- Page 1 Revision 1.000 Page 1 of 31 Industrial Electronic Devices User Manual Revision 1.000 English PROFIBUS / HART Master - Converter (Order Code: HD67911-A1) For Website information: www.adfweb.com?Product=HD67911 For Price information: www.adfweb.com?Price=HD67911-A1 Benefits and Main Features: Very easy to configure For other HART products see also the following link:...
-
Page 2: Table Of Contents
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 2 of 31 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 3 of 31 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 4 of 31 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 5 of 31 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67911-A1 ADFweb.com S.r.l. -
Page 6: Characteristics
Page 6 of 31 Industrial Electronic Devices CHARACTERISTICS: The HD67911-A1 are PROFIBUS / HART Master - Converters. It allows for the following characteristics: Triple isolation between PROFIBUS - Power Supply, PROFIBUS - HART, HART - Power Supply; Two-directional information between Ethernet bus and HART bus;... -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67911-A1 Caution: Do not reverse the polarity power HD67911-A1 ADFweb.com S.r.l. -
Page 8: Function Modes
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 8 of 31 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 9 of 31 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Hart
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 10 of 31 Industrial Electronic Devices HART: “HART” is an acronym for Highway Addressable Remote Transducer. The HART Protocol makes uses Frequency Shift Keying (FSK) standard to superimpose digital communication signals at a low level on top of the 4-20mA. This enables two-way field communication to take place and makes it possible for additional information beyond just the normal process variable to be communicated to/from a smart field instrument. -
Page 11: Profibus
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 11 of 31 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®... -
Page 12: Ethernet
ETHERNET: The updating of the converters and Ethernet communication must be made using Connector4 of the HD67911-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 13: Use Of Compositor Sw67911
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 13 of 31 Industrial Electronic Devices USE OF COMPOSITOR SW67911: To configure the Converter, use the available software that runs with Windows called SW67911. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 14: New Configuration / Open Configuration
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 14 of 31 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “... -
Page 15: Software Options
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 15 of 31 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 16 of 31 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 17 of 31 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of HART and PROFIBUS buses. By Pressing the “Set Communication” button from the main window for SW67911 (Fig. 2) the window “Set Communication”... -
Page 18: Hart Variables
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 18 of 31 Industrial Electronic Devices HART VARIABLES: By Pressing the “HART Variables” button from the main window for SW67911 (Fig. 2) the window “Definition of HART Variables List” appears (Fig. -
Page 19: Profibus Gsd
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 19 of 31 Industrial Electronic Devices In the field “Swap” the bytes’ order is reversed; In the field “Conv Int” the data from HART device is converted in Integer format; In the field “Operations”... -
Page 20: Update Device
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 20 of 31 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 21 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 21 of 31 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67911 device. Warning: If Fig.
-
Page 22: Mechanical Dimensions
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 22 of 31 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67911-A1 ADFweb.com S.r.l. -
Page 23: Scan Function
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 23 of 31 Industrial Electronic Devices SCAN FUNCTION: “SCAN” function is integrated in the configurator software SW67911. It is possible to access to these functions by simple click on the “Scan” button in “HART Variables”... - Page 24 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 24 of 31 Industrial Electronic Devices Insert the IP Address configured in the converter; Start the Scan by clicking on “Start Scan” button. The window will appear like below: Figure 8b: “HART Scan”...
-
Page 25: Webserver Interface
WEBSERVER INTERFACE: The HD67911-A1 has an integrated Webserver that allows to scan HART network, discover HART devices and program them for first installation. It is possible to use the most common browser like Internet Explorer, Google Chrome, Mozilla Firefox by editing the IP Address of the converter in the address bar of the browser. - Page 26 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 26 of 31 Industrial Electronic Devices When one of the buttons of the “Welcome” page are pressed, it is necessary to do the login, using the “Admin” and “Password” defined in the section “Set Communication”...
- Page 27 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 27 of 31 Industrial Electronic Devices HART S Figure 11: “HART Scan” window When the “HART Scan” button is pressed, the “HART Scan” window appears (Fig. 11). It has the following fields: “NUMBER OF DEVICES TO SEARCH FOR (Maximum 16)”...
- Page 28 User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 28 of 31 Industrial Electronic Devices HART C ONTROL Figure 12: “Data Logger Commands” window When the “HART Control” button is pressed or when a discovered HART node from HART Scan section is selected, the “HART Control”...
-
Page 29: Ordering Information
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67911: PROFIBUS / HART Master - Converter Order Code: HD67911-A1 PROFIBUS / HART Master - Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 30: Disclaimer
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 30 of 31 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 31: Warranties And Technical Support
User Manual PROFIBUS / HART Master Document code: MN67911_ENG Revision 1.000 Page 31 of 31 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
