Summary of Contents for IKEA FORDELAKTIG
- Page 1 FÖRDELAKTIG...
- Page 3 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed Authorized Service Centre and relative national phone number...
-
Page 4: Table Of Contents
Cooking zone control panel Rating Plate Extractor control panel Environment concerns Cookware guidance IKEA GUARANTEE Safety information For your safety and correct operation of the appliance, read this manual carefully before installation and use. Always keep these instructions with the appliance even if you move or sell it. Users must fully know the operation and safety features of the appliance. - Page 5 ENGLISH • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the product. • Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
- Page 6 ENGLISH • If the supply cord is damaged, it must be replaced from the manufacturer or its service agent or similarly qualified person in order to avoid a hazard. • Connect the plug to a socket complying with current regulations, located in an accessible place. •...
- Page 7 ENGLISH way and understand the hazards involved. Children shall not play with the appliance. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
- Page 8 ENGLISH A short term cooking process has to be supervised continuously. • The appliance is not intended to be operated by means of an external timer or separate remote-control system. WARNING: Danger of fire: do not store items on the cooking surfaces.
-
Page 9: General Information
ENGLISH General information General recommendations • Never use scouring pads, steel wool, muriatic acid or other products which could scratch or mark the surface. Min. 500 mm • For safety reasons, do not clean the appliance with steam blasters or high-pressure cleaners. •... - Page 10 ENGLISH Care and Cleaning Grease Filters Switch off or unplug the appliance from the mains • Clean or replace the filters continuously supply before carrying out any maintenance work. according to below time intervals, to maintain good performance of the hood and to Charcoal Filter prevent a potential fire hazard, caused by excessive grease build-up.
- Page 11 ENGLISH Cleaning the appliance • Clean the appliance after every use in order to prevent food residues from burning on. Cleaning dried-on and burnt-on dirt requires more effort. • To clean everyday dirt, use a soft cloth or sponge with water and a suitable cleaning agent.
-
Page 12: Electrical Connection
• If the cables are damaged, replace with • The connection terminals can be accessed by original spare parts cables. Contact the removing the junction box cover. call center of your IKEA store. • Check that the domestic power supply Caution! Do not solder any wires! - Page 13 ENGLISH 220-240V ~ 1+N+GND 380-415V ~ 2+N+GND 380-415V ~ 3+N+GND N PE 220V - 240V 220V - 240V Connection diagram product side 220V - 240V 220V - 240V 220V - 240V 220V - 240V N PE 220V - 240V 220V - 240V 220V - 240V 220V - 240V 220V - 240V...
- Page 14 ENGLISH ENGLISH agram home side ENGLISH Connection diagram home side Connection diagram home side Connection diagram home side Brown Black or brown Black Blue Blue Yellow / Green Brown Black or brown Yellow / Green Black Blue Brown Black or brown Blue Yellow / Green Black...
-
Page 15: Product Description
ENGLISH Product description Single cooking zone (220 x 185 mm) 2100W, with Booster 3700W Single cooking zone (220 x 185 mm) 2100W, with Booster 3700W Single cooking zone (220 x 185 mm) 2100W, with Booster 3700W Single cooking zone (220 x 185 mm) 2100W, with Booster 3700W Control Panel Extractor Bridge cooking area (220 x 370 mm) 3700W... -
Page 16: Control Panel
ENGLISH Control Panel Hob extractor ON/OFF. Press to turn ON. Press again to turn OFF. By default, when the Hob extractor is turned on the hood is in automatic mode and the led will turn on. Touch (press) the selection bar to deactivate automatic mode and work with the extractor fan in manual mode. - Page 17 ENGLISH Stop&Go / Recall This function allows any function active on the hob to be suspended / restarted, bringing the cooking power to zero. Press to activate, press again and slide the slider shown (close to the pause function ) all the way from left to right to deactivate. Note: If after 10 minutes, the Pause function is not deactivated, the hob will turn off automatically.
