Preventing Electrostatic Discharge Damage to the SRX3400 Services Gateway
Many services gateway hardware components are sensitive to damage from static
electricity. Some components can be impaired by voltages as low as 30 V. You can
easily generate potentially damaging static voltages whenever you handle plastic or
foam packing material or if you move components across plastic or carpets. Observe
the following guidelines to minimize the potential for electrostatic discharge (ESD)
damage, which can cause intermittent or complete component failures:
Always use an ESD wrist strap or ankle strap, and verify that it is in direct contact
with your skin.
CAUTION: For safety, periodically check the resistance value of the ESD strap. The
measurement should be in the range of 1 to 10 megaohms.
When handling any component that is removed from the chassis, verify that the
equipment end of your ESD strap is attached to one of the ESD points on the
chassis, which are shown in Figure 1 and Figure 2.

Figure 1: ESD Point on Front of SRX3400 Services Gateway

Console USB
SFB
ports ports
Slot
ESD
number IOC in
CFM slots
guide point
slot 1
for IOCs
and SPCs
Preventing Electrostatic Discharge Damage to the SRX3400 Services Gateway
Cooling
air exhaust
1
