T
hank you for purchasing the PC5132-RS Wireless Receiver. This product
is the result of several years of development and will allow you to connect
up to 8 wireless detection devices to the PC585, PC1565, PC5008 and
up to 32 detection devices to the PC5010 and PC5015.
The PC5132-RS uses 900 MHz, spread spectrum technology, which provides
several advantages:
• supervisory transmissions are sent every 12 minutes, as opposed to every
50-60 minutes
• programmable supervisory window can be as little as 1 hour, or as long as
24 hours
• devices use standard alkaline batteries as opposed to specialized
batteries
• orthogonal antenna arrangement for better RF reception
Version 3.0 of this product introduces two new features:
• 6 digit serial numbers for all wireless devices: These new serial
numbers include hexadecimal digits. Please read Section 3.1 "A note on
Electronic Serial Numbers (ESN)" for more information on enrolling older 5-
digit and newer 6-digit devices.
• Identification of Wireless Keys (WLS909): Wireless keys 1 to 16 can now
be identified as access codes 17 to 32 (respectively) for identified
openings/closings and command output activation. This feature is only
supported on the following control panels: PC5010 v2.1, PC5015 v2.2,
PC5008 v2.1, PC1565 v2.1 and PC585 v2.1 or higher. For more information
regarding this feature, see Section 3.4 "Identified Wireless Keys."
We are confident you will find the PC5132-RS Wireless Receiver a unique and
useful control panel enhancement.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DSC PC5008
Summary of Contents for DSC PC5008
- Page 1 PC5132-RS Wireless Receiver. This product is the result of several years of development and will allow you to connect up to 8 wireless detection devices to the PC585, PC1565, PC5008 and up to 32 detection devices to the PC5010 and PC5015.
-
Page 2: Section 1: Introduction
- can be wired up to 750 ft. / 230 m from the main panel with 22 gauge wire - connects to Keybus - for longer wire runs, thicker gauge wire must be used. • Compatibility: The PC5132-RS v3.0 can be connected to the following panels: PC5010, PC5015, PC5008, PC1565, PC585... -
Page 3: Compatible Wireless Devices
1.3 Compatible Wireless Devices Please refer to the Installation Instruction sheets of the following devices for more information. The PC5132-RS v3.0 can receive signals from the following devices: · WLS904 Motion Detector · WLS906 Smoke Detector · WLS905 and WLS907 Universal Transmitters ·... -
Page 4: Section 2: Pc5132-Rs Set Up & Wiring
PC5132-RS Set up & Wiring This section describes how to set up and wire the PC5132-RS module. 2.1 Unpack the PC5132-RS Check that the following parts are in your PC5132-RS package: · PC5132-RS PCB · PC5132-RS plastic cabinet · 2 antennas 2.2 Choose a Mounting Location for the PC5132-RS NOTE: Do not permanently mount the PC5132-RS now. -
Page 5: Connect The Pc5132-Rs Receiver
& 2.4 Connect the PC5132-RS Receiver CAUTION: Remove all power from the system while connecting modules to the Keybus. Connect the PC5132-RS to the four-wire Keybus of the control panel according to the following diagram. After you have completed the wiring, re-connect the power to the security system. -
Page 6: Section 3: Enroll & Program Devices
When connecting the PC5132-RS to a PC5010 or PC5015 v1.x panel, enter 5- digit serial numbers only. When connecting the PC5132-RS to a PC5010, PC5015 v2.x and higher, PC5008, PC1565 or PC585 panel follow the instruc- tions below. New Wireless Device ESNs All new devices have both a 5-digit and a 6-digit serial number printed on them so that they can be used with all versions of the PC5132-RS wireless receiver. -
Page 7: Enroll Wireless Devices Using Zones (Wls904, Wls905, Wls906, Wls907 And Wls908)
