Using AV1 or AV2 inputs

without S-video
terminal
VIDEO EQUIPMENT
To audio
Y Y R R
W W
outputs
To video
output
Yellow (VIDEO)
Y Y
White (AUDIO L/MONO)
W W
Red (AUDIO R )
R R

Using AV3 inputs

Side terminals
To earphone jack
S-VIDEO
VIDEO
To video
input
L/MONO
R
To audio
inputs
(3)
To view video program from AV1, AV2 or AV3 inputs
1
Connect video equipments to AV inputs (AV1, AV2 or AV3) as the figures above.
2 Press AV to display video input menu.
3
Select the corresponding video mode (Video1 , Video2 or Video3) by using CH+ or CH-.
4 Press VOL+ or VOL- to confirm.
Notes:
In AV1, AV2, AV3 inputs, the S-VIDEO terminal takes precedence over the VIDEO terminal. To
view program from the VIDEO terminal, be sure to disconnect the S-VIDEO terminal.
Please refer to the owner's manual of your specific equipment as well.
Rear terminals
S-VIDEO
Signal
VIDEO
L
/MONO
AUDIO
R
Signal
Installation
Signal
MONITOR
To S-VIDEO
To video
output
To audio
outputs
(continued)
with S-video
terminal
VIDEO EQUIPMENT
R R
W W
output
