USER MANUAL
Saved 11/16/2021
By
®
Parvus
DuraNET 20-11
Rugged 8-Port Managed Layer 2+ Gigabit Ethernet Switch
MNL-0656-01 Rev A8
ECO-N/A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Parvus DuraNET 20-11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Curtiss-Wright Parvus DuraNET 20-11

Summary of Contents for Curtiss-Wright Parvus DuraNET 20-11

  • Page 1 USER MANUAL Saved 11/16/2021 ® Parvus DuraNET 20-11 Rugged 8-Port Managed Layer 2+ Gigabit Ethernet Switch MNL-0656-01 Rev A8 ECO-N/A...
  • Page 2 Curtiss-Wright reserves the right to change the contents and form of this document, as well as the features and specifications of its products, at any time without notice.

  • Page 3: Table Of Contents

    Curtiss-Wright Parvus DuraNET 20-11 ABLE OF ONTENTS Chapter 1 Introduction ......................6 About This Document ............................ 6 Description of Safety Symbols ........................ 6 Functional Description ........................... 7 Features ..............................8 Small Form Factor Ethernet Switch ....................8 Management ............................ 8 Rugged MIL-STD Design .........................
  • Page 4 Parvus DuraNET 20-11 Curtiss-Wright Chapter 5 Specifications ....................... 33 Technical Specifications ..........................33 Architecture ............................33 Ports ..............................33 Layer 2 Switching ..........................33 Layer 3 Routing ............................ 33 Management ............................34 Security ..............................34 Reliability .............................. 34 Breakout Cable Set ..........................34 Mechanical Specifications ...........................
  • Page 5 Curtiss-Wright Parvus DuraNET 20-11 IST OF IGURES Figure 1. DuraNET 20-11 Block Diagram ....................9 Figure 2. Management Interface Block Diagram ..................10 Figure 3. Front View ........................... 11 Figure 4. Bottom View ..........................12 Figure 5. Breakout Cable Set (CBL-NET-20-11-01) .................. 14 Figure 6.

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction Parvus DuraNET 20-11 Curtiss-Wright HAPTER NTRODUCTION The DuraNET 20-11 is an ultra-miniature, rugged, 8-port managed Layer 2 Gigabit network switch. It contains a MIL-STD-1275/704 power supply in an IP67 (dust/water proof) sealed aluminum chassis with micro-miniature MIL-DTL-38999 like connectors.

  • Page 7: Functional Description

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 1 Introduction UNCTIONAL ESCRIPTION The DuraNET 20-11 is a rugged Commercial Off the Shelf (COTS) Gigabit Ethernet switch subsystem optimized for Size, Weight, Power and Cost (SwaP-C) sensitive embedded military and civilian computer network systems applications...

  • Page 8: Features

    Chapter 1 Introduction Parvus DuraNET 20-11 Curtiss-Wright EATURES Small Form Factor Ethernet Switch  8 ports of 10/100/1000Mbps Gigabit Ethernet in size, weight & power (SWaP) optimized chassis: approx. 0.5 lbs. weight, less than 10.0 cubic inches, and less than 8 watts max power ...

  • Page 9: Configurations

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 1 Introduction ONFIGURATIONS The DuraNET 20-11 is available with electroless-nickel-plated micro-miniature MIL-DTL-38999 like connectors and the 20-12 is available with standard Glenair quadrax inserts for enhanced signal integrity. The DuraNET 20-12 is documented in a separate manual.

  • Page 10: Management Interface Overview

    Chapter 1 Introduction Parvus DuraNET 20-11 Curtiss-Wright ANAGEMENT NTERFACE VERVIEW The DuraNET 20-11 provides two types of user interfaces for switch configuration and management: a serial command line interface (CLI) via RS-232 serial port, and a Web GUI via Ethernet. Each management interface on the card connects to a host PC which acts as the console.

  • Page 11: Chapter 2 Operational Description

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 2 Operational Description HAPTER PERATIONAL ESCRIPTION This chapter describes how to connect and power-up the DuraNET 20-11. ONNECTOR DENTIFICATION RONT ANEL Figure 3 shows the front view of the DuraNET 20-11 and the three connectors.

