Specifications - igus i.Sense CF.D Manual

Product

3.2 Specifications

Mechanical Specifications
D x W x H in millimeters
Weight in grams
Fastening / Assembly
Case
Interfaces
UART
Ethernet
Electrical Specifications
Power supply
Rated current
Measurement interval
Configuration optionen
Frequency band
Output power
- Risk of destruction
An operating voltage above the voltage specified in the technical data destroys the i.Sense CF.D. Select an operating
voltage that is within the voltage range specified in the technical data.
Be aware of possible disturbances and induced voltages caused by other consumers and/or motors and plan appropriate
safety reserves and countermeasures. Make sure that your power supply is back-proof if the logic and load voltage are
supplied from the same power supply or transformer
Ambient conditions
Temperature range
Relative humidity
Protection
- Risk of malfunctions
- Fire
- Danger of explosion
- Risk of electric shock
Operate i.Sense CF. D not in water, humid environments or in aggressive, flammable or explosive atmospheres.
Manual i.Sense CF.D - V 1.1
31 x 32 x 84 mm
Approx. 50 g
Built into network transmission cable
Black or golden aluminum housing
5V 115200 baud, 8N1, no parity
100 Mbit/s, connection of the line to be measured
5 V DC
0.15 A
1s – 24h
- Measurement interval (in seconds)
- Measuring frequency/ measuring channel (0 - 9)
- Output power
868... 886 MHz
3... 100 mW
Operation
Storage
Transport
≤ 90%, non-condensing
IP 30/ DIN EN 60529
-20... 40 °C
-40... 45 °C
-40... 45°C
6/13
