Rear-view camera input.
-
Front-view camera input.
-
Provides three AV Inputs.
-
Front-view camera and AV Inputs can still be used even if vehicle is equipped with an
OEM rear view camera.
-
With OE type Dynamic Parking Guidelines.
-
Toggle AV inputs from Comand knob, wireless remote control or wired push button
switch provided.
-
On-screen display and setup.
Mercedes Benz
2016 - 2017
- Works on Mercedes Benz E Class with NTG5.5 systems and 12.3" or 8.4" screens.
12.3" Screen
E Class
1 / 10
8.4" Screen
rev.012217
Advertisement
Related Manuals for Crux RVCMB-78E
Summary of Contents for Crux RVCMB-78E
- Page 1 Rear-view camera input. Front-view camera input. Provides three AV Inputs. Front-view camera and AV Inputs can still be used even if vehicle is equipped with an OEM rear view camera. With OE type Dynamic Parking Guidelines. Toggle AV inputs from Comand knob, wireless remote control or wired push button switch provided.
- Page 2 RGB Cable RGB Cable IR OUT Cable AV Harness CAP Touch Cable Uart Touch Cable Selector Button IR Cable Remote Control TOUCH IN Cable 2 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
- Page 3 Rear View Integration Interface for MERCEDES BENZ E CLASS NTG5.5 Navigation (Not Included) Mode button connection IR cable Capa citive touch screen REAR FRO NT CANERA CANERA 3 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
-
Page 4: Installation
Then, another side of connector shall be connected to the LVDS IN of the interface LVDS IN Cable 4 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188... - Page 5 OEM wire Connect the red B+ wire of the supplied power cable to the orange/blue OEM wire 5 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
-
Page 6: Dip Switch Settings
(Press this button for 2 seconds to access the factory mode.) RIGHT (Press this button for 2 seconds to reset all the user settings.) 6 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188... - Page 7 F-CAM ENABLE: Front camera setting - OEM CAMERA : Select OEM front camera - EXT CAMERA : Select aftermarket front camera - NOT USED 7 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
- Page 8 IMAGE SYST EM VERSION PARK UT IL1 (MAIN - 130723) UT IL2 (T RIP - 130723) INFO MENU to Retur n SEL to Select/Save 8 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
- Page 9 NAVI button Long press : Switch mode Short press: Back to OEM mode BACK button Long press: Switch mode Short press: Back to OEM mode 9 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
- Page 10 DVD, DTV mode) Push Monitor Direction Mode Movement Comand Knob Short UP,DOWN,LEFT,RIGHT 12.3 inch / 8.4 inch Long Select 10 / 10 rev.012217 Crux Interfacing Solutions tel. #: (818) 609-9299 www.cruxinterfacing.com fax #: (818) 996-8188...
