Package Contents
The w8 package includes:
12V Power Adapter
●
54V Power Adapter (PoE+)
●
Rubber feet
●
2x WiFi antennas
●
w8 appliance
●
Micro USB cable
●
Installation
1.
For desktop installation, attach the rubber feet to the bottom corners of the appliance.
2.
Fasten the included WiFi antennas to the WiFi labeled SMA connectors.
3.
Plug in the 12V power adapter to a power source and connect it to the DC 12V power input on the rear panel.
4.
Plug in the 54V power adapter to a power source and connect it to the DC 54V power input on the rear panel.
5.
Connect an ethernet cable from your Internet modem or router to Port 1.
6.
Connect an ethernet cable from your network switch to Port 2.
7.
Power on the system by pressing the power button located on the rear panel next to the power input.
8.
Allow approximately 2 minutes for the system to initialize before continuing with the next steps.
untangle.com | © Copyright 2022. Untangle, Inc. All rights reserved.
Rear Panel
Front Panel
w8 Setup Guide
w8 Setup Guide - Page 1
Advertisement
Table of Contents
Related Manuals for Untangle w8
Summary of Contents for Untangle w8
- Page 1 Power on the system by pressing the power button located on the rear panel next to the power input. Allow approximately 2 minutes for the system to initialize before continuing with the next steps. untangle.com | © Copyright 2022. Untangle, Inc. All rights reserved. w8 Setup Guide - Page 1...
- Page 2 From Command Center Navigate your web browser to https://untangle.com/cmd. Log in with your Untangle Command Center account, or click Create Account to set up an account. Navigate to the Appliances screen and click Add. Enter the Untangle serial number located on the bottom of your appliance.