3.2 Enroll Wireless Devices Using Zones (WLS904, WLS905, WLS906, WLS907 and WLS908) Enroll wireless devices which use zones (universal transmitters, motion detec- tors, smoke detectors, and panic pendants): 1. At a system keypad, enter [ ][8][Installer’s code] to go the installer’s programming section. -
Page 8: Enroll & Program Wireless Keys (Wls909)
3.3 Enroll & Program Wireless Keys (WLS909) For wireless keys to work on the system, you need to enroll them and then program the function buttons. Wireless keys are not assigned to zones and require no zone programming. You can enroll up to 16 wireless keys on the system. -
Page 9: Identified Wireless Keys
· Disable the Quick Exit option in section [015]: [4] Command Output Activation NOTE: The Identified Wireless Key Command Output Activation feature is only available with the PC5010, PC5015, PC5008, PC1565 and PC585 v2.0 and higher. To enable command output activation by wireless keys, ensure that: ·... -
Page 10: Enrolling & Programming Handheld Keypads (Wls910)
3.5 Enrolling & Programming Handheld Keypads (WLS910) For handheld keypads to work on the system, you need to enroll them and then program the function buttons. You can enroll up to 4 handheld keypads on the system. Enroll Handheld Keypads 1. -
Page 11: Deleting Wireless Devices
3.6 Deleting Wireless Devices To remove a wireless device from the system, follow the guideline for adding a wireless device. Program the ESN as [000000]. The wireless device for the zone will be removed. NOTE: You may need to remove power from the panel in order to clear troubles caused by deleted zones. -
Page 12: Section 4: Other Programming
Delay 24-hr fire (wireless) [87] or Standard 24-hr fire (wireless) [88] for proper supervision. • Enable the wireless zone attribute for each wireless zone (PC585, PC1565, PC5008, PC5010 v2.0 and up, PC5015 v2.2 and up only)(programming sections [101]-[132]). See your system Installation Manual, for more information on each of the above programming sections. -
Page 13: Enable Supervision Of Wireless Zones
Double End of Line (DEOL) supervi- sion in the control panel. For more information, refer to your Installation Manual. NOTE (PC5010 v2.0 and higher, PC5015 v2.2 and higher, PC5008, PC1565, PC585 only): For wireless supervision to work, you must enable the wireless zone attribute on all wireless zones (sections [101] to [132], option [8] ON). -
Page 14: Pc5132-Rs Software Default
4.4 PC5132-RS Software Default Returning the PC5132-RS programming to factory default settings is a quick way to remove all the enrolled devices from the system and reset all the programming in section [804]. NOTE: Performing this procedure will not change any programming sections except [804]. -
Page 15: Section 5: Testing & Mounting
Testing & Mounting 5.1 Test the placement of WLS904, WLS905, WLS906 and WLS907 devices It is very important to test the proposed placement of each wireless device before it is mounted. Following these steps will test the placement of the wireless motion detectors (WLS904), wireless smoke detectors (WLS906) and wireless door/window contacts (WLS905 &... -
Page 16: Test Wls908, Wls909 And Wls910 Reception
& 5.2 Test WLS908, WLS909 and WLS910 Reception The panic pendant (WLS908), wireless key (WLS909) and handheld keypad (WLS910) cannot be tested using the module placement test described above. To ensure that the PC5132-RS is receiving transmissions from these devices, conduct the following tests: WLS908: Activate the Panic alarm at several different points in the installation. - Page 17 4. If the pendant’s battery condition is normal , the Ready light on the LCD keypad will turn OFF for 30 seconds or until the [#] key is pressed. On the PC5010, PC5015 v2.x or higher, PC5008, PC1565 and PC585: If the pendant’s battery condition is normal, the keypad will beep and the LCD keypad will display “System Test in Progress.”...
