Summary of Contents for Powertrain V100

  • Page 1 MOTORIZED TREADMILL – MODEL V100 INSTRUCTION MANUAL Please read these instructions carefully before use and keep for future reference FOR DOMESTIC INDOOR USE ONLY WARNING: Keep young children away from this machine at all times. Contact with the moving surface may result in severe friction burns.

  • Page 2: Safety Notice

    1. CAUTION To avoid injuries please read this manual carefully before using the treadmill.  Before starting any exercise program you should consult your doctor to determine if you have any physical or health conditions which could create a risk to your health and safety, or prevent you from using the equipment properly.

  • Page 3: Product Specifications

    3. CAUTION PRIOR TO USE  Do not use the machine if you are unwell and immediately stop using the machine if you start feeling unwell whilst using it.  Disconnect the machine from power when not in use.  Prior to relocating or folding the machine, disconnect it from power. ...
  • Page 4 Main Specifications and Parts List Main Specifications Parameters Names Description Input power voltage AC220-240V(50/60Hz) Motor power 3.0HP Speed 1-20Km/h Packing list Name Units Treadmill Unit Accessory Bag Screws bag list Name Name Inner hexagon spanner 6mm MP3 cable Inner hexagon spanner 5mm Base Corner Cover 1 Set Combination wrench...
  • Page 5 attach the columns to the base of the treadmill (as shown in the diagram below.  Use an inner hexagon spanner (#5) and screw M8*25 to fix the console to the columns.  Use a screwdriver and insert M5*14 to fix the base corner covers to the columns, as shown in the below diagram.
  • Page 6 CAUTION: Ensure cables are not pinched or jammed as it will damage the unit and void warranty.  Place the exposed surplus cabling inside the case and mount the console on to the console slot. Adjust the position/angle. Insert screws M8*25 and tighten them as shown in Diagram B.

  • Page 7: Using The Treadmill

     Safety Key Function o Disconnecting the safety key will immediately stop the running track and the screen will display “E7”, and the treadmill will emit a beep. o Placing the safety key back on the designated area on the console will clear all data in 2 seconds.
  • Page 8 o In standby mode, pressing the Program key will cycle through the options, ranging from P1 to P12 (automatic programs) – FAT - P0 (Standby). o In standby mode, holding down this button will set the parameter values (refer below) ...

  • Page 9: Time Display

     Time Display o In running mode or set value: the display will show the time value (i.e., countdown time) o In standby mode: entering the FAT function will display Gender – Age – Height – Weight.  Distance/Calorie Display o Running Mode –...

  • Page 10: Error Codes

    Incline Speed Incline Speed Incline Speed Incline Speed Incline Error Codes Error code Description Solution Erroneous Connection: Possible Cause: the communication between the lower controller when the power is on, the and console is blocked, check each joint between the controller and connection between lower console, make sure that each core is fully plugged in.

  • Page 11: Maintenance

    7. Maintenance Warning: Before cleaning or carrying out any maintenance, ensure the treadmill is disconnected from power  Comprehensive cleaning will extend the life of your treadmill  Remove dust periodically in order to maintain all parts clean.  Be sure to clean running belt with both sides of the exposed portion, which will reduce the accumulation of impurities.
  • Page 12 o Frequent user (use more than 7 hours a week) - once a fortnight.  To safeguard your treadmill and extend the life of the unit, it is recommended that after 2 hours of continued use, the machine be switched off and allowed to cool for a minimum of10 minutes before using it again.

  • Page 13: Exercise Instructions

     Step 3: Lock the motor base, and re- install the front cover.  Exercise Instructions Using your Powertrain treadmill provides you with several benefits such improving your physical fitness, toning muscles and together with a calorie controlled diet may help you lose weight.
  • Page 14 Exercise Phase This is the stage where you put the effort in. After regular use, the muscles in your legs will become stronger. Work to your own pace, but it is very important to maintain a steady tempo throughout. The rate of work should be sufficient to raise your heart beat into the target zone shown on the graph below.
  • Page 15 Warranty and Contact Details Kmate Pty Ltd provides a 12 month warranty for this product when used for domestic purposes. This product is not intended for commercial use and any such use will void all warranty. The benefits of this warranty are provided in addition to other rights and remedies you may have under a law in relation to the goods and services to which this warranty relates.
