Roborock S7 Pro Ultra User Manual page 14

C16-2— Remove the water filter and wipe off
any water marks with a cloth.
C16-3— Carefully place the the dock upside
down on a hard floor covered with
a soft towel.
C16-4— Unscrew the eight screws and
remove the cover.
C16-5— Wipe the air duct and duct cover
with a dry cloth.
C16-6— Re-install the cover and screw it
back in place.
Basic Parameters
Robot
Model S300RR
14.4V/5200mAh
Battery
lithium-ion battery
Rated Input 20VDC 1.8A
Charging Time < 6 hours
Note: The serial number is on a sticker on the underside of
the robot.
Empty Wash Fill Dock
Model EWFD01LRR, EWFD02LRR
Rated Input Voltage 120VAC
Rated Frequency 50-60Hz
Rated Input
9.5A
(Dust Collection)
Rated Input (Charge) 0.75A
Rated Output 20VDC 1.8A
14.4V/5200mAh
Charging Battery
lithium-ion battery
13
