ASSEMBLY INSTRUCTIONS
Read this instruction carefully. Remove all wrapping material, staples and straps from
the carton.
See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft
surface, such as a carpet or rug, to prevent from being scratched. Follow the figure to
start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw until all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.

Step 1

Attach part 1 and 2 for all four sides and lock it using hardware A, B, C, and D.
1
2
C
2
D
Model no : BW19-02T

Part List

Qty
No
1
Table Top
1
2
Table Leg
4
1
A
B
Description
No
A
M5 ALLEN KEY
B
JCBC Screw M8 x 60mm
C
Spring Washer
D
Flat Washer
COMPLETE
ASSEMBLE
Qty
1
8
8
8