-
Page 18: Cooking Zone Control Panel
ENGLISH Cooking zone control panel Cooking zone position indicator. The cooking zones are able to work in combination, creating a single zone with the same power level. Front master and back secondary cooking zones. To activate the Bridge function: touch simultaneously the 2 bar and the symbol lights up. -
Page 19: Extractor Control Panel
ENGLISH Extractor control panel Extractor fan selection Increase/Decrease extraction speed (power) Activation/Deactivation of automatic function (by default auto- matic mode is active). When the selection bar of the cooker hood is touched (pres- sed), the automatic mode deactivates and works with the extractor fan in manual mode. -
Page 20: Cookware Guidance
ENGLISH Cookware guidance What pots to use If an error message appears, refer to Only use pots and pans with bottom made “Troubleshooting”. from ferromagnetic material which are suitable for use with inductions hobs: Hint/tips • cast iron Noise during cooking •... -
Page 21: Daily Use
ENGLISH of different materials layered one upon the Rhythmic sounds, similar to the ticking other, and when they are additionally used sound of a clock at maximum output and also on two cooking This noise occurs only when at least three zones. - Page 22 ENGLISH Timer -Press at the same time the bargraphs of the two When a timer is set, the cooking zone switches off cooking zone (same side). after a set time between 1 min and 1 h 59 min. -The display near the two zones shows on one side and on the other side.
-
Page 23: Troubleshooting
After Sales authorised installer, the visit from the After Service. You can find a full list of IKEA Sales Service technician or dealer will not be appointed contacts at the end of this user free of charge, even during the warranty manual. -
Page 24: Power Management
- appliance model (Art./Cod.) Further information on technical data is - serial number (S.N.) available on: www.Ikea.com This information is given on the rating plate. The rating plate is attached on the bottom side. Power Management This product is equipped with electronically controlled Power Management. -
Page 25: Hob Extractor Technical Data
ENGLISH Hob Extractor Technical Data Unit Value FÖRDELAKTIG Model identifier 905.348.52 Product Type BUILT IN Width Dimensions Depth Height min/max Airflow max* - Exhaust Installation m3/h Noise max* - Exhaust Installation Airflow max* - Recirculating Installation m3/h Noise max* - Recirculating Installation Extractor Rating Power Hob Rating Power 7400... -
Page 26: Extractor Energy Efficiency
ENGLISH Extractor Energy efficiency Product Information according to EU n°66/2014 Unit Value FÖRDELAKTIG Model identifier 905.348.52 Annual Energy Consumption kWh/a 28,7 Time increase factor Fluid Dynamic Efficiency 37,6 Energy Efficiency Index 32,8 Measured air flow rate at best efficiency point m3/h 328,0 Measured air pressure at best efficiency point... -
Page 27: Hob Energy Efficiency
ENGLISH Hob Energy efficiency Product Information according to EU n°66/2014 Value FÖRDELAKTIG Model identifier 905.348.52 Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter size of the zone (dimensions) 220 x 185 mm Energy consumption per cooking zone (EC electric cooking) 170 Wh/kg Energy consumption of the hob (EC electric cooking) 170 Wh/kg... -
Page 28: Environment Concerns
IKEA appliances, please contact your For quicker service, always refer to the nearest IKEA Customer Support Centre, IKEA article number (8-digit code) and the the number is available on www.IKEA.com. 12-digit service number found on the rating We recommend you read the appliance plate of your appliance. - Page 31 Country name in local languages Telephone number Opening times Victoria: (03) 8523 2154 New South Wales: (02) 5020 6641 Australia Queensland: (07) 3380 6800 IKEA Perth: (08) 9201 4532 IKEA Adelaide: (08) 8154 4532 Österreich 13602771461 Mo-Fr: 8 - 20 België / Belgique 26200311...
- Page 32 23199 © Inter IKEA Systems B.V. 2019 AA-2312628-1...