  • Page 12: Bottom View

    Chapter 2 Operational Description Parvus DuraNET 20-11 Curtiss-Wright OTTOM Figure 4 shows the bottom view of the system with the mounting screw locations that are also used for grounding. Refer to "Grounding" (page 18) for grounding instructions. Figure 4. Bottom View...

  • Page 13: Test Equipment Installation

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 2 Operational Description QUIPMENT NSTALLATION To use the DuraNET 20-11 in a lab environment, recommended equipment includes:  Appropriate cables, such as the CBL-NET-20-11-01 Breakout Cable Set  A power source applied at connector J1, 5-36VDC input, 28V nominal. A power cable is included with the Breakout Cable Set.

  • Page 14: Figure 5. Breakout Cable Set (Cbl-Net-20-11-01)

    Chapter 2 Operational Description Parvus DuraNET 20-11 Curtiss-Wright Figure 5. Breakout Cable Set (CBL-NET-20-11-01) Page 14 of 44 MNL-0656-01 Rev A8 ECO-N/A Effective: 16 Nov 21...

  • Page 15: Power-On Sequence

    Note: These instructions explain how to set up the DuraNET 20-11 using the cables from the Parvus DuraNET 20-11 cable set (CBL-NET-20-11-01). If you have a custom setup and customer-designed cables, modify these instructions as needed.

  • Page 16: Mounting The Duranet 20-11

    Chapter 2 Operational Description Parvus DuraNET 20-11 Curtiss-Wright NET 20-11 OUNTING THE After testing is complete, you can mount the DuraNET 20-11 vertically or horizontally. HERMAL ONSIDERATIONS FOR HOOSING A OUNTING OCATION The DuraNET 20-11 enclosure is highly efficient at removing heat from the components inside of the unit to the case.

  • Page 17: Alternate Mounting

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 2 Operational Description LTERNATE OUNTING Optional mounting brackets may be designed to attach to the unit (example shown: MCH-2562-01). Note: MCH-2562-01 is comprised of two feet. CLEARANCE FOR #6 SCREWS Figure 7 Alternate Mounting Feet...

  • Page 18: Grounding

    Chapter 2 Operational Description Parvus DuraNET 20-11 Curtiss-Wright ROUNDING  The bottom of the baseplate is conductive to allow the system to be grounded via the baseplate.  Four holes are provided for grounding/mounting. Refer to figure 8 below. These are 6-32 holes that are approximately 0.47”...

  • Page 19: Chapter 3 Management Interface Description

    Chapter 3 Management Interface Curtiss-Wright Parvus DuraNET 20-11 Description HAPTER ANAGEMENT NTERFACE ESCRIPTION The DuraNET 20-11 management interfaces provide the network administrator with a set of comprehensive management functions. The network administrator has a choice of two easy-to-use management interfaces: ...

  • Page 20: Using The Cli

    Chapter 3 Management Interface Parvus DuraNET 20-11 Curtiss-Wright Description SING THE This section describes basic usage and configuration of the command line interface (CLI) for the DuraNET 20-11. The CLI interface is an industry-standard CLI and consists of configuration commands which provide the ability to configure and view the configuration using the serial console, or Telnet or SSH access.

  • Page 21: Zeroization

    Chapter 3 Management Interface Curtiss-Wright Parvus DuraNET 20-11 Description EROIZATION For data security, the DuraNET 20-11 provides zeroization capability which erases all user configurable data on the system. Not all data contained in Non-volatile memory is erased, the system software persists through zeroization.

  • Page 22: Cli Command Groups

    Chapter 3 Management Interface Parvus DuraNET 20-11 Curtiss-Wright Description CLI C OMMAND ROUPS CLI commands can be grouped into the following functional categories:  Manage and show switch settings.  Manage configuration and firmware files.  Manage system.  Manage Parvus extensions.

  • Page 23: Using The Web Gui

    Chapter 3 Management Interface Curtiss-Wright Parvus DuraNET 20-11 Description SING THE The web-based software management method allows the network administrator to configure, manage, view, and control the switches remotely. The GUI also provides help pages to assist the switch administrator in understanding GUI configuration. SNMP management is standards-based, with configuration parameters specified in the supported MIBs.

