Socket SOMO 650RX Specification Sheet

With antimicrobial protection

Advertisement

Quick Links

Size
Weight
Antimicrobial Rating
(JIS Z2801:2000 Test)
Display
Touch Panel
Backlight
Extended Battery
Backup Battery
Expansion Slots
LED Indicators
Buttons
Input Devices
Connectors
Audio
Pre-loaded Socket Software
Pre-loaded 3rd Party
Software
Processor
Operating System
Memory
SoMo File Store
Operating Temperature
Storage Temperature
Humidity
Drop Specification
ESD Specification
*Wi-Fi Companion is pre-installed. Enhanced Wi-Fi Companion is optional to install.
SoMo
®
650Rx Handheld Computer
With Antimicrobial Protection
S p e c i f i c a t i o n S h e e t
5.00 x 2.94 x 0.98 inches (127 x 74.60 x 25 mm)
7.20 oz (204 g) with extended battery and stylus
2.49 on Methicillin-resistant Staphylococcus aureus (MRSA)
6.07 when cleaned with Sani-Cloth
EasyView® 65K colors TFT LCD, 3.5" 16 bit per pixel, 240 (w) x 320 (l) resolution
Glass analog resistive touch
White LED backlight
3.7V 2600 mAh Lithium Ion rechargable
Super Capacitor to support Realtime Clock
CompactFlash and SDIO Slots: Reinforced to prevent damage from drop events
Red/Green LED for alarm, battery charging
Blue/Green LED for Bluetooth and Wireless LAN
4 front panel programmable soft buttons
2 side programmable action buttons
Control hold switch
Stylus (Note: touch sensitive display for stylus or fingertip)
Barrel connector power jack
26 pin docking connector for ActiveSync
USB 1.1 host & USB 2.0 Client
2.5mm headset jack with support for both voice and stereo music
Built-in Microphone and Speaker, voice recording capability with Notes application
SocketScan™ keyboard wedge
Serial I/O Card drivers
SoMo 650 Back Pack software
Programmable Home Screen
Outlook Mobile
PowerPoint Mobile
.NET Compact Framework v2.0
Intel PXA270 @ 624 MHz
®
Windows Mobile
6 Classic - Worldwide English
Other languages available with ROM upgrade DVD (sold separately)
128MB SDRAM, 256MB NAND FLASH
Non-volatile memory for device applications/configurations can survive hard reset of device
Features Auto-Run support, ideal for provisioning deployments
0° to 50° C (32° to 120° F)
-25° to 75° C (-13° to 167° F)
95% non-condensing
Multiple 1 meter drops to concrete covered with vinyl
+/- 8kV air discharge, +/- 8kV direct discharge
®
Plus disposable cloth wipes
5 navigation buttons
Device reset button
Power on/off button
Connect!Agent
Bluetooth
Enhanced Wi-Fi
®
Companion
USB Ethernet Gigabit Adapter drivers
IE Mobile
Word Mobile
Calculator
ActiveSync Client
®
software
Modem Utilities
software*
Ethernet Utilities
USB to Serial drivers
Excel Mobile
Windows Media Player 10.2 Mobile
MSN Messenger Client
