- Page 1 Nice RGBW-Control Universal remote control for RGB/RGBW and other LEDs EN - Instructions and warnings for installation and use...
-
Page 2: Warnings And General Precautions
• RGBW-Control and the load connected to its output must be powered by 12VDC or 24VDC stabilized power supply with short circuit pro- tection. Connecting higher voltage or voltage not matching the load’s voltage may cause damage to the device. - Page 3 • RGBW-Control and the load connected to its output must be powered by 12VDC or 24VDC stabilized power supply (SELV) with short circuit protection. Connecting higher voltage or voltage not matching the load’s voltage may cause damage to the device.
- Page 4 3.5 - Connection with 0-10V analog sensors The 2-wire analog sensor requires pull-up resistor. You can connect up to 4 analog sensors to IN1/IN2/IN3/IN4 terminals. 1. Disconnect power. 12/24V DC 2. Connect with the diagram on the right. 3. Verify correctness of connection. 0-10V 4.
-
Page 5: Removing The Device
4. LED will start blinking yellow, wait for the removing process to end. 5. Successful removing will be confirmed by the Z-Wave controller’s message and red LED colour. Note. Removing RGBW-Control from the Z-Wave network restores all the default parameters of the device, but does not reset power meter- ing data. - Page 6 6.3 - Menu Menu allows to perform Z-Wave network actions. In order to use the menu: 1. Press and hold the service button to enter the menu, device blinks to signal adding status (see 7.2: Visual indications). 2. Release the service button when device signals desired position with colour: »...
- Page 7 1st association group – “Lifeline” reports the device status and allows for assigning single device only (main controller by default). 2nd association group – “RGBW Sync” allows to synchronize state of other RGBW-Control devices. 3rd association group – “On/Off (IN1)” is used to turn the associated devices on/off reflecting IN1 operation.
-
Page 8: Advanced Parameters
The device allows to customize its operation to user’s needs using configurable parameters. The settings can be adjusted via Z-Wave control- ler to which the device is added. The way of adjusting them might differ depending on the controller. Table A3 - RGBW-Control - Available parameters Parameter: 1. - Page 9 Parameter: 30. Alarm configuration - 1st slot Description: This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification. X –...
- Page 10 Parameter: 34. Alarm configuration - 5th slot Description: This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification. X –...
- Page 11 Parameter: 62. Power reports - periodic Description: This parameter determines in what time intervals the periodic power reports are sent to the main controller. Peri- odic reports do not depend of power change (parameter 61). Available settings: 0 - periodic reports are disabled 30-32400 (30-32400s) - report interval Default setting: 3600 (1h)
- Page 12 Parameter: 154. ON frame value for single click Description: This parameter defines value sent to devices in association groups. The parameters consist of 4 bytes, each byte reserved for separate channel, from least significant (IN1) to most significant (IN4). Applicable for Basic Set and Switch Multilevel Set commands. Available settings: For every byte: 0-99, 255 Default setting:...
- Page 13 COMMAND_CLASS_SUPERVISION [0x6C] COMMAND_CLASS_SECURITY [0x98] COMMAND_CLASS_SECURITY_2 [0x9F] COMMAND_CLASS_DEVICE_RESET_LOCALLY [0x5A] COMMAND_CLASS_APPLICATION_STATUS [0x22] COMMAND_CLASS_POWERLEVEL [0x73] COMMAND_CLASS_FIRMWARE_UPDATE_MD [0x7A] COMMAND_CLASS_CONFIGURATION [0x70] COMMAND_CLASS_PROTECTION [0x75] COMMAND_CLASS_NOTIFICATION [0x71] COMMAND_CLASS_COLOR_SWITCH [0x33] COMMAND_CLASS_METER [0x32] COMMAND_CLASS_CENTRAL_SCENE [0x5B] COMMAND_CLASS_SENSOR_MULTILEVEL [0x31] COMMAND_CLASS_BASIC [0x20] Multichannel Command Class: MULTICHANNEL CC ROOT (Endpoint 1) Generic Device Class GENERIC_TYPE_SWITCH_MULTILEVEL Specific Device Class SPECIFIC_TYPE_COLOR_TUNABLE_MULTILEVEL...
- Page 14 COMMAND_CLASS_ZWAVEPLUS_INFO [0x5E] COMMAND_CLASS_SWITCH_MULTILEVEL [0x26] COMMAND_CLASS_ASSOCIATION [0x85] COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION [0x8E] Command Classes COMMAND_CLASS_ASSOCIATION_GRP_INFO [0x59] COMMAND_CLASS_SUPERVISION [0x6C] COMMAND_CLASS_SECURITY [0x98] COMMAND_CLASS_SECURITY_2 [0x9F] COMMAND_CLASS_APPLICATION_STATUS [0x22] EP2 controlls directly Output 1 [Red] EP3 controlls directly Output 2 [Green] Description EP4 controlls directly Output 3 [Blue] EP5 controlls directly Output 4 [White] Endpoint 6, 7, 8 and 9 Generic Device Class GENERIC_TYPE_SENSOR_MULTILEVEL...
- Page 15 Unprotected - The device accept and respond to all Outputs can be controlled RF Commands. via Z-Wave. No RF control – command class Basic, Switch Mul- Outputs cannot be con- tilevel and Color Switch are rejected, every other trolled via Z-Wave. command class will be handled * only Central Scene Notifications can be triggered in this state.
-
Page 16: Technical Specifications
The product RGBW-Control is produced by Nice S.p.A. (TV). Warnings: - All technical specifications stated in this section refer to an ambient temperature of 20 °C (± 5 °C) - Nice S.p.A. reserves the right to apply modifications to the product at any time when deemed necessary, while maintaining the same functionalities and intended use. -
Page 17: Product Disposal
Caution! – local legislation may envisage serious fines in the event of abusive disposal of this product. DECLARATION OF CONFORMITY Hereby, Nice S.p.A., declares that the radio equipment type RGBW-Control is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.niceforyou.com/en/support... - Page 18 Nice SpA Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