  • Page 24: Web Gui Introduction

    Chapter 3 Management Interface Parvus DuraNET 20-11 Curtiss-Wright Description GUI I NTRODUCTION This section explains how to access the web GUI, navigate to pages, access help, and display details. Accessing the Web Interface Once the IP address of the switch VLAN 1 is set up, you can use the Web GUI to manage the switch.
  • Page 25 Chapter 3 Management Interface Curtiss-Wright Parvus DuraNET 20-11 Description MNL-0656-01 Rev A8 ECO-N/A Effective: 16 Nov 21 Page 25 of 44...

  • Page 26: Navigation Pane

    Chapter 3 Management Interface Parvus DuraNET 20-11 Curtiss-Wright Description Navigation Pane The navigation pane selects what is displayed in the work area. The pane is organized into categories (Configuration, Monitor, Diagnostics, and Maintenance) and subcategories (such as System, Green Ethernet, and Ports under Monitor). The categories and subcategories are just navigation tools—they aren't displayed in the work area.

  • Page 27: Firmware Alternate

    Chapter 3 Management Interface Curtiss-Wright Parvus DuraNET 20-11 Description IRMWARE LTERNATE Alternate Firmware SFT-0856-01 is the 3.67 firmware release for the DuraNET 20-11. All DuraNET 20-11 are shipped out with 3.30 firmware release. All NET-2011 will be shipped out with 3.67 firmware as the alternate image which can be activated when selected by going to the WEB GUI page as shown below going to Maintenance ->...
  • Page 28 Chapter 3 Management Interface Parvus DuraNET 20-11 Curtiss-Wright Description 6. Test out the new firmware and if need to switch back to the old firmware just activate the old image by going to the WEB GUI page as shown below going to Maintenance -> Software ->...

  • Page 29: Chapter 4 Connector Descriptions

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 4 Connector Descriptions HAPTER ONNECTOR ESCRIPTIONS This chapter identifies connector part numbers, locations, and pinouts to facilitate fabrication of cables that can connect to the DuraNET 20-11. ONNECTOR UMBERS The following table shows the manufacturer part numbers for the DuraNET 20-11 connectors (identified in Figure 10), together with the suggested mating connectors.

  • Page 30: Pinouts

    Curtiss-Wright INOUTS This section provides the pinouts necessary for creating cables that connect properly to this assembly. If custom cabling is not designed and built by Curtiss-Wright, all EMI and EMC considerations must be handled by the customer. J0 P...

  • Page 31: J1 Gigabit Ethernet (Port 1-4)

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 4 Connector Descriptions J1 G 1-4) IGABIT THERNET J1 is a 37 pin socket connector used to bring out four GigE ports. Four twisted pairs are used for each GigE port (8 pins total). This documentation refers to these pairs as a pair (GbEn_A_P / GbEn_A_N, GbEn_B_P / GbEn_B_N, GbEn_C_P / GbEn_C_N, GbEn_D_P / GbEn_D_N) where n = a port number from 1 to 4.

  • Page 32: J2 Gigabit Ethernet (4 Port), Console & Zeroize

    Chapter 4 Connector Descriptions Parvus DuraNET 20-11 Curtiss-Wright J2 G (4 P ), C & Z IGABIT THERNET ONSOLE EROIZE J2 is a 37 pin socket connector with four GigE ports brought out on it. Four twisted pairs are used for each GigE port (8 pins total).
  • Page 33 Curtiss-Wright Parvus DuraNET 20-11 Chapter 5 Specifications HAPTER PECIFICATIONS ECHNICAL PECIFICATIONS RCHITECTURE  Packet processor: Vitesse Carrier Grade Ethernet Switch Engine  Switching: Non-Blocking OSI Data Layer 2, IPv4 / IPv6 Multicast, Low-Latency, Auto-MDI/MDIX, Auto- Negotiation, Auto-Detect; Speed Auto-Sensing, Auto-Crossover, Full/Half Duplex Modes, ...
  • Page 34 Chapter 5 Specifications Parvus DuraNET 20-11 Curtiss-Wright ANAGEMENT  In-band Ethernet management using Web GUI, Simple Network Management Protocol (SNMP), or command line interface (CLI) over RS-232 console for Telnet / SSH / Terminal  HTTP/HTTPS Web Server, SNMP v1 / v2 / v3 Client, DHCP Client, IEEE 802.1X Authentication, System Syslog, SSHv2, IPv6 Management, IGMP/MLD/DHCP Snooping , Access Control Lists, Port Mirroring, BPDU Guard, RMON, Cisco Discovery Filtering, IEEE-802.10AB LLDP...

