Installation

Have the included screws and the ap-
propriate screwdriver ready.
Before initial startup, mount the loose
enclosed parts on the device.
Mounting the wheels
1. Plug in the wheels.
Note
Pay attention to the alignment of the
hole.
2. Secure the wheels with 1 screw
each.
Mounting the stand
1. Insert the stand.
2. Insert the 2 dowels into the holes as
far as they will go.
3. Secure the stand with 2 screws.
Mounting the storage for spray
1. Hook in the storage for the spray
lances.
2. Secure the storage with 2 screws.
3. Secure the cover with 4 screws.
Mounting the transport handle
1. Attach the transport handle.
2. Secure the transport handle with 2
screws.
English
lances
9
