SPA POOL PUMP
Installation and
Operating Instructions
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
The installation of this product should be carried out by a person knowledgable in
spa pool plumbing requirements following the Installation Instructions provided in
this manual.
Please pass these instructions on to the operator of this equipment.
QB SERIES
Advertisement
Table of Contents
Related Manuals for Davey QB Series
Summary of Contents for Davey QB Series
- Page 1 QB SERIES SPA POOL PUMP Installation and Operating Instructions WARNING: Failure to follow these instructions and comply with all applicable codes may cause serious bodily injury and/or property damage. The installation of this product should be carried out by a person knowledgable in spa pool plumbing requirements following the Installation Instructions provided in this manual.
-
Page 2: Installation Diagram
Pool and Spa Equipment. You are assured of many years of reliable and efficient performance from your Davey QB Series backed by Davey’s two year guarantee. Davey QB Series have been designed to circulate swimming pool and spa water in conditions set out in the Australian Standard for swimming pool water quality (AS 3633) or equivalent. -
Page 3: Power Connection
Davey QB Series are suitable for connection to a nominal 240 volt 50Hz power supply and are equipped with a flex lead and 3 pin plug or AMP plug to allow connectability to a Davey Spa controller. If a power outlet is not available within 3 metres of the pump, a 3 pin power point in a safe, dry place, may need to be provided by an electrician. -
Page 4: Pipe Connection
If the pump and filter are located below pool water level, it is necessary to fit isolating valves in the pipe between the pump and the skimmer box or suction inlet and in the return pipe from the filter to the pool. Warning! Ensure that an electrical isolation switch is located with easy access so that the pump can be switched off in an emergency. -
Page 5: Troubleshooting
4. Move the pipework with the barrel unions attached until the pump can be pulled clear. NOTE: When making any enquiries about your Davey QB Series be certain to quote the model number from the nameplate located on motor. -
Page 6: Pump Dimensions
15.7 50/50 QB2002 14.7 QB2502 431 235 202 15.9 QB3002 Note: Available in either thread pitch 3.175mm FBT or Davey 4.23mm FBT. See Thread Type table. THREAD TYPE Thread Type Type (Available) 40mm FBT QB035, QB1501 (Pitch 3.175mm) QB2001AUS, QB2501AUS,... - Page 7 DANGER - Hazardous suction. Do not block water entry into filtration system with any part of your body as the pressure can trap hair or body parts, causing severe injury or death. Do not block suction. Turn off pump immediately if someone becomes trapped.
-
Page 8: Davey Repair Or Replacement Guarantee
Customer Service line on 1300 367 866 in Australia, or 0800 654 333 in New Zealand, or send a written letter to Davey at the address listed below. On receipt of your claim, Davey will seek to resolve your difficulties or, if the product is faulty or defective, advise you on how to have your Davey product repaired, obtain a replacement or a refund.