  • Page 35: Figure 11. Top View Dimensions

    Curtiss-Wright Parvus DuraNET 20-11 Chapter 5 Specifications ECHANICAL PECIFICATIONS OWER  Power input: 28 VDC nominal steady state; input range: 5-36VDC  MIL-STD-704F & MIL-STD-1275D compliant: steady state voltage, ripple, surges, spikes  Power consumption (estimated): < 8 watts maximum ...
  • Page 36 Chapter 5 Specifications Parvus DuraNET 20-11 Curtiss-Wright HYSICAL  Weight: ~0.5 lbs.  Installation: base flange mount  Connectors: micro-miniature MIL-DTL-38999 like connectors (Glenair 2M series)  Cooling: passive natural convection without forced air or fans; no moving parts ...
  • Page 37 Curtiss-Wright Parvus DuraNET 20-11 Chapter 6 Troubleshooting HAPTER ROUBLESHOOTING RODUCT DENTIFICATION The product is labeled with the Parvus P/N and serial number. Please refer to this information when communicating with Technical Support. ECHNICAL SSISTANCE If you have a technical question or if you cannot isolate a problem with your product, please call or e-mail...
  • Page 38 Chapter 7 Contact Info Parvus DuraNET 20-11 Curtiss-Wright HAPTER ONTACT Company Contact Info: Defense Solutions Division Curtiss-Wright 3222 S. Washington St. Salt Lake City, Utah, USA 84115 (801) 483-1533 FAX (801) 483-1523 Website: www.curtisswrightds.com Sales: +1(800) 483-3152 or (801) 483-1533 slp_sales@curtisswright.com...
  • Page 39 Curtiss-Wright Parvus DuraNET 20-11 Appendix A – EAU Information A – EAU I PPENDIX NFORMATION Early Access units (EAUs) were made before the final production design was completed have a slightly different connector configuration. The design details for the EAUs are captured in this appendix.
  • Page 40 Appendix A – EAU Information Parvus DuraNET 20-11 Curtiss-Wright Page 40 of 44 MNL-0656-01 Rev A8 ECO-N/A Effective: 16 Nov 21...
  • Page 41 Appendix A – EAU Information INOUTS This section provides the pinouts necessary for creating cables that connect properly to this assembly. If custom cabling is not designed and built by Curtiss-Wright, all EMI and EMC considerations must be handled by the customer. ONNECTOR...
  • Page 42 Appendix A – EAU Information Parvus DuraNET 20-11 Curtiss-Wright J1 G 1-4), P , & Z IGABIT THERNET OWER EROIZE J1 is a 37 pin socket connector with four GigE ports brought out on it, as well as power and a zeroize port.
  • Page 43 Curtiss-Wright Parvus DuraNET 20-11 Appendix A – EAU Information J2 G (4 P ), C IGABIT THERNET ONSOLE J2 is a 37 pin socket connector with four GigE ports brought out on it. Four twisted pairs are used for each GigE port (8 pins total). This documentation refers to these pairs as a pair (GbEn_A_P / GbEn_A_N, GbEn_B_P / GbEn_B_N, GbEn_C_P / GbEn_C_N, GbEn_D_P / GbEn_D_N) where n = a port number from 5 to 8.
  • Page 44 Appendix A – EAU Information Parvus DuraNET 20-11 Curtiss-Wright {Parvus back cover, 8.5 x 11 picture inserted in front of text. DO NOT DELETE THE COMMENTS OR THIS PAGE. These comments are only visible in Normal view. The picture hides these comments when you print the manual or view it in Print Layout or Print Preview.}...
