FÖRDELAKTIG
GB

Advertisement

Table of Contents
loading

Related Manuals for IKEA FORDELAKTIG

Summary of Contents for IKEA FORDELAKTIG

  • Page 1 FÖRDELAKTIG...
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Power limitation Rating plate Hob functions Environmental aspects Cooking table IKEA guarantee Extractor functions Safety information For your safety and the correct operation of the device, please read this manual carefully before installation and use. Always keep these instructions with the appliance, even when it is sold or passed on to third parties.
  • Page 5 ENGLISH • The manufacturer cannot be held responsible for any damage resulting from incorrect or inadequate installation. • Check that the mains power supply corresponds to the one in- dicated on the rating plate affixed to the inside of the product. •...
  • Page 6 ENGLISH • As regards the technical and safety measures to be taken for exhausting of fumes, it is important that the regulations set by local authorities be followed carefully. WARNING: Remove the protective films before installing the appliance. • Only use the screws and other hardware elements supplied with the appliance.
  • Page 7 ENGLISH Keep children under 8 years of age well away from the appliance, unless they are under constant supervision. • Clean and/or replace the filters after the period indicated (danger of fire). See the paragraph on Cleaning and mainten- ance. •...

  • Page 8: General Information

    ENGLISH WARNING: Danger of fire: do not place objects on the cook- ing surfaces. • The appliance must be installed to allow it to be cut off from the electrical power supply with a contact opening (3 mm) that ensures complete disconnection under overvoltage category III conditions.
  • Page 9 ENGLISH it. Do not drag pans or plates over the sur- face. Cabinet requirements Min. 500 mm Installation • The appliance is intended for recessed in- stallation in the kitchen worktop above a cabinet with a width of 600 mm or more. •...

  • Page 10: Electrical Connection

    • If the cables are damaged, replace with ori- ginal spare parts cables. Contact the call • Before making the connections, check that center of your IKEA store. the rated voltage of the appliance indicated on the rating plate corresponds to the Attention! Do not weld any of the mains power supply.
  • Page 11 ENGLISH Connection diagram product side Insert the shunts between the screws as illustrated Brown Black Blue Yellow / Green Black or brown Blue Yellow / Green...
  • Page 12 ENGLISH Connection diagram home side Brown Black or brown Black Blue Blue Yellow / Green Yellow / Green...

  • Page 13: Cleaning And Maintenance

    ENGLISH Cleaning and maintenance • Switch the appliance off or disconnect it every 2 months of operation, or more fre- from the electricity supply before any main- quently for particularly heavy usage, and tenance work. can be washed in a dishwasher. Activated charcoal filter •...
  • Page 14 ENGLISH crusted and burnt-on dirt. • Remove any melted plastic using a scraper pad suitable for vitreous ceramic, while the • For day-to-day dirt, use a soft cloth cooker hob is still hot. If you do not, the or sponge and a suitable detergent. Follow residue may damage the vitreous ceramic the manufacturer’s recommendations re- surface.

  • Page 15: Product Description

    ENGLISH Product description Single cooking zone (220x197 mm) 2100 W, with 3000 W Booster function Single cooking zone (220x197 mm) 2100 W, with 3000 W Booster function Single cooking zone (145 mm) 1400 W, with 1850 W Booster function Single cooking zone (200 mm) 2300 W, with 3000 W Booster function Control panel Extractor Bridge cooking area...

  • Page 16: Control Panel

    ENGLISH Control panel On/Off Pause key Cooking zone power level indicator Extractor power level indicator Extractor timer control Extractor controls zone symbol Cooking zone timer control Timer management zone Grease filter saturation indicator Activated carbon filter saturation indicator Lock key Melting Scroll keypad Auto key...
  • Page 17 ENGLISH The cooking zones can be activated by If there are no pans or other objects on the hob, the digits are not visible. pressing the reference digit . The digit The functions which can be selected are becomes brighter to confirm the operation. always visible on the control panel, but with a When a pan is placed on one of the 4 cooking dimmed light.

