Micropilot FMR51, FMR52 FOUNDATION Fieldbus
Antenna size
Beam angle α
Distance (D)
3 m (9.8 ft)
6 m (20 ft)
9 m (30 ft)
12 m (39 ft)
15 m (49 ft)
20 m (66 ft)
25 m (82 ft)
30 m (98 ft)
35 m (115 ft)
40 m (131 ft)
45 m (148 ft)
60 m (197 ft)
70 m (230 ft)
Endress+Hauser
40 mm (1½ in)
23°
1.22 m (4 ft)
2.44 m (8 ft)
3.66 m (12 ft)
4.88 m (16 ft)
6.1 m (20 ft)
8.14 m (27 ft)
10.17 m (33 ft)
-
-
-
-
-
-
FMR51
50 mm (2 in)
18°
Beam diameter W
0.95 m (3.1 ft)
1.9 m (6.2 ft)
2.85 m (9.4 ft)
3.80 m (12 ft)
4.75 m (16 ft)
6.34 m (21 ft)
7.92 m (26 ft)
9.50 m (31 ft)
11.09 m (36 ft)
12.67 m (42 ft)
-
-
-
80 mm (3 in) 100 mm (4 in)
10°
0.53 m (1.7 ft) 0.42 m (1.4 ft)
1.05 m (3.4 ft) 0.84 m (2.8 ft)
1.58 m (5.2 ft) 1.26 m (4.1 ft)
2.1 m (6.9 ft) 1.68 m (5.5 ft)
2.63 m (8.6 ft) 2.10 m (6.9 ft)
3.50 m (11 ft) 2.80 m (9.2 ft)
4.37 m (14 ft) 3.50 m (11 ft)
5.25 m (17 ft) 4.20 m (14 ft)
6.12 m (20 ft) 4.89 m (16 ft)
7.00 m (23 ft) 5.59 m (18 ft)
7.87 m (26 ft) 6.29 m (21 ft)
10.50 m (34 ft) 8.39 m (28 ft)
- 9.79 m (32 ft)
Mounting
8°
