Roberts Sports 995 Manual

W h a t i s i n t h e Bo x ?
Personal radio, stereo earphones, quick start guide and safety/warranty leaflet.
Features
MW (AM) / FM stereo wavebands, standby mode clock, 15 direct access presets, scan tuning, manual tuning, auto power off, deep
bass boost function, lock switch, FM stereo/mono switch, stereo earphones, batteries 2 x LR03 / AAA size (not included).
Controls
1 Mono/Stereo / Time Set button
3
2 Deep bass boost / Step button
3 LCD display
4 Tuning Up button
5 Tuning Down button
6 Volume Down button
2 4
7 Volume Up button
SET
8 Strap holder
1 5
9 Power / Band button
10 Lock switch
11 Battery compartment
C D E F
G
A. Waveband indicator
ST
B. Battery power indicator
B
H
C. Signal strength indicator
A D. FM Stereo indicator
E. 90 minute auto shut off indicator
I
Battery operation
1 Open the battery cover by sliding it in the direction shown by the arrow.
2 Insert two LR03 (AAA) size batteries into the compartment. Ensure that batteries
are inserted in accordance with the diagram shown inside the battery compartment
and close the battery cover.
3 Batteries should be replaced when the low battery indicator
appears on the display.
4 During battery replacement ensure that the radio is turned off and the Lock switch
is in the 'Lock' position. Battery replacement should be completed within three
minutes to prevent loss of stations stored in memory presets.
5 If the radio is not to be used for a long period, set the Lock switch to the 'Lock'
position, this will reduce power drain on the batteries during storage. Reduced power,
distortion and a 'stuttering' sound are all signs that the batteries may need replacing.
If the radio is not to be used for an extended period of time it is recommended that
the batteries are removed from the radio.
Important: The batteries should not be exposed to excessive heat such as sunshine, fire
or the like. After use, disposable batteries should if possible be taken to a suitable recycling
centre. On no account should batteries be disposed of by incineration.
Caution: Replace batteries only with the same or equivalent type. Danger of explosion if
the batteries are incorrectly replaced.
8
12
7
9
6
12 Earphone socket
10
13 Memory preset buttons (1 - 5)
14 Earphones
READ
SAFETY
Frequency Range GUIDE
FM: 87.5-108 MHz
AM: 520 - 1710 kHz
Battery: 2x 1.5V AAA
Roberts Radio Ltd,
Stoney Lane, Whiston,
Prescot, L35 2XW, UK
Glen Dimplex Europe Ltd,
Airport Road, Cloghran,
14
Co. Dublin, K67 VE08, Ireland
Designed & Engineered in the UK,
11
Made in China
F. Lock indicator
G. Memory preset indicator
H. Deep bass boost indicator
I. Time / Frequency indicator
flashes and 'E'
READ
SAFETY
Frequency Range GUIDE
FM: 87.5-108 MHz
AM: 520 - 1710 kHz
Battery: 2x 1.5V AAA
Roberts Radio Ltd,
Stoney Lane, Whiston,
Prescot, L35 2XW, UK
Glen Dimplex Europe Ltd,
Airport Road, Cloghran,
Co. Dublin, K67 VE08, Ireland
Designed & Engineered in the UK,
Made in China
Lock switch
The Lock switch is used to prevent unintentional operation of your radio.
1 Set the Lock switch located on the back of your radio to the 'Lock' position. The power
and all other buttons will be disabled, this will prevent accidental operation when your
radio is packed in a suitcase or travel bag.
2 To prevent accidental operation of the controls when your radio is switched on, set the
Lock switch to the left 'Lock' position, the
3 To release the Lock switch, move the lock switch to the right 'Unlock' position, the
symbol will be removed from the display.
13
Earphones
Plug the earphones into the Earphone socket located on the top of your radio. Check that the
volume is not set too loud and place the earpieces into your ears. IMPORTANT: Excessive
sound pressure from earphones and headphones can cause hearing loss. To prevent possible
hearing damage, do not listen at high volume levels for long periods.
The lead connecting earphones to your radio acts as an FM aerial when plugged into the
Earphone socket. The lead should be extended as much as possible to increase reception.
For MW (AM) reception there is a built in ferrite aerial. Rotate your radio to the position
giving best reception.
Setting the time
1 After inserting the batteries your radio will show 12:00 until the correct time is
set. The time is shown using the 12 hour clock format.
2 To set the correct time, press and hold the Time Set button for 2 seconds and
then release. The hour digits will flash on the display.
3 Press and release the Tuning Up or Down buttons to choose the desired hour
and then press and release the Time Set button. The minute digits will flash
on the display. Press and release the Tuning Up or Down buttons to choose
the desired minute and then press and release the Time Set button to confirm
the time setting.
• Press and hold the Tuning Up or Down buttons to advance the time quickly.
Scan tuning
The earphone lead should be extended as much as possible to increase FM reception.
For MW (AM) reception there is a built in ferrite aerial. Rotate your radio to the
position giving best reception.
Press and release the Power / Band button to switch on your radio.
1
2 Press and release the Power / Band button until the desired waveband FM1,
FM2 or MW(AM) is selected.
3 Press and hold the Tuning Up button for 2 seconds and then release the button
your radio will scan in an upwards direction (low frequency to high frequency)
and stop automatically when it finds a station of sufficient strength.
4 To find other stations press the Tuning Up button as before.
5 To scan the band in a downwards direction (high frequency to low frequency)
press and hold the Tuning Down button for 2 seconds and then release the
button. When the waveband end is reached your radio will recommence tuning
from the opposite waveband end. Adjust the Volume to the required setting.
6 To switch off your radio press and hold the Power / Band button.
Manual tuning
1 Press and release the Power / Band button to switch on your radio. To select the required waveband repeatedly press the
Power / Band button. Press and release the Tuning Up or Down buttons to tune to a station. With each press the frequency
will advance in the following increments. FM 50kHz or 100kHz (see choosing step size overleaf) MW (AM) 9kHz or 10kHz
(see choosing step size overleaf). Adjust the Volume to the required setting.
S T E P 1 - B e f or e u s in g y o ur r a d io
symbol will appear in the display.
S T E P 2 - O p e r a t in g y o ur r a d io
SET
ST
continued overleaf...
