- Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL SYSWALL WALL MOUNTED FAN COIL UNIT 2013-0...
-
Page 3: Table Of Contents
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL INDEX INTRODUCTION RECOMMENDATIONS MAIN COMPONENTS LOCATION FOR FAN COIL UNIT WORK LIMITS GENERAL DIMENSIONS HYDRAULIC CONNECTION AND CONDENSATE DRAIN TECHNICAL DATA MOUNTING PLATE INSTALLATION PIPING AND DRAINAGE OF FAN COIL UNIT FIELD PIPING CONNECTION HOW TO REMOVE THE FRAME GRILLE CHECKING THE DRAINAGE... -
Page 4: Introduction
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL 4. REMOTE CONTROL UNIT INTRODUCTION Using this unit make possible to set all operating parameters of the unit, these para- Please read this manual carefully before operating the unit. meter are shown in the LCD display to make the programming operations easier. -
Page 5: General Dimensions
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL GENERAL DIMENSIONS MOD. 1-2 MOD. 3-4 HYDRAULIC CONNECTIONS AND CONDENSATE DRAIN MOD. 1-2 MOD. 3-4 Return Ø 1/2” Return Ø 1/2” Supply Ø 1/2” Supply Ø 1/2” Condensate drain Ø 16.5 mm Condensate drain Ø... -
Page 6: Mounting Plate Installation
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL 6. Drill a piping hole 70.0 mm diameter hole either from the right or to the left fan MOUNTING PLATE INSTALLATION coil side and make sure that the hole is slightly slant downward. 1. -
Page 7: Field Piping Connection
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL 6. Connect the piping and make sure that the seals are fi tted neatly. 7. Connect the drain hose and tape over the connecting parts. WATER WATER WATER 8. -
Page 8: Wiring Connections
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING CONNECTIONS - Be sure to turn off the main power supply before open the frame grille for servicing. - Always refer to the wiring diagrams inside the unit. Connect the unit to adequate power outlet. -
Page 9: Wiring Diagrams
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING DIAGRAMS MOD. 1-2 WITH IR REMOTE CONTROL WITH ON/OFF VALVE 230 Vac CABLE COLORS: Blue Brown Black Yellow Green White LEGENDA: AUX. Emergency auxiliary switch Receiver with display UNIT LIMIT ID/OD Water temperature sensors... - Page 10 INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING DIAGRAMS MOD. 1-2 FORESEEN FOR REMOTE CONTROL WITH ON/OFF VALVE 230 Vac CAPACITOR CABLE COLORS: Blue Brown Black Yellow UNIT LIMIT Green White LEGENDA: Fan motor Terminal block 3 way valve SPEED 3 COMMON...
- Page 11 INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING DIAGRAMS MOD. 1-2 FORESEEN FOR REMOTE CONTROL WITHOUT ON/OFF VALVE 230 Vac CAPACITOR CABLE COLORS: Blue Brown Black UNIT LIMIT Yellow Green White LEGENDA: Fan motor Terminal block SPEED 3 COMMON Motor common...
- Page 12 INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING DIAGRAMS MOD. 1 WITH IR REMOTE CONTROL WITHOUT ON/OFF VALVE 230 Vac CABLE COLORS: Blue Brown Black Yellow Green White LEGENDA: AUX. Emergency auxiliary switch Receiver with display UNIT LIMIT ID/OD Water temperature sensors...
- Page 13 INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL WIRING DIAGRAMS MOD. 3-4 WITH IR REMOTE CONTROL WITHOUT ON/OFF VALVE 230 Vac CABLE COLORS: Blue Brown Black Yellow Green White LEGENDA: AUX. Emergency auxiliary switch UNIT LIMIT Receiver with display ID/OD Water temperature sensors...
-
Page 14: Air Purging
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL AIR PURGING PREPARATION OF THE REMOTE CONTROLLER 1. After connecting the water inlet and outlet pipes to the main water supply - Open the battery cover by pressing slightly in the direction of arrow. lines, turn on the power and operate the unit by pressing the Auxiliary switch. -
Page 15: Operation Guide Of Remote Controller
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL 1. POWER ON/OFF 12. TIMER ON - Press POWER “ ” button will turn on the air conditioner or vice versa. When - The air conditioner can be programmed to turn off in advance. turn on, it will operate according to the setting shown on the remote unit. - Page 16 INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL 5. PRESS THE “SWING” AND “LOUVER” BUTTON FUNCTIONING IN JUST VENTILATION MODE - When the “SWING” button is pressed, the horizontal louver is oriented conti- This program is used to move the room air and avoid stagnation. nuously oscillating movements.
-
Page 17: Self Diagnostic
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL - Press “SET” button, the ( ) symbol will display on the LCD screen. - If this function is activated, unit will start automatically everytime it reach the time setting. -
Page 18: Trouble Shooting Guide
INSTALLATION, OPERATION Vers. 2013-0 wall mounted fan coil unit AND MAINTENANCE MANUAL TROUBLE SHOOTING GUIDE IMPORTANT INFORMATION If the unit appears to be malfunctioning, check the following points before calling The unit is connected to the power supply. Operations performed by per- for service. - Page 19 NOTE...
- Page 20 With the perspective of improvement, and against the continuous action of research and development, the Manufacturer might modify, even without any prior notice, the given technical data.
