Type 8020
Flowmeter with paddle wheel
Operating Instructions
Bedienungsanleitung
Manuel d'utilisation
1.
ABOUT THIS MANUAL ........................................... 3
2.
INTENDED USE ...................................................... 5
3.
BASIC SAFETY INFORMATION .............................. 6
4.
GENERAL INFORMATION ...................................... 9
5.
DESCRIPTION ....................................................... 10
6.
TECHNICAL DATA ................................................. 13
7.
8.
MAINTENANCE ..................................................... 33
9.
ACCESSORIES ..................................................... 36
10. PACKAGING, TRANSPORT .................................. 37
11. STORAGE .............................................................. 37
12. DISPOSAL OF THE PRODUCT............................. 38
English
2
We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
www.burkert.com
© Bürkert SAS, 2010 - 2022
Operating Instructions 2205/04_EU-ML 00419607/Original_EN
1.
ABOUT THIS MANUAL
This manual describes the entire life cycle of the device.
Please keep this manual in a safe place, accessible to all
users and any new owners.
This manual contains important safety information.
Failure to comply with these instructions can lead to
hazardous situations.
This manual must be read and understood.
Symbols used
DANGER
Warns against an imminent danger.
Failure to observe this warning can result in death or
in serious injury.
WARNING
Warns against a potentially dangerous situation.
Failure to observe this warning can result in serious
injury or even death.
English
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8020 and is the answer not in the manual?

Questions and answers

Summary of Contents for Burkert 8020

  • Page 1: Table Of Contents

    Type 8020 Flowmeter with paddle wheel We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Operating Instructions www.burkert.com Bedienungsanleitung © Bürkert SAS, 2010 – 2022 Manuel d'utilisation Operating Instructions 2205/04_EU-ML 00419607/Original_EN ABOUT THIS MANUAL ........... 3 ABOUT THIS MANUAL This manual describes the entire life cycle of the device.
  • Page 2: Intended Use

    INTENDED USE CAUTION Warns against a possible risk. Use of the device that does not comply with the Failure to observe this warning can result in sub- instructions could present risks to people, nearby stantial or minor injuries. installations and the environment. NOTE liquids free of solid particles.
  • Page 3: General Information

    Do not touch any of the live electrical components. English English DESCRIPTION The device is made up of an electronic module and of a FLOW:8020-FKM-PVDF HALL LONG 12-36VDC OUT:OPENCOL.NPN/PNP S-N:21219 419589 W48LG power supply...
  • Page 4: Technical Data

    TECHNICAL DATA module The electrical connection of all the devices is made Ambient temperature Air humidity Protection rating IP65, female connector wired, plugged and tightened The applied standards, which verify conformity with NPN and regulated energized via Conformity to the Pressure Equipment Directive the Bürkert Power, short transmitter the...
  • Page 5 Measurement deviation please refer to the technical data sheets regarding • with standard • country.burkert.com K-factor • with Teach-In • Linearity Repeatability Fluid temperature upstream and downstream distances respected, appropriate pipe pressure dependency curves for dimensions the device. See •...
  • Page 6: Installation And Commissioning

    INSTALLATION AND DANGER COMMISSIONING Risk of injury due to electrical voltage. Shut down and isolate the electrical power source before carrying out work on the system. DANGER Observe all applicable accident protection and safety Risk of injury due to high pressure in the installation. regulations for electrical equipment.
  • Page 7 Flow rate US gpm l/min • 100000 20000 5000 DN 400 • 50000 DN 350 10000 2000 DN 300 30000 DN 250 20000 5000 1000 DN 200 DN 150 10000 2000 DN 125 5000 DN 100 1000 • 3000 DN 80 2000 DN 65 DN 50 (DN65)*...
  • Page 8 Insert the cable into pressure pulling gently on the cable so that the wires do not clutter the housing. 0 V DC Power supply 12-36 V DC correct electrical contact. English English 0 V DC IN = pulse input on remote transmitter Power supply 12-36 V DC Remote transmitter...
  • Page 9: Maintenance

    MAINTENANCE DANGER Risk of injury due to electrical voltage. Shut down and isolate the electrical power source before carrying out work on the system. IN = pulse input on remote transmitter Observe all applicable accident protection and safety regulations for electrical equipment. Remote transmitter Risk of injury due to high pressure in the installation.
  • Page 10: Accessories

    ACCESSORIES 10. PACKAGING, TRANSPORT CAUTION NOTE Risk of injury and/or damage caused by the use of Damage due to transport unsuitable parts. Incorrect accessories and unsuitable spare parts may device. cause injuries and damage the device and the sur- Transport the device in shock-resistant packaging and rounding area.
