QUICK START PROCEDURE
Table 3. LED Indicators
NOMENCLATURE
IN
OUT
ALERT
SCL
SDA
GPIO3
GPIO2
Table 4. Jumpers
NOMENCLATURE
CLK, INT, EXT
ON, INTV
, FLOAT, GND
CC
ADR0, H, NC, L
ADR1, H, NC, L
ADR2, H, NC, L
WRITE PROTECT, LOCK, WRITE
Table 5. Connectors
NOMENCLATURE
DC590
DC1613
DEMO MANUAL DC2442A
LED
D1 (Green)
D2 (Green)
D5 (Red)
D6 (Green)
D7 (Green)
D8 (Green)
D9 (Green)
JUMPER
JP1
JP2
JP3
JP4
JP5
JP6
CONNECTOR
J1
J2
DESCRIPTION
Input Power Indicator
Output Power Indicator
ALERT Pin Logic Low
Serial Clock Active
Serial Data Active
GPIO3 Logic Low
GPIO2 Logic Low
DESCRIPTION
Internal/External Clock Select
ON Input Select, V
, Float (External), GND
CC
Address Pin ADRO Select
Address Pin ADR1 Select
Address Pin ADR2 Select
Write Protect for EEPROM
DESCRIPTION
Connection for DC590
Connection for DC1613
dc2442af
3
