Page 1: Installation Manual
• W A R N I N G • This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. Installation Manual PC5132-433 Version 3.12... - Page 2 WARNING Please Read Carefully or positioned. Smoke may not be able to reach the smoke detec- tors, such as when the fire is in a chimney, walls or roofs, or on Note to Installers the other side of closed doors. Smoke detectors may not detect This warning contains vital information.
-
Page 3: Table Of Contents
Compatible Wireless Devices ............... 2 Batteries ....................2 PC5132 Set up & Wiring Unpack the PC5132 ................3 Choose a Mounting Location for the PC5132 ........3 Antennas ....................3 Connect the PC5132 Receiver ............. 3 Enrolling Wireless Devices A Note about Electronic Serial Numbers ..........4 Enrolling Wireless Devices .............. - Page 4 • Wireless key support: Up to sixteen WLS909-433/ WLS919-433 wireless keys can be enrolled. • RF jamming detection: Two different RF jamming detection sensitivity settings. We are confident you will find the PC5132 Wireless Receiver a unique and useful control panel enhancement.
-
Page 5: Introduction
1.1 How to use this Manual Read this manual before you begin installing the PC5132. To install and set up the PC5132 and wireless devices, follow these steps. Refer to the sections listed below. 1. Temporarily mount and wire the PC5132 module (see Section 2 ) 2. -
Page 6: Compatible Wireless Devices
1.3 Compatible Wireless Devices Please refer to the Instruction sheets of the following devices for more information. The PC5132 v3.12 can receive signals from the following devices: • WLS904-433 Motion Detector • WLS906-433 Photoelectric Smoke Detector • WLS907-433 Universal Transmitter •... -
Page 7: Pc5132 Set Up & Wiring
Make sure that electrical wires will not run over the antenna(s) of the module when it is mounted. When mounting the PC5132 in a basement, place the module as high and as close to the underside of the first floor as possible. The range of the module will be reduced if the unit is mounted below ground level. -
Page 8: Enrolling Wireless Devices
5-digit and a 6-digit serial number printed on them. When connecting the PC5132 to a PC5015 v1.x panel, enter 5-digit serial numbers only. When connect- ing the PC5132 to a PC5015 v2.x and higher, PC5008, PC1565 or PC585 panel enter the 6-digit serial number. - Page 9 Enroll Wireless keys 1. At a system keypad, enter [✱][8][Installer’s code] to go to the Installer’s programming section. 2. Enter programming section [804]. 3. Enter a 2-digit number [41]-[56] to assign the wireless key a slot. These numbers correspond to wireless key numbers 01-16. 4.
-
Page 10: Identified Wireless Keys
(using [✱][5] access code programming) for this feature to work correctly. NOTE: Program these access codes on the system after you have connected the PC5132 to the Keybus (see section 2.4). Refer to your system Installation Manual for information on access code programming. -
Page 11: Other Programming
See your system Installation Manual, for more information on each of the above programming sections. 4.2 Enable PC5132 Supervision The control panel will supervise the PC5132 receiver via the Keybus after at least one device has been enrolled on the module (see section 3.2 “Enrolling Wireless Devices”). -
Page 12: Enable Supervision Of Wireless Zones
4. To exit press [#]. 4.4 Jamming Signal Detection The PC5132 receiver detects jamming signals that can prevent the receiver from properly receiving transmissions from enrolled devices. When jamming signals are detected for 5 seconds, the control panel will generate a General System Tamper trouble, which will be reported immediately. -
Page 13: Pc5132 Software Default
There are two RF jamming detection settings for sensitivity: Normal and Sensi- tive. Use the Sensitive setting for installations in rural areas, or for installations where the zones are located at the far end of their range from the PC5132 receiver. Use the Normal setting for all other applications. -
Page 14: Testing & Mounting
5.1 Test the Reception of Wireless Devices It is very important to test the proposed placement of each wireless device before it is mounted. Following these steps will test the signal strength between the PC5132 and the wireless devices. You can test all of the devices together (global placement testing) or test each device individually. -
Page 15: Mount The Pc5132 And Wireless Devices
NOTE: Wait until the placement test of one device is shown/sounded before beginning to test the next device. Continue to test the devices until both the PC5132 and the devices are in good locations. If several wireless devices produce BAD test results, you may need to move the PC5132 to a better location. -
Page 16: Additional Notes
• General System Supervisory • Device Low Battery • Zone Fault Tamper Switches There are two tamper switches on the PC5132 board. Both removing the plastic cover and/or removing the PC5132 from its mounting location will cause a general system tamper. -
Page 17: Troubleshooting
• Verify that you are testing the correct zone • Verify that the correct ESN was entered when the device was enrolled • Verify that the device is in range of the PC5132. Try testing the device in the same room as the receiver. -
Page 18: Programming Worksheets
Programming Worksheets [804] 5132--433 Wireless Expansion Programming • 6-digit entry is required. See Section 3.1 “A note on Electronic Serial Numbers” for details on programming 6-digit serial numbers. Zone Serial Numbers Default = 000000 [01] Zone 1 [17] Zone 17 l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l _ ____ l [02] Zone 2... - Page 19 Wireless Key Serial Numbers Default = 000000 [49] Key 09 [41] Key 01 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l [50] Key 10 [42] Key 02 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l...
- Page 20 Partition 1 Wireless Key Options Default = 00 [59] Function Key 1 Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l Function Key 2 Function Key 4 l _ ___ l _ ___ l l _ ___ l _ ___ l Partition 2 Wireless Key Options [60] Function Key 1...
- Page 21 [84] Zone Device Supervision Options (17-24) Default = ON Option ON Option OFF Option 1 Zone 17 Supervision enabled Disabled l _ _______ l Option 2 Zone 18 Supervision enabled Disabled l _ _______ l Option 3 Zone 19 Supervision enabled Disabled l _ _______ l Option 4...
- Page 22 [91] Wireless Keys (1-8) Partition Assignments Default = OFF Option ON Option OFF Option 1 Wireless Key 01 on partition 2 On partition 1 l _ _______ l Option 2 Wireless Key 02 on partition 2 On partition 1 l _ _______ l Option 3 Wireless Key 03 on partition 2 On partition 1...
-
Page 23: Index
9 devices 12 global 10 panel 9 individual 11 delete device 9 motion detector 10 devices 2 mount adding 4 PC5132 10 devices 11 placement 10 removing 9 PC5132 11 distance from control trouble 12 troubleshooting 13 panel 1 number... -
Page 24: Limited Warranty
The current market price of the replace application of the products. ment product will be charged for each replacement unit. ©2001 Digital Security Controls Ltd. Toronto, Canada • www.dsc.com Technical Support: 1-800-387-3630 Printed in Canada 29004754 R002...