  • Page 18: Power Limitation

    ENGLISH Power limitation When connecting to the household power The rear left digit indicates and a number supply for the first time, the installer must set indicating the type of menu. The front left the power of the cooking zones based on the digit indicates a number which depends on actual capacity of the household power the parameters indicated in the selection.

  • Page 19: Hob Functions

    ENGLISH Hob functions This function prevents accidental use of the appliance. This cannot be used during a cooking operation. To enable: remove all cookware from the appliance, turn the appliance off. Turn the appliance on and within 3 seconds press and hold any of the 5 digits for 3 seconds. Release and slowly swipe along the Child lock power bar from 0 to BOOST.
  • Page 20 ENGLISH Timer with alarm for generic use. To enable: switch on the hob making sure there are no pans or active cooking areas. The 3 digits to control the timer show “- - -”. Press the digit to access the timer menu and display “0 0 0”. Press “+”...

  • Page 21: Cooking Table

    ENGLISH This function is used to recall the function settings of the hob if it is switched off by mistake or the elec- tricity is unexpectedly cut off. Recall function When the hob is switched off, if it is switched on again with 6 seconds by touching , the key flashes for 6 seconds.

  • Page 22: Extractor Functions

    ENGLISH Extractor functions The controls for the cooking zones, extractor and timer can be activated by pressing on the reference Digit. Press “9” on the power bar to set INTENSIVE 1 speed. This setting is timed to operate for 10 minutes. Once this “...

  • Page 23: User Menu Customisation

    ENGLISH User menu customisation Before carrying out the procedure, it is advisable to read the entire paragraph. – Press – Press and hold again for 3 seconds. – key starts flashing. – Press and hold : the digits in the cooking area indicate . –...

  • Page 24: Cookware Guidance

    ENGLISH Cookware guidance Which pans to use Empty pots/pans or with thin base Only use pots and pans with the bottom Do not use empty or thin-based pots/pans on made from ferromagnetic material which are the hob as it will be unable to detect the suitable for use with inductions hobs: temperature or turn off automatically if the temperature is too high, thus damaging the...

  • Page 25: Power Management

    ENGLISH Loud whistle electronic system. The fan may continue to operate after the appliance has been turned This noise occurs with pans made up of layers off, if the temperature of the cooker hob is of different materials, and also when these still detected to be too high.

  • Page 26: Troubleshooting

    After- After-Sales Service. You can find a full list of Sales Service technician or dealer will not be IKEA appointed contacts at the end of this free of charge, even during the warranty user manual.

  • Page 27: Extractor Technical Data

    This information can be found on the Further information on the technical data is identification plate. The identification plate is available on the website: www.Ikea.com affixed to the bottom of the device. Extractor technical data RECESSED...

  • Page 28: Extractor Energy Efficiency

    ENGLISH Extractor energy efficiency Unit Value Product information FÖRDELAKTIG Model id 505.348.54 kWh/a 40.9 Annual energy consumption Time increase factor 33.1 Fluid dynamics efficiency 44.3 Energy efficiency index m3/h Air flow measured at the optimum efficiency point Air pressure measured at the optimum efficiency point m3/h Maximum air flow Electrical power supply measured at the optimum efficiency point...

  • Page 29: Rating Plate

    ENGLISH Rating plate The image above shows the rating plate for the appliance. The serial number is specific for each product.

  • Page 30: Environmental Aspects

    IKEA appliances, please contact your For quicker service, always refer to the IKEA nearest IKEA Customer Support Centre, the article number (8-digit code) and the 12-digit number is available on www.IKEA.com.
  • Page 31 Country name in local languages Telephone number Opening times Victoria: (03) 8523 2154 New South Wales: (02) 5020 6641 Queensland: (07) 3380 6800 Australia IKEA Perth: (08) 9201 4532 IKEA Adelaide: (08) 8154 4532 Österreich 13602771461 Mo-Fr: 8 - 20 België / Belgique 26200311 Ma-Vr: 8 - 20 / Lun-Ven: 8 - 20 България...
  • Page 32 23199 AA-2310368-2 Inter IKEA Systems B.V. 2021...
