D-Link DWC-2000 Quick Installation Manual page 3

Item
A
B
C
D
E Hard disk drive module slot
F Gigabit LAN SFP ports (1-4)
G Gigabit LAN RJ-45 ports (1-4)
H
I
J
Status LEDs and Ethernet Port LEDs
Part
Reset button
Power LED
Fan LED
USB ports (1-2)
Console port
Power switch
Power outlet
Description
System reset
Indicates if the wireless controller is powered on
Indicates the fan status on the wireless controller
These ports can support various USB 1.1 or 2.0 devices
Slot for the hard disk drive module
Connect to Ethernet devices such as computers,
switches, and hubs
Connect to Ethernet devices such as computers,
switches, and hubs
Used to access the Command Line Interface (CLI) via an
RJ-45 to DB-9 console cable
Powers On/Off the device
Connects to the power cord
