Roof installation

Danger
Disconnect the mains power supply to the unit before performing any work.
Caution
Risk of injury through pinching. Use protective clothing.

Enclosed in the kit:

Systemair Sverige AB · Industrivägen 3, SE-739 30 Skinnskatteberg, Sweden
Phone +46 222 440 00 Fax +46 222 440 99
Installation Guide ODK Roof
Corner brackets
4 pcs for all Topvex
Sheet metal screws with rubber seal
24 pcs for Topvex SR20-35, SC20-60
32 psc for Topvex SR60-100, SC70
Side bracket
2 pcs for Topvex SR20-35, SC20–60
4 pcs for Topvex SR60-100, SC70
Roof parts
2 pcs
3 pcs for Topvex SC70
247576-en_GB- vA002
1 (3)
