WisGate Edge Pro RAK7289C User Manual
1 Product description
WisGate Edge is RAKwireless'
to work either indoor, customizable in terms of the backhaul connectivity options, antenna type, and power provisioning.
RAK7289 WisGate Edge Pro is a LoRaWAN Gateway. It is ideal product for IoT commercial deployment. With its industrial-
grade components, it achieves a high standard of reliability.
It supports up to 16 LoRa channels, multi backhaul with Ethernet, Wi-Fi, and Cellular connectivity. Optionally there is a
dedicated port for different power options, solar panels, and batteries. With its new enclosure design, it allows the LTE,
Wi-Fi, and GPS antennas to be inside the enclosure.
The gateway provides for a solid out-of-the-box experience for quick deployment. Additionally, since its software and UI
sits on top of OpenWRT it is perfect for the development of custom applications (via the open SDK).
Manufacturer's address:
Shenzhen RAKwireless Technology Co., Ltd.
Room 506, Bldg B, New Compark, Pingshan First Road, Taoyuan Street, XiLi Town Nanshan District, Shenzhen, China
Instructions for use and safety information:
For safe commissioning, please read this manual and the documentation of your product. The complete
documentation and further information about your product can be found in the RAKwireless
Documentation Center: https://docs.rakwireless.com/Product-Categories/WisGate/#wisgate-edge. To
do this, enter the product name or item number in the search box and click Search.
PRODUCT NAME: WisGate Edge Pro
MODEL NAME: RAK7289C
flagship line of commercial-grade gateways. Gateways from this product line are designed
Advertisement
Table of Contents
Related Manuals for RAKwireless WisGate Edge Pro
Summary of Contents for RAKwireless WisGate Edge Pro
- Page 1 RAK7289 WisGate Edge Pro is a LoRaWAN Gateway. It is ideal product for IoT commercial deployment. With its industrial- grade components, it achieves a high standard of reliability.
-
Page 2: Packing List
2 Packing List Device (1x) Installation Bracket (1x) Cable Gland (1x) LoRa Antenna (1x or 2x) Power Cord (1x) Power Adapter (1x) Waterproof Tape (1x) PVC Insulating tape (1x) 12V Cable (1x) User Manual (1x) -
Page 3: Product Specifications
3 Product specifications Feature Specifications Computing MT7628, DDR2 RAM 128 MB Frequency: 2.4 GHz (802.11 b/g/b/) 2x2 MIMO Wi-Fi feature X Sensitivity: -95 dBm (Min) TX Power: 20 dBm (Max) Operation channels: 2.4 GHz: 1-13 SX1303 mPCIe card (connects maximum of two) 8 Channels (16 channels optional) LoRa feature RX Sensitivity: -139 dBm (Min) -
Page 4: Interfaces And Connectors
4 Interfaces and connectors RAK7289’s interfaces and connectors are illustrated below: Notes: The SD card and the SIM card do not support hot-swap. Please always turn off the gateway before you insert or take off SIM or SD card. ... -
Page 5: Leds Status
5 LEDs Status Name Status Description ON – device power on ON/OFF OFF –device power off ON – link up ON/OFF/FLASH OFF – link down Flash - data transmitting and receiving ON - LoRa1 is working LoRa1 ON/OFF/FLASH OFF - LoRa1 is not working Flash - LoRa1 packet transmitting and receiving ON - LoRa2 is working LoRa2... -
Page 6: Installation
6 Installation Instructions on mounting and securing the mounting kit to the enclosure and the bearing pole. 6.1 Mounting Step 1. Fix the device bracket on the bottom of the enclosure with four M6*12 screws as shown below. Step 2. Position and tighten the pole clamps together around the pole with bolts, washers, and nuts. Note: The diameter of the pole that is supported by the brackets is 50-100 mm. - Page 7 6.2 Connecting the PoE Adapter Step 1. Connect the Ethernet cable from the enclosure to the Ethernet port labeled POE on the adapter. Step 2. Connect an Ethernet cable from your LAN network to the Ethernet port labeled LAN on the adapter. Step 3.
- Page 8 Step 2. Cut off about 50 cm waterproof tape. Stretch it to double the length. Wrap three layers around the connector with a 50% overlap. Hold the tape in place with your hand for a few seconds. Step 3. Wrap three additional layers with PVC tape with natural uncoiling force and a 50% overlap. Make sure to cover the head and the tail of the connector.
-
Page 9: Accessing The Gateway
7 Accessing the gateway Make sure all the antennas are connected before powering the Gateway. The Gateway comes configured in such a way that you can use either the Ethernet port or the Wi-Fi in AP mode to connect to the Management platform. In both modes you can access the Management UI via a web browser pointing to the IP address of the gateway (check your router DHCP list). - Page 10 Note: Detailed Quick Start Guides for the modules are available in the RAKwireless Documentation Center: https://docs.rakwireless.com/Product-Categories/WisGate/RAK7289/Overview/#product-description 8 Certification warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
