ASSEMBLY INSTRUCTIONS
Final Installation
17. Snap end caps (B) onto top and bottom of
mounting arm (A).
18. Place mounting plate (E) onto mounting arm (A).
19. Secure mounting plate (E) to mounting arm (A) with
the two previously removed mounting arm
screws (PP).
Note: DO NOT fully tighten mounting arm screws (PP).
Tighten ONLY to snug tension.
Hardware Used
PP
Mounting arm screw
17
A
18
E
A
19
A
x 2
13
B
E
PP
