P
Important Note
Double end of line (EOL) resistors must be enabled in the
PC5010 control panel for the wireless zones to be supervised.
If normally Closed or Single EOL resistors are selected the
control panel will not be able to supervise the wireless
devices.
If a wireless device stops sending a supervisory signal (the
unit stops functioning) the panel will not indicate a supervi-
sory trouble condition unless double EOL resistors are used.
In addition, all hardwire zones must be wired for double EOL
resistors.
T
hank you for purchasing the PC5132-RS Wireless Receiver. This product
is the result of several years of development and will allow you to add up to
32 wireless zones to the control panel.
A
short list of advantages:
• Twelve minute supervisory time as opposed to fifty or sixty minutes
• Programmable supervisory window, from one to twelve hours
• Standard alkaline batteries versus specialized batteries
• Orthogonal antenna design
W
e are confident you will find the PC5132-RS Wireless Receiver a unique
and useful control panel enhancement.
C
5
1
firealarmresources.com
3
2
-
R
1
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power832 PC5132-RS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC Power832 PC5132-RS

Summary of Contents for DSC Power832 PC5132-RS

  • Page 1 Important Note Double end of line (EOL) resistors must be enabled in the PC5010 control panel for the wireless zones to be supervised. If normally Closed or Single EOL resistors are selected the control panel will not be able to supervise the wireless devices.
  • Page 2 Overview 1.1 Specifications and Features PC5132-RS Wireless Receiver • Current Draw: 130 mA • Frequency: 922 to 926 MHz, Spread Spectrum • Zones - receiver can receive signals from up to 32 wireless zones • Antenna - orthogonal design for enhanced performance •...
  • Page 3 WLS906 Smoke Detector • Standard alkaline batteries, six ‘AA’ batteries, 30 to 36 month life • Fully supervised for communication integrity • 12 minute supervisory time • Easy enroll process (ESN) • Tamper condition is monitored • Photoelectric detection technology (Patent pending) •...

  • Page 4: Glossary Of Terms

    Batteries The wireless devices are designed to use Eveready Alkaline Ener- gizer batteries (AA: E91; AAA: E92). Do not use other brands of batteries. Using any other brand voids any UL approvals and may affect the system operation. 1.2 Glossary of Terms •...

  • Page 5: Getting Started

    Getting Started 2.1 Connecting the PC5132-RS Receiver Wire the PC5132-RS to the four wire Keybus of the control panel according to the following diagram. After wiring is complete the panel must be told the module has been added. This will happen automati- cally when the panel is powered up after the module is connected.

  • Page 6: Deleting Wireless Devices

    In addition, you must program how the zones will operate, (see the section on “Zone Definitions” in the Control Panel’s Installation Manual). Also the function keys for the handheld keypads and wireless keys will also need to be programmed, (see Sections 2.3.1 and 2.3.2 of this manual).
  • Page 7 2.5 Replacing a Pendant with a Low Battery Once there is a low battery on a pendant, the pendant should be replaced immediately. In order to clear the low battery correctly, follow these steps: From the keypad 1. Enter [ ] [8] [Installer Code]. 2.
  • Page 8 Wireless devices can be mounted where results were Good or Fair. Devices indicating a Bad result must be moved to another location. No device should be mounted where a Bad test result was indicated. If multiple tests on the same device are performed you must wait at least 10 seconds between tests.

  • Page 9: Supervision Of Wireless Zones

    2.8 5132 Tamper A PC5132 tamper will be logged to the event buffer or transmitted as a general system tamper under two conditions. It will first occur if the tamper terminals T1 and T2 on the PC5132-RS are open; the tamper will be restored by shorting out these terminals.

  • Page 10: Programming Worksheets

    Programming Worksheets [804] 5132-RS Wireless Expansion Programming • 5 digit decimal entry is required • First digit represents transmitter type (0, 1, 8-9 are not valid) 2=UTX/SLX, 3=PIR, 4=SMOKE, 5=Pendant, 6=Wireless Key, 7=Handheld Keypad • Next 4 digits represent the serial number (valid entries are 0001 to 4094) Zone Serial Numbers Default = 00000 [17] Zone 17...
  • Page 11 Handheld Keypad Serial Numbers Default = 00000 [33] Keypad 01 [35] Keypad 03 l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l [34] Keypad 02 [36] Keypad 04 l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l...
  • Page 12 Default = 00 Partition 1 Handheld Keypad Options [57] Function Key 1 [59] Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l [58] Function Key 2 [60] Function Key 4 l _ ___ l _ ___ l l _ ___ l _ ___ l Partition 2 Handheld Keypad Options [61] Function Key 1...
  • Page 13 [82] Zone Transmitter Supervision Options (1-8) Default = ON Option ON Option OFF Option 1 Zone 01 Supervision enabled Disabled l _ _______ l Option 2 Zone 02 Supervision enabled Disabled l _ _______ l Option 3 Zone 03 Supervision enabled Disabled l _ _______ l Option 4...
  • Page 14 [84] Zone Transmitter Supervision Options (17-24) Default = ON Option ON Option OFF Option 1 Zone 17 Supervision enabled Disabled l _ _______ l Option 2 Zone 18 Supervision enabled Disabled l _ _______ l Option 3 Zone 19 Supervision enabled Disabled l _ _______ l Option 4...
  • Page 15 Partition Assignments [90] Handheld Keypads (1-4) Partition Assignments Default = OFF Option ON Option OFF Option 1 Keypad 1 on partition 2 On partition 1 l _ _______ l Option 2 Keypad 2 on partition 2 On partition 1 l _ _______ l Option 3 Keypad 3 on partition 2 On partition 1...

  • Page 16: Troubleshooting

    Troubleshooting When I enter the two digit zone number when ‘Adding a Wireless Device’ the keypad gives me a long beep. The panel will not allow you to enter ESN unless a PC5132-RS Wireless Receiver is connected to the Keybus. To enroll the module ensure the Keybus connections are correct then power down and power up the panel with the PC5132-RS Wireless Receiver connected to the Keybus.

  • Page 17: Guidelines For Locating Smoke Detectors

    Guidelines for Locating Smoke Detectors Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke precede detectable levels of heat in most cases. For these reasons, NFPA standard 74 requires smoke detectors to be installed outside of each sleeping area and on each additional story of the family unit.
  • Page 18 PC5132 v2.1 Notice of Software Release The PC5132 Version 2.1 software incorporates several new programming sections for the support of the WLS-908 Panic Pendant and the WLS-909 Wireless Key Fob. WLS-908 Panic Pendant • Two button activation • Built in test feature •...

  • Page 19: Important Note

    Installation Manual IMPORTANT NOTE When using the PC5132 version 2.X Receiver, after programming or defaulting the module, confirm that the data in sections [82] through [85] is correct. PC5132-RS Version 2.1 firealarmresources.com...
  • Page 20 Limited Warranty Digital Security Controls Ltd. warrants that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use and that in fulfilment of any breach of such warranty, Digital Security Controls Ltd.
