Product

2.3 Electromagnetic compatibility

- Risk of injury due to interference of signals and devices
Disturbed signals can cause unforeseen device actions.
Perform wiring according to EMC guidelines. Failure to comply with these precautions may result in death, serious injury
or material damage.
EMC measures
Use cable clamps for shield support,
connect metallic parts over a large area
Device
Add switching devices such as contactors,
assembly
relays or solenoid valves with interference
suppression
extinguishing
varistors, RC links).
Keep cables as short as possible
Do not lay sensor cables and signal cables
together with cables for DC and AC voltage
above 60 V in a cable duct.
Wiring
Ground shields of digital signal lines on both
sides over a large area or via conductive
connector housings.
3 Product

3.1 Modes

Mode
Config mode
Measuring mode
Manual i.Sense CF.D - V 1.1
combination or
elements (e.g. diodes,
Description
- Updates and firmware reset
- Determination of the data after start of the measurement, setting of the measurement
parameters
Effects
Good conductivity due to flat contact
spark Reduce mutual interference coupling.
Avoid capacitive and inductive interference couplings
Avoidance of mutual interference coupling
Avoid interference with control cables, reduce emissions.