-
Page 18: Section 6: Additional Notes
Additional Notes 6.1 Trouble Conditions The control panel always watches for possible trouble conditions. If a trouble condition occurs, the keypad “Trouble” light will turn on and the keypad will beep. Press [ ][2] to display the trouble conditions. The following trouble conditions apply to the PC5132-RS and/or any enrolled devices. -
Page 19: Section 7: Troubleshooting
Troubleshooting 1. When I enter the 2-digit zone number when adding a wireless device, the keypad gives me a long beep. You cannot enter ESNs unless a PC5132-RS wireless receiver is connected to the Keybus. See section 2 for instructions on setting up and wiring the PC5132-RS module. -
Page 20: Programming Worksheets
Programming Worksheets [804] 5132-RS Wireless Expansion Programming • 6-digit entry is required. See Section 3.1 “A note on Electronic Serial Numbers” for details on programming 6-digit serial numbers. • When enrolling devices with 5-digit serial numbers on the PC5132-RS v3.0, the first digit must be zero (0), followed by the 5-digit serial number (6-digits total). - Page 21 Handheld Keypad Serial Numbers Default = 000000 [35] Keypad 03 [33] Keypad 01 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l [36] Keypad 04 [34] Keypad 02 l _____ l _____ l _____ l _____ l _____ l _____ l l _____ l _____ l _____ l _____ l _____ l _____ l...
- Page 22 Default = 00 Partition 1 Handheld Keypad Options [57] Function Key 1 Function Key 3 l _ ___ l _ ___ l l _ ___ l _ ___ l Function Key 2 Function Key 4 l _ ___ l _ ___ l l _ ___ l _ ___ l Partition 2 Handheld Keypad Options [58] Function Key 1...
- Page 23 [83] Zone Device Supervision Options (9-16) Default = ON Option ON Option OFF Option 1 Zone 09 Supervision enabled Disabled l _ _______ l Option 2 Zone 10 Supervision enabled Disabled l _ _______ l Option 3 Zone 11 Supervision enabled Disabled l _ _______ l Option 4...
- Page 24 Partition Assignments [90] Handheld Keypads (1-4) Partition Assignments Default = OFF Option ON Option OFF Option 1 Keypad 1 on partition 2 On partition 1 l _ _______ l Option 2 Keypad 2 on partition 2 On partition 1 l _ _______ l Option 3 Keypad 3 on partition 2 On partition 1...
-
Page 25: Appendix A: Guidelines For Locating Smoke Detectors
Guidelines for Locating Smoke Detectors Experience has shown that all hostile fires in family living units generate smoke to a greater or lesser extent. Experiments using typical fires in family living units indicate that detectable quantities of smoke precede detectable levels of heat in most cases. In existing homes, NFPA Standard 72 requires that a smoke detector be installed outside each sleeping area and on each additional story of the family unit. -
Page 26: Index
Index handheld keypad 10 serial number 6 device 7 slot number handheld keypad 10 wireless key 8 wireless key 8 smoke detector interference 4 antenna 2 zone definition 12 installing 4 supervision DEOL 13 Keybus 5 device 13 batteries disable 12 module 12 replacing 18 location... - Page 27 LIMITED WARRANTY ter a reasonable number of attempts will be lim- ited to a replacement of the product, as the ex- Digital Security Controls Ltd. warrants the origi- clusive remedy for breach of warranty. Under nal purchaser that for a period of twelve months no circumstances shall Digital Security Controls from the date of purchase, the product shall be Ltd.
- Page 28 © 1998 Digital Security Controls Ltd. 1645 Flint Road, Downsview, Ontario, Canada M3J 2J6 Tel. (416) 665-8460 • Fax (416) 665-7498 Tech. Line 1-800-387-3630 Printed in Canada 29003020 R0...
- Page 29 Installation Manual PC5132-RS Version 3.0...
- Page 30 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital Security Controls Ltd. could void your authority to use this equipment. This equipment generates and uses radio frequency energy and if not installed and used properly, in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.
-
Page 31: Table Of Contents
Contents Section 1: Introduction How to use this Manual ................ 2 Specifications and Features ..............2 Compatible Wireless Devices ............... 3 Batteries ....................3 Section 2: PC5132-RS Set up & Wiring Unpack the PC5132-RS ................ 4 Choose a Mounting Location for the PC5132-RS ......... 4 Installing the Antennas ................. - Page 32 WARNING follow. The smoke detectors may have been improperly in- Please Read Carefully stalled or positioned. Smoke may not be able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs, Note to Installers or on the other side of closed doors.
