400 Floorstanding Cloakroom
Assembly Instructions -
Dimensions
Width - 40cm
Depth - 22cm
Height - 82.8cm
Important -
Please read these instructions fully before starting assembly
For all enquiries please contact : 0333 241 2701
Please keep for future reference
609865
609874
Ref. no BTOFST002 Date: 04/2021
Advertisement
Related Manuals for Homebase 609865
Summary of Contents for Homebase 609865
- Page 1 400 Floorstanding Cloakroom Assembly Instructions - 609865 Please keep for future reference 609874 Dimensions Width - 40cm Depth - 22cm Height - 82.8cm Important - Please read these instructions fully before starting assembly For all enquiries please contact : 0333 241 2701...
- Page 2 Safety and care advice Getting started - Please read these intructions fully before starting assembly • Check the pack and make • Warning: sure that you have all parts. Serious or fatal crushing If not contact your local store injuries can occur from furni- who will be able to help you.
- Page 3 Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Washer x 2 Bump x 2 Cover x 4 Bracket x 2 Cover x 2 15mm Screw x 4...
- Page 4 Assembly Instructions Step 1 Fix the bracket Step 2 Mark the location of the bracket against the wall...
-
Page 5: Care And Maintenance
A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure. - Page 6 Assembly Instructions Step 3 Fix wall anchor into the wall Ø8 x 2 (not included) Step 4 Fix the bracket to the wall x 2 (not included)
- Page 7 Assembly Instructions Step 5 Insert cover Step 6 Fix the clip hunge Door...
- Page 8 Assembly Instructions Step 7 Fix hinge mounting plate...
- Page 9 Assembly Instructions Step 8 Fix the door “CLICK”...
- Page 10 Assembly Instructions Step 9 A Fix push latch...
- Page 11 Assembly Instructions tep 9 A Soft closing deactivation tep 9 A Push latch adjustment...
- Page 12 Assembly Instructions Step 9 B Fix the handle handle not included handle not included...
- Page 13 Assembly Instructions tep 9 B Soft closing setting...
- Page 14 Assembly Instructions Step 10 Insert shelf Shelf Shelf Step 11 Remove protective films and insert washbasin washbasin not included...
- Page 15 Assembly Instructions Step 12 Remove protective films Step 13 Adjustment door...
- Page 16 Assembly Instructions Step 14 Total max weight of shelves loading 3kg each...
-
Page 17: Cleaning Instructions
Assembly Instructions That's the Stool completed. Take care of your unit by using a damp cloth to clean it. Please remember to occasionally check that all Cams and Screws are tight. CLEANING INSTRUCTIONS This product has been manufactured using modern manufacturing methods and materials.
