- Page 2 Component List Description Label Picture Side Board Body Marble Top Shelves Hardware List Description Label Picture Allen Bolt 6 x 45 mm Shelf Pin Allen Bolt 6 x 30 mm Washer 25x8mm Tool List Description Label Picture Allen Key 4mm Assembly Prep Before Beginning: * Save all packing until finished.
- Page 3 Assembly Steps Step 1 Careful : Extremely heavy product. Place Cabinet Body (A) upside down on a non-damaging padded surface. To attach Legs, align holes of Leg (B) with Side Board Body (A) as shown above, Insert Allen Bolt (H1) and tighten it with Allen Key (T1) .
- Page 4 Step 3 Remove the 2 drawers (First and Second) and open the doors of sideboard as shown in image. Align the holes on top frame and holes underside of Marble Top (C) and secure holes using Allen Bolt (H3) and Flat Washer (H4) and fully tighten using Allen Key (T1). Page 4...
- Page 5 Step 4 Open the door and fix the Shelf Pin (H2) in the desired holes and place The Wood Shelf (C) on Shelf Pin as shown above in the drawing. Follow the same process to place the other shelf. Product is ready to use. Assembled View Product assembly is now complete and product is ready to use.
